English
Safety Notes
Safety Warnings for Cordless Worklights
Read all safety warnings and all instructions.
Failure to follow the
warnings and instructions may result in electric shock, fire and/or seri-
ous injury.
Please read and observe all safety warnings and instructions enclosed with
the battery or the power tool, with which the battery was provided.
Handle the cordless worklight with care.
The cordless worklight generates in-
tense heat, which leads to increased danger of fire and explosion.
Do not work with the cordless worklight in hazardous areas.
After the automatic shut-off of the cordless worklight, do not continue to
press the On/Off button.
The battery could become damaged.
Do not direct the light beam at persons or animals and do not stare into the
light beam yourself (not even from a distance).
Use only original Bosch accessories.
Do not cover off the lamp head while operating the cordless worklight.
The
lamp head heats up during operation and can cause burns when the heat accumu-
lates.
Do not use the cordless worklight in road traffic.
The cordless worklight is not
approved for illumination in road traffic.
OBJ_BUCH-1279-003.book Page 12 Tuesday, December 11, 2012 10:43 AM
English |
13
Bosch Power Tools
1
6
09 9
2
A 01W | (11.1
2
.1
2
)
Before any work on the cordless worklight itself (e.g. assembling, mainte-
nance, etc.), as well as when transporting and storing, remove the battery
from the cordless worklight.
Do not allow children to use the cordless worklight.
It is intended for profes-
sional use. Children can unintentionally blind themselves or other persons.
Do not open the battery.
Danger of short-circuiting.
When battery pack is not in use, keep it away from other metal objects like pa-
per clips, coins, keys, nails, screws, or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals
together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery; avoid con-
tact. If contact accidentally occurs, flush with water. If liquid contacts eyes,
additionally seek medical help.
Liquid ejected from the battery may cause irrita-
tions or burns.
In case of damage and improper use of the battery, vapours may be emitted.
Ventilate the area and seek medical help in case of complaints.
The vapours
can irritate the respiratory system.
Recharge only with the charger specified by the manufacturer.
A charger that
is suitable for one type of battery pack may create a risk of fire when used with an-
other battery pack.
Use the battery only in conjunction with your Bosch product.
This measure
alone protects the battery against dangerous overload.
Use only original Bosch batteries with the voltage listed on the nameplate of
your cordless worklight.
When using other batteries, e. g. imitations, recondi-
tioned batteries or other brands, there is danger of injury as well as property dam-
age through exploding batteries.
Product Description and Specifications
Intended Use
The cordless worklight is intended for hand-guided illumination with regard to space
within dry areas.
Protect the battery against heat, e.g., against continuous intense sun-
light, fire, water, and moisture.
Danger of explosion.
OBJ_BUCH-1279-003.book Page 13 Tuesday, December 11, 2012 10:43 AM
14
| English
1
6
09 9
2
A 01W | (11.1
2
.1
2
)
Bosch Power Tools
Product Features
The numbering of the product features refers to the illustration of the cordless work-
light on the graphics page.
1
Lens plate
2
On/Off switch
3
Lamp head
4
Battery pack*
5
Battery unlocking button*
6
Retainer opening for carrying handle
7
Carrying handle
8
Heat sink
*Accessories shown or described are not part of the standard delivery scope of the product.
A complete overview of accessories can be found in our accessories program.
Technical Data
Assembly
Battery Charging (Accessory)
Use only the battery chargers listed on the accessories page.
Only these bat-
tery chargers are matched to the lithium ion battery of your cordless worklight.
Note:
The battery is supplied partially charged. To ensure full capacity of the battery,
completely charge the battery in the battery charger before using your power tool for
the first time.
The Lithium-Ion battery can be charged at any time without reducing its service life.
Interrupting the charging procedure does not damage the battery.
The lithium ion battery is protected against deep discharging by the “Electronic Cell
Protection (ECP)”. When the battery is empty, the cordless worklight is switched off
by means of a protective circuit.
Cordless Worklight
GLI VariLED
Article number
3
6
01 D43 4..
Rated voltage
V=
14.4
18
Lighting duration, approx.
min/Ah
115
135
Operating temperature
°C –10...+40 –10...+40
Storage temperature
°C –15...+50 –15...+50
Weight according to EPTA-Procedure 01/
2
003
kg
0.3
0.3
OBJ_BUCH-1279-003.book Page 14 Tuesday, December 11, 2012 10:43 AM
English |
15
Bosch Power Tools
1
6
09 9
2
A 01W | (11.1
2
.1
2
)
Do not continue to press the On/Off switch after the cordless worklight has
been automatically switched off.
The battery can be damaged.
To remove the battery
4
, press the battery unlocking button
5
and pull the battery to-
ward the rear out of the cordless worklight.
Do not exert any force when doing this.
The battery is equipped with a NTC temperature control which allows charging only
within a temperature range of between 0 °C and 45 °C. A long battery service life is
achieved in this manner.
