English
Safety Notes
Read and observe all instructions. SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
Have the measuring tool repaired only through qualified specialists using
original spare parts. This ensures that the safety of the measuring tool is main-
tained.
Do not operate the measuring tool in explosive environments, such as in the
presence of flammable liquids, gases or dusts. Sparks can be created in the
measuring tool which may ignite the dust or fumes.
Keep the measuring tool away from cardiac pacemakers. The
magnet plate 5 generates a field that can impair the function of car-
diac pacemakers.
Keep the measuring tool away from magnetic data medium and magnetically-
sensitive equipment. The effect of the magnet plate 5 can lead to irreversible da-
ta loss.
Bosch Power Tools 1 609 92A 05F | (20.12.12)
OBJ_BUCH-821-003.book Page 14 Thursday, December 20, 2012 12:37 PM
14 | English
Product Description and Specifications
Please unfold the fold-out page with the representation of the measuring tool and
leave it unfolded while reading the operating instructions.
Intended Use
The measuring tool is intended for swift finding of pulsating laser beams.
Technical Data
Laser Receiver LR 2
Article number
3 601 K69 100
Working range
1)
5–50m
Receiving angle
90°
Measuring accuracy
2)
– “Fine” adjustment
±1mm
–“Coarse” adjustment
±3mm
Operating temperature
–10 °C...+50 °C
Storage temperature
–20 °C...+70 °C
Battery
1x9V(6LR61)
Operating life time, approx.
30 h
Weight according to EPTA-Procedure 01/2003
0.2 kg
Degree of protection
IP 54 (dust and splash water
protected)
Dimensions (length x width x height)
74 x 41 x 150 mm
1) The working range can be decreased by unfavourable environmental conditions (e.g. direct sun
irradiation).
2) depends on distance between laser receiver and cross-line laser
The measuring tool can be clearly identified with the serial number 12 on the type plate.
Product Features
The numbering of the product features shown refers to the illustration of the measur-
ing tool on the graphic page.
1 Button for adjustment of the measuring accuracy
2 On/Off button
3 Audio signal button
4 Display
1 609 92A 05F | (20.12.12) Bosch Power Tools
OBJ_BUCH-821-003.book Page 15 Thursday, December 20, 2012 12:37 PM
English | 15
5 Magnet plate
6 Direction LED “move downward”
7 Centre-indication LED
8 Centre mark
9 Direction LED “move upward”
10 Reception area for the laser beam
11 Latch of battery lid
12 Serial number
13 Battery lid
14 Mounting hole for M6 thread
The accessories illustrated or described are not included as standard delivery.
Display Elements
a Audio signal indicator
b Direction indicator “move upward”
c Centre indicator
d Direction indicator “move downward”
e Battery low indicator
f “Coarse” adjustment indicator
g “Fine” adjustment indicator
Noise Information
The A-weighted sound pressure level of the audio signal at one meter distance
is 80 dB(A).
Do not hold the measuring tool close to your ear!
Assembly
Inserting/Replacing the Battery
Alkali-manganese batteries are recommended for the measuring tool.
Pull the latch 11 of battery lid outward and open the battery lid 13.
When inserting the battery, pay attention to the correct polarity according to the rep-
resentation on the inside of the battery compartment.
When the battery low indicator e appears for the first time on the display 4, the meas-
uring tool can still be operated for approx. 2 h.
If the measuring tool is not used for a long period of time, the battery must be
removed. The battery can corrode or discharge itself over long periods.
Bosch Power Tools 1 609 92A 05F | (20.12.12)
OBJ_BUCH-821-003.book Page 16 Thursday, December 20, 2012 12:37 PM
16 | English
Operation
Initial Operation
Protect the measuring tool against moisture and direct sun light.
Do not subject the measuring tool to extreme temperatures or variations in
temperature. As an example, do not leave it in vehicles for long time. In case of
large variations in temperature, allow the measuring tool to adjust to the ambient
temperature before putting it into operation. In case of extreme temperatures or
variations in temperature, the accuracy of the measuring tool can be impaired.
Setting Up the Measuring Tool (see figure A)
Position the measuring tool at least 5 m away from the cross-line laser. Switch on the
pulsating function on the cross-line laser, and select horizontal or vertical operation.
Note: Do not select cross-line operation, as otherwise faulty indications on the height
of the laser beam can occur.
Position the measuring tool in such a manner that the laser beam can reach the recep-
tion area 10. Align the measuring tool in such a manner that the laser beam runs lat-
erally through the reception area (as shown in the figure).
Switching On and Off
A loud audio signal sounds when switching on the measuring tool. Therefore,
keep the measuring tool away from your ear or other persons when switching
on. The loud audio signal can cause hearing defects.
To switch on the measuring tool, press the On/Off button 2. All display indicators as
well as all LEDs light up briefly and an audio signal sounds.
