Assembly

Delivery Scope

Please also observe the represen-

tation of the delivery scope at the

beginning of the operating instruc-

tions.

Before assembling the saw stand, check if all

parts listed below are provided:

Additionally required tools (not in delivery

scope):

– Phillips screwdriver

– Open-end spanner  (10 mm, 8 mm, 6 mm)

Assembling the Mobile Stand Base

– Carefully remove all parts included in the de-

livery from their packaging.

– Remove all packaging material.

– For assembly, follow figures A – E. Also ob-

serve the following notes.

For Fig. A:

– Bolt the upper frame

6

 and the bottom frame

7

 together.

For Fig. B:

– Screw both the left and right wheel

8

 to the

upper frame

6

.

Pay attention that the linkage bars

9

 face out-

ward and that the tires of the wheels face to-

ward the bottom frame

7

.

Note:

Do not over-tighten the nuts. Parts bolted

together must move freely.

For Fig. C:

– Bolt the foot lever

10

 to both wheels

8

.

For Fig. D:

– Screw the mounting plate

1

 on both sides to

the upper frame

6

.

Note:

Do not over-tighten the nuts. Parts bolted

together must move freely.

For Fig. E:

– Bolt the left and right linkage bar

9

 each to

the mounting plate

1

.

Note:

Do not over-tighten the nuts. Parts bolted

together must move freely.

No. Designation

Quantity

1

Mounting plate

1

6

Upper frame with lock

2

1

7

Bottom frame

1

8

Wheel with linkage bar

9

2

10

Foot lever

1

11

Fastening kit

consisting of:

– Hexagon bolt

M10 x 100

M10 x 50

M6 x 110

M6 x 75

M6 x 40

– Phillips screw

M8 x 50

– Washer

M10

M10 (clamping washer)

M6

– Lock  nut

M10

M8

M6

6

2

4

4

4

6

18

2

8

6

6

4
