Bosch GTA 60 W Professional: Symbols

14

 | English

1 609 929 S18 | (29/1/09)

Bosch Power Tools

Symbols

The following symbols can be important for the

operation of your saw stand. Please memorise

the symbols and their meanings. The correct in-

terpretation of the symbols helps you operate

the saw stand better and more secure.

Functional Description

Read all warning notes and instruc-

tions enc slosed with the saw

stand and the power tool to be

mounted.

Failure to follow the

warnings and instructions may re-

sult in electric shock, fire and/or se-

rious injury.

Intended Use

The saw stand is intended exclusively for mount-

ing the following stationary Bosch saws  (as of

2008.11):

– GTS 10

3 601 L30 0..

Together with the power tool, the saw stand is

intended for the cutting to length of boards and

profiles.

The saw stand is also suitable for various com-

petitor products (see page 16).

Product Features

The numbering of the product features refers to

the illustration of the saw stand on the graphics

pages.

1

Mounting plate

2

Lock for the wheels

8

3

Handle

4

Limit bolt

5

Height-adjustable leg

6

Upper frame with lock

2

7

Bottom frame

8

Wheel

9

Linkage bar

10

Foot lever

11

Fastening kit

12

Wing nut

*Accessories shown or described are not part of the

standard delivery scope of the product. A complete

overview of accessories can be found in our acces-

sories program.

Technical Data

Symbol

Meaning

The maximum carrying ca-

pacity (power tool + work-

piece) of the saw stand is

180 kg.

180

kg

Saw stand

GTA 60 W

Professional

Article number

3 601 M12 000

Height of saw stand

mm

622

Max. carrying capacity

(power tool + work-

piece)

kg

180

Weight according to

EPTA-Procedure

01/2003

kg

35