To switch off the measuring tool, press the On/Off button 2 again. Before switching
off, all LEDs briefly light up.
When no button is pressed on the measuring tool for approx. 20 minutes and when no
laser beam reaches the reception area 10 for 20 minutes, the measuring tool auto-
matically switches off in order to save the battery. The switching off is indicated by
brief lighting up of all LEDs.
Selecting the Setting of the Centre Indicator
With button 1, you can specify with which accuracy the position of the laser beam is
indicated as central on the reception area:
– “Fine” adjustment (indication g on the display),
– “Coarse” adjustment (indication f on the display).
Whenever switching on the measuring tool, the accuracy level “coarse” is set.
1 609 92A 05F | (20.12.12) Bosch Power Tools
OBJ_BUCH-821-003.book Page 17 Thursday, December 20, 2012 12:37 PM
English | 17
Direction Indicators
The position of the laser beam on the reception area 10 is indicated:
– via the direction indicators “move downward” d, “move upward” b or the centre in-
dicator c on the display 4 on the front and back side of the measuring tool,
– via the LEDs “move downward” 6, “move upward” 9 or the centre-indication LED 7
on the front side of the measuring tool,
– optionally via the audio signal (see “Audio Signal for Indication of the Laser Beam”,
page 17).
Measuring tool too low: When the laser beam runs through the top half of the recep-
tion area 10, the direction indicator b on the display and the corresponding direction
LED 9 light up.
When the audio signal is switched on, a slow-beat signal sounds.
Move the measuring tool upward in the direction of the arrow.
Measuring tool too high: When the laser beam runs through the bottom half of the
reception area 10, the direction indicator d on the display and the corresponding di-
rection LED 6 light up.
When the audio signal is switched on, a fast-beat signal sounds.
Move the measuring tool downward in the direction of the arrow.
Measuring tool in centre position: When the laser beam runs through the reception
area 10 at the centre mark 8, the centre indicator c on the display and the corre-
sponding centre-indication LED 7 light up. When the audio signal is switched on, a
continuous signal sounds.
Audio Signal for Indication of the Laser Beam
The position of the laser beam on the reception area 10 can be indicated via an audio
signal.
After the measuring tool has been switched on, the audio signal is always set to the
low volume level.
The volume level can be increased or switched off.
To change the volume level or switch off the audio signal, push the acoustic signal but-
ton 3 until the requested volume level is indicated on the display. At low volume level,
the audio signal indicator a appears on the display with one bar; at high volume level,
the indicator appears with three bars. When the audio signal is set to off, the indicator
goes out.
Independent of the audio signal setting, a short beep sounds at low volume level each
time a button is pressed on the measuring tool.
Bosch Power Tools 1 609 92A 05F | (20.12.12)
OBJ_BUCH-821-003.book Page 18 Thursday, December 20, 2012 12:37 PM
18 | English
Working Advice
Marking
When the laser beam runs through the center of the reception area 10, its height can
be marked at the centre mark 8 right and left on the measuring tool.
When marking, take care to align the measuring tool exactly vertical (for horizontal
laser beam), or horizontal (for vertical laser beam), as otherwise the marks are offset
with respect to the laser beam.
Attaching with the Magnet (see figure B)
When a positive-lock attachment is not absolutely required, the measuring tool can be
attached to steel parts via the face side using the magnet plate 5.
Maintenance and Service
Maintenance and Cleaning
Keep the measuring tool clean at all times.
Do not immerse the measuring tool in water or other fluids.
Wipe off debris using a moist and soft cloth. Do not use any cleaning agents or sol-
vents.
If the measuring tool should fail despite the care taken in manufacturing and testing
procedures, repair should be carried out by an authorised after-sales service centre
for Bosch power tools. Do not open the measuring tool yourself.
In all correspondence and spare parts orders, please always include the 10-digit
article number given on the type plate of the measuring tool.
After-sales Service and Application Service
Our after-sales service responds to your questions concerning maintenance and
repair of your product as well as spare parts. Exploded views and information on
spare parts can also be found under:
www.bosch-pt.com
Bosch’s application service team will gladly answer questions concerning our prod-
ucts and their accessories.
1 609 92A 05F | (20.12.12) Bosch Power Tools
OBJ_BUCH-821-003.book Page 19 Thursday, December 20, 2012 12:37 PM
English | 19
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: (0844) 7360109
Fax: (0844) 7360146
E-Mail: boschservicecentre@bosch.com
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: (01) 4666700
Fax: (01) 4666888
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 428570
Outside AU and NZ:
Phone: +61 3 95415555
www.bosch.com.au
Bosch Power Tools 1 609 92A 05F | (20.12.12)
OBJ_BUCH-821-003.book Page 20 Thursday, December 20, 2012 12:37 PM
20 | English
Republic of South Africa
Customer service
Hotline: (011) 6519600
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: (011) 4939375
Fax: (011) 4930126
E-Mail: bsctools@icon.co.za
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: (031) 7012120
Fax: (031) 7012446
E-Mail: bsc.dur@za.bosch.com
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: (021) 5512577
Fax: (021) 5513223
E-Mail: bsc@zsd.co.za
Bosch Headquarters
Midrand, Gauteng
Tel.: (011) 6519600
Fax: (011) 6519880
E-Mail: rbsa-hq.pts@za.bosch.com
People’s Republic of China
China Mainland
Bosch Power Tools (China) Co., Ltd.