Observe the notes for disposal.
Operation
Initial Operation
Inserting the battery
Use only original Bosch lithium ion batteries with the voltage listed on the
nameplate of your cordless worklight.
Using other batteries can lead to injuries
and pose a fire hazard.
Insert the charged battery
4
into lamp head
3
until it can be felt to engage and faces
flush against the lamp head
3
.
Switching On and Off
To
start
the cordless worklight, press the On/Off switch
2
.
To
switch off
the cordless worklight, press the On/Off switch
2
again.
To save energy, only switch the cordless worklight on when using it.
Temperature Dependent Overload Protection
When exceeding the allowable heat-sink temperature of
6
0 °C, the cordless worklight
flashes 3x and then switches off. Allow the cordless worklight to cool down, then
switch the cordless worklight on again.
Working Advice
When the lighting duration is ≤ 10 minutes, the luminous efficiency of the cordless
worklight is lower.
The lens plate
1
is used to scatter or diffuse the light when using the cordless work-
light e.g., as a reading lamp.
Swivelling the Lamp Head (see figure A)
The lamp head
3
can be swivelled by 135° max. in 15° steps.
OBJ_BUCH-1279-003.book Page 15 Tuesday, December 11, 2012 10:43 AM
16
| English
1
6
09 9
2
A 01W | (11.1
2
.1
2
)
Bosch Power Tools
Carrying Handle (see figure B)
The cordless worklight can be carried or fastened to an object with the carrying
handle
7
.
Maintenance and Service
Maintenance and Cleaning
When the battery is no longer operative, please refer to an authorised after-sales ser-
vice agent for Bosch power tools.
The cordless worklight is maintenance-free and and contains no components that
must be replaced or maintained.
To avoid damage, clean the plastic lens of the cordless worklight only with a dry, soft
cloth. Do not use cleaning agents or solvent.
If the cordless worklight should fail despite the care taken in manufacturing and test-
ing procedures, repair should be carried out by an authorized after-sales service
agent for Bosch power tools.
In all correspondence and spare parts orders, please always include the 10-digit arti-
cle number given on the nameplate of the cordless worklight.
After-sales Service and Application Service
Our after-sales service responds to your questions concerning maintenance and re-
pair of your product as well as spare parts. Exploded views and information on spare
parts can also be found under:
www.bosch-pt.com
Bosch’s application service team will gladly answer questions concerning our prod-
ucts and their accessories.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: (0844) 73
6
0109
Fax: (0844) 73
6
014
6
E-Mail: boschservicecentre@bosch.com
OBJ_BUCH-1279-003.book Page 16 Tuesday, December 11, 2012 10:43 AM
English |
17
Bosch Power Tools
1
6
09 9
2
A 01W | (11.1
2
.1
2
)
Ireland
Origo Ltd.
Unit
2
3 Magna Drive
Magna Business Park
City West
Dublin
2
4
Tel. Service: (01) 4
666
700
Fax: (01) 4
666
888
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag
66
Clayton South VIC 31
6
9
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 4
2
8570
Outside AU and NZ:
Phone: +
6
1 3 95415555
www.bosch.com.au
Republic of South Africa
Customer service
Hotline: (011)
6
519
6
00
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: (011) 4939375
Fax: (011) 49301
26
E-Mail: bsctools@icon.co.za
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: (031) 701
2
1
2
0
Fax: (031) 701
2
44
6
E-Mail: bsc.dur@za.bosch.com
OBJ_BUCH-1279-003.book Page 17 Tuesday, December 11, 2012 10:43 AM
18
| English
1
6
09 9
2
A 01W | (11.1
2
.1
2
)
Bosch Power Tools
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: (0
2
1) 551
2
577
Fax: (0
2
1) 5513
22
3
E-Mail: bsc@zsd.co.za
Bosch Headquarters
Midrand, Gauteng
Tel.: (011)
6
519
6
00
Fax: (011)
6
519880
E-Mail: rbsa-hq.pts@za.bosch.com
People’s Republic of China
China Mainland
Bosch Power Tools (China) Co., Ltd.
5
6
7, Bin Kang Road
Bin Jiang District 31005
2
Hangzhou, P.R.China
Service Hotline: 4008
26
8484
Fax: (0571) 8777450
2
E-Mail: contact.ptcn@cn.bosch.com
www.bosch-pt.com.cn
HK and Macau Special Administrative Regions
Robert Bosch Hong Kong Co. Ltd.
2
1st Floor,
62
5 King’s Road
North Point, Hong Kong
Customer Service Hotline: +85
2
2
101 0
2
35
Fax: +85
2
2
590 97
62
E-Mail: info@hk.bosch.com
www.bosch-pt.com.hk
Indonesia
PT. Multi Mayaka
Kawasan Industri Pulogadung
Jalan Rawa Gelam III No.
