Bosch Remote Keypad: Functional Description

22

en

FMR-5000-C

F.01U.258.926 | 3.0 | 2012.09

Bosch Sicherheitssysteme GmbH

Functional Description

The Remote Keypad can be used to perform the same operating procedures as the control

panel, enabling variable operation of a networked system. It has the following functional

elements (see

Figure 1

,

Page 4

):

Installation

Follow the mounting instructions according to the mouting variant for your application.



Before mounting the housing, remove the operating unit. This prevents the touch screen

being damaged and facilitates installing the lower mounting screws.

Wiring



Connect the shield wires to the screw terminal (

Figure 11

,

Page 13

 (step 1).



Fasten the cables with cable ties (

Figure 11

,

Page 13

, step 1 to 4).

The Remote Keypad has

-

2 CAN interfaces (CAN1/CAN2) for networking

-

2 Ethernet interfaces (ETH1/ETH2) for networking

-

2 signal inputs (IN1/IN2)

-

1 USB and 1 RS232 interface

Consider the maximum cable length of 2 m when using the USB and RS232 interfaces (see

Figure 10

,

Page 12

).

WARNING!

Live components and stripped cable! Risk of injury from electric shock. The system must be

current-free during connection work.

NOTICE!

Installation must only be performed by authorized and specialized personnel!

Pos.

Designation

Function

A

Touch screen

Operating the networked system through virtual buttons and variable display windows

B

22 fixed buttons

Standard entries

C

11 LEDs

Indicating the operating status

D

Key switch

2 switch settings, freely programmable, e.g. for switching between day/night mode or

connecting/disconnecting for local alarm signaling

E

Reboot button

Remote Keypad HW reset

F

6-pin DIP switch

Configuration

G

3 rotary switches

Address setting

Mounting variants

Illustration

Mounting Instructions

Surface wall mounting

See

Figure 2, Page 5

, I

See

Figure 3

,

Page 6

 to

Figure 5

,

Page 8

 (step 1 to 13) and

Figure 6

,

Page 9

Flush wall mounting

See

Figure 2, Page 5

, II

See

Figure 3

,

Page 6

 to

Figure 5

,

Page 8

 (step 1 to 13) and

Figure 7

,

Page 10

Tilted installation

See

Figure 2, Page 5

, III

See

Figure 3

,

Page 6

 to

Figure 5

,

Page 8

 (step 1 to 13) and

Figure 8

,

Page 11

NOTICE!

You will find detailed information about the CAN and Ethernet networking of the fire panels in

the Networking Guide available for download at www.boschsecurity.com.