567, Bin Kang Road
Bin Jiang District 310052
Hangzhou, P.R.China
Service Hotline: 4008268484
Fax: (0571) 87774502
E-Mail: contact.ptcn@cn.bosch.com
www.bosch-pt.com.cn
1 609 92A 05F | (20.12.12) Bosch Power Tools
OBJ_BUCH-821-003.book Page 21 Thursday, December 20, 2012 12:37 PM
English | 21
HK and Macau Special Administrative Regions
Robert Bosch Hong Kong Co. Ltd.
21st Floor, 625 King’s Road
North Point, Hong Kong
Customer Service Hotline: +852 2101 0235
Fax: +852 2590 9762
E-Mail: info@hk.bosch.com
www.bosch-pt.com.hk
Indonesia
PT. Multi Mayaka
Kawasan Industri Pulogadung
Jalan Rawa Gelam III No. 2
Jakarta 13930
Indonesia
Tel.: (021) 46832522
Fax: (021) 46828645/6823
E-Mail: sales@multimayaka.co.id
www.bosch-pt.co.id
Philippines
Robert Bosch, Inc.
28th Floor Fort Legend Towers,
3rd Avenue corner 31st Street,
Fort Bonifacio Global City,
1634 Taguig City, Philippines
Tel.: (02) 8703871
Fax: (02) 8703870
matheus.contiero@ph.bosch.com
www.bosch-pt.com.ph
Bosch Service Center:
9725-27 Kamagong Street
San Antonio Village
Makati City, Philippines
Tel.: (02) 8999091
Fax: (02) 8976432
rosalie.dagdagan@ph.bosch.com
Bosch Power Tools 1 609 92A 05F | (20.12.12)
OBJ_BUCH-821-003.book Page 22 Thursday, December 20, 2012 12:37 PM
22 | English
Malaysia
Robert Bosch (S.E.A.) Sdn. Bhd.
No. 8A, Jalan 13/6
G.P.O. Box 10818
46200 Petaling Jaya
Selangor, Malaysia
Tel.: (03) 79663194
Fax: (03) 79583838
cheehoe.on@my.bosch.com
Toll-Free: 1800 880188
www.bosch-pt.com.my
Thailand
Robert Bosch Ltd.
Liberty Square Building
No. 287, 11 Floor
Silom Road, Bangrak
Bangkok 10500
Tel.: 02 6311879 – 1888 (10 lines)
Fax: 02 2384783
Robert Bosch Ltd., P. O. Box 2054
Bangkok 10501, Thailand
Bosch Service – Training Centre
2869-2869/1 Soi Ban Kluay
Rama IV Road (near old Paknam Railway)
Prakanong District
10110 Bangkok
Thailand
Tel.: 02 6717800 – 4
Fax: 02 2494296
Fax: 02 2495299
Singapore
Robert Bosch (SEA) Pte. Ltd.
11 Bishan Street 21
Singapore 573943
Tel.: 6571 2772
Fax: 6350 5315
leongheng.leow@sg.bosch.com
Toll-Free: 1800 3338333
www.bosch-pt.com.sg
1 609 92A 05F | (20.12.12) Bosch Power Tools
OBJ_BUCH-821-003.book Page 23 Thursday, December 20, 2012 12:37 PM
English | 23
Vietnam
Robert Bosch Vietnam Co. Ltd
10/F, 194 Golden Building
473 Dien Bien Phu Street
Ward 25, Binh Thanh District
84 Ho Chi Minh City
Vietnam
Tel.: (08) 6258 3690 ext. 413
Fax: (08) 6258 3692
hieu.lagia@vn.bosch.com
www.bosch-pt.com
Disposal
Measuring tools, accessories and packaging should be sorted for environmental-
friendly recycling.
Do not dispose of measuring tools and batteries/rechargeable batteries into house-
hold waste!
Only for EC countries:
According to the European Guideline 2002/96/EC, measuring
tools that are no longer usable, and according to the European
Guideline 2006/66/EC, defective or used battery packs/batteries,
must be collected separately and disposed of in an environmentally
correct manner.
Batteries no longer suitable for use can be directly returned at:
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: (0844) 7360109
Fax: (0844) 7360146
E-Mail: boschservicecentre@bosch.com
Subject to change without notice.
Bosch Power Tools 1 609 92A 05F | (20.12.12)
