Assembly

Inserting/Replacing the Battery

Use only alkali-manganese batteries.

Press the latch

9

 of the battery lid outward with a suitable tool and

open the battery lid

10

.

When inserting batteries, pay attention to the correct polarity ac-

cording to the representation on the inside of the battery compart-

ment.

When the direction indicators

4

 and

2

 flash alternately, the batter-

ies must be replaced.

Always replace all batteries at the same time. Only use batteries

from one brand and with the identical capacity.

f

Remove the batteries from the measuring tool when not using

it for extended periods.

When storing for extended periods,

the batteries can corrode and discharge themselves.

Operation

Initial Operation

f

Do not subject the measuring tool to extreme temperatures or

variations in temperature.

As an example, do not leave it in ve-

hicles for longer periods. In case of large variations in tempera-

ture, allow the measuring tool to adjust to the ambient temper-

ature before putting it into operation.

Position the measuring tool at least 50 cm away from the laser level

and in such a manner that the laser beam can reach the reception

area

6

. Set the highest rotational speed on the laser level.

OBJ_BUCH-71-002.book  Page 19  Friday, July 20, 2007  10:07 AM

1 609 929 L81 | (20.7.07)

Bosch Power Tools

20

 | English

Switching On and Off

f

A loud audio signal sounds when switching on the measuring

tool. Therefore, keep the measuring tool away from your ear

or other person when switching on.

The loud audio signal can

cause hearing defects.

For

switching on

 the measuring tool, briefly press button

5

(“<1 sec on

”

). The direction indicators

4

,

3

 and

2

 on the front and

rear side of the measuring tool light up for one second and a brief

audio signal sounds.

To indicate the operational readiness, the centre indicator

3

 lights

up every 2 seconds when the receiver is switched on. As soon as

the laser beam runs through the reception area

6

, the direction in-

dicators

4

,

3

 and

2

 indicate only the height of the laser beam (see

“Direction Indicators

”

, page 20).

To

switch off

 the measuring tool, press button

5

 for more than one

second (“>1 sec off

”

). The switching off of the measuring tool is in-

dicated by the three direction indicators

4

,

3

 and

2

 lighting up, and

a brief audio signal sounds.

When no pushbutton on the measuring tool is pressed for approx.

30 minutes and when no laser beam is impinged upon the recep-

tion area

6

 for 30 minutes, the measuring tool switches off auto-

matically to save the batteries.

Direction Indicators

The direction indicators for bottom

4

, centre

3

 and top

2

 (on both

the front and rear side of the measuring tool) as well as the audio

signal indicate the position of the rotating laser beam in the recep-

tion area

6

.

When the laser beam runs through the reception area

6

 the first

time, a single tone is signalled, even when the audio signal is

switched off.

OBJ_BUCH-71-002.book  Page 20  Friday, July 20, 2007  10:07 AM

 English |

21

Bosch Power Tools

1 609 929 L81 | (20.7.07)

Laser beam too high:

 When the laser beam runs through the upper

half of the reception area

6

, the direction “bottom

”

 indicator

4

flashes. When the audio signal is switched on, a slow pulsing signal

sounds. In this case, move the measuring tool upward in the direc-

tion of the arrow.

Laser beam too low:

 When the laser beam runs through the lower

half of the reception area

6

, the direction “top

”

 indicator

2

 flashes.

When the audio signal is switched on, a fast pulsing signal sounds.

In this case, move the measuring tool downward in the direction of

the arrow.

Laser beam centred:

 When the laser beam runs through the recep-

tion area

6

 at the height of the centre mark

7

, then the centre indi-

cator

3

 flashes. When the audio signal is switched on, a continuous

signal sounds.

Audio Signal

The audio signal can be switched on and off. For this, briefly press

pushbutton

5

 once (“<1 sec

”

).

When the audio signal is switched on and off, the direction indica-

tors

4

,

3

 and

2

 light up briefly. When switching on, three audio sig-

nals sound; when switching off, a single audio signal sounds.

When the laser beam runs through the reception area

6

 the first

time, a single tone is signalled, even when the audio signal is

switched off.

After the measuring tool has been switched on, the audio signal is

always switched on.

OBJ_BUCH-71-002.book  Page 21  Friday, July 20, 2007  10:07 AM

1 609 929 L81 | (20.7.07)

Bosch Power Tools

22

 | English

Operating Instructions

Marking

The height of the laser beam can be marked at the centre mark

7

on the right and left of the measuring tool when it runs through the

centre of the reception area

6

. The centre mark is 50 mm away

from the upper edge of the measuring tool.

Aligning with the Spirit Level

The measuring tool can be aligned vertically (plumb line) with the

spirit level

1

. A measuring tool applied out-of-level leads to faulty

measurements.

Attaching with the Holder (see figure A)

With the holder

14

, the measuring tool can be fastened to a con-

struction laser measuring rod

16

 (accessory) as well as to other

auxiliary tools with a width of approx. 5 to 50 mm.

Slide the holder

14

 sidewards into the retainer openings

8

 on the

rear side of the measuring tool until it can be heard to latch.

Loosen the locking screw

17

, slide the holder onto the construc-

tion laser measuring rod

16

, for example, and retighten the locking

screw

17

.

The upper edge

15

 of the holder is located at the same height as

the centre mark

7

 and can be used for marking of the laser beam.

To remove the measuring tool from the holder

14

, press the holder

latch

13

 and pull the measuring tool out of the holder.

Attaching with the Magnet (see figure B)

When a positive-lock attachment is not absolutely required, the

measuring tool can be attached to steel parts via the face and rear

side using the magnet plate

12

.