2
Jakarta 13930
Indonesia
Tel.: (0
2
1) 4
6
83
2
5
22
Fax: (0
2
1) 4
6
8
2
8
6
45/
6
8
2
3
E-Mail: sales@multimayaka.co.id
www.bosch-pt.co.id
OBJ_BUCH-1279-003.book Page 18 Tuesday, December 11, 2012 10:43 AM
English |
19
Bosch Power Tools
1
6
09 9
2
A 01W | (11.1
2
.1
2
)
Philippines
Robert Bosch, Inc.
2
8th Floor Fort Legend Towers,
3rd Avenue corner 31st Street,
Fort Bonifacio Global City,
1
6
34 Taguig City, Philippines
Tel.: (0
2
) 8703871
Fax: (0
2
) 8703870
matheus.contiero@ph.bosch.com
www.bosch-pt.com.ph
Bosch Service Center:
97
2
5-
2
7 Kamagong Street
San Antonio Village
Makati City, Philippines
Tel.: (0
2
) 8999091
Fax: (0
2
) 897
6
43
2
rosalie.dagdagan@ph.bosch.com
Malaysia
Robert Bosch (S.E.A.) Sdn. Bhd.
No. 8A, Jalan 13/
6
G.P.O. Box 10818
4
62
00 Petaling Jaya
Selangor, Malaysia
Tel.: (03) 79
66
3194
Fax: (03) 79583838
cheehoe.on@my.bosch.com
Toll-Free: 1800 880188
www.bosch-pt.com.my
Thailand
Robert Bosch Ltd.
Liberty Square Building
No.
2
87, 11 Floor
Silom Road, Bangrak
Bangkok 10500
Tel.: 0
2
6
311879 – 1888 (10 lines)
Fax: 0
2
2
384783
Robert Bosch Ltd., P. O. Box
2
054
Bangkok 10501, Thailand
OBJ_BUCH-1279-003.book Page 19 Tuesday, December 11, 2012 10:43 AM
20
| English
1
6
09 9
2
A 01W | (11.1
2
.1
2
)
Bosch Power Tools
Bosch Service – Training Centre
2
8
6
9-
2
8
6
9/1 Soi Ban Kluay
Rama IV Road (near old Paknam Railway)
Prakanong District
10110 Bangkok
Thailand
Tel.: 0
2
6
717800 – 4
Fax: 0
2
2
494
2
9
6
Fax: 0
2
2
495
2
99
Singapore
Robert Bosch (SEA) Pte. Ltd.
11 Bishan Street
2
1
Singapore 573943
Tel.:
6
571
2
77
2
Fax:
6
350 5315
leongheng.leow@sg.bosch.com
Toll-Free: 1800 3338333
www.bosch-pt.com.sg
Vietnam
Robert Bosch Vietnam Co. Ltd
10/F, 194 Golden Building
473 Dien Bien Phu Street
Ward
2
5, Binh Thanh District
84 Ho Chi Minh City
Vietnam
Tel.: (08)
62
58 3
6
90 ext. 413
Fax: (08)
62
58 3
6
9
2
hieu.lagia@vn.bosch.com
www.bosch-pt.com
Transport
The contained lithium-ion batteries are subject to the Dangerous Goods Legislation re-
quirements. The user can transport the batteries by road without further requirements.
When being transported by third parties (e.g.: air transport or forwarding agency),
special requirements on packaging and labelling must be observed. For preparation
of the item being shipped, consulting an expert for hazardous material is required.
Dispatch batteries only when the housing is undamaged. Tape or mask off open contacts
and pack up the battery in such a manner that it cannot move around in the packaging.
Please also observe possibly more detailed national regulations.
OBJ_BUCH-1279-003.book Page 20 Tuesday, December 11, 2012 10:43 AM
English |
21
Bosch Power Tools
1
6
09 9
2
A 01W | (11.1
2
.1
2
)
Disposal
Cordless worklights, battery packs, accessories and packaging should be
sorted for environmental-friendly recycling.
Do not dispose of cordless worklights and batteries/rechargeable batteries into
household waste!
Only for EC countries:
According to the European Guideline
2
00
2
/9
6
/EC for Waste
Electrical and Electronic Equipment, cordless worklights that are
no longer usable, and according to the European Guideline
2
00
6
/
66
/EC, defective or used battery packs/batteries, must be
collected separately and disposed of in an environmentally correct
manner.
Batteries no longer suitable for use can be directly returned at:
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: (0844) 73
6
0109
Fax: (0844) 73
6
014
6
E-Mail: boschservicecentre@bosch.com
Battery packs/batteries:
Li-ion:
Please observe the instructions in section “Transport”,
page
2
0.
Subject to change without notice.
OBJ_BUCH-1279-003.book Page 21 Tuesday, December 11, 2012 10:43 AM
