Sony Grand Wega KF-42SX200K: Labelling and Selecting the screen format of Input Sources

24

Menu System

Menu System

This function enables you to select the size of the picture coming from the input source. It also allows you to assign a name to the

optional equipment you have connected to the sockets of this TV set. This name can contain up to 5 characters (letters or

numbers).

Labelling and Selecting the screen format of Input Sources

1

Press the

 button on the remote control to display the menu

on the screen.

2

Push the joystick   to select the

 symbol, then push

 to enter the

Set Up

 menu.

3

Push the joystick   or   to select

AV Preset

, then push

 to enter.

4

Push the joystick   or   to select the input source. Then push

to enter.

5

Push the joystick   or   to select:

 Off

(The size of picture is not automatically adjusted).

Normal

 (The size of picture is automatically adjusted according to

the broadcaster information).

Full

(The TV set automatically adjusts the picture size to

eliminate any dark areas on the TV picture (as shown in

the section “Changing the Screen Format”).

Next push

 .

6

With the first element of the

LABEL

 column highlighted, push the

joystick   or   to select a letter, number, "+" or blank;

then push

 to confirm this character. Select the other four

characters in the same way.

7

After selecting all the characters, press the

 button.

8

Repeat steps 4 to 7 if you wish to select the picture size or label other

 input

sources.

9

Press the

 button to exit and return to the normal TV screen.

Whenever the equipment with the labelled input is selected for use, the name

appears on the screen for a few seconds.

Picture Adjustment

Select:

Enter Menu:

Picture Mode

  Contrast

  Brightness

  Colour

  Sharpness

     Reset

AI

Noise Reduction

Colour Tone

Personal

On

Off

Normal

Set Up

Auto Tuning

Programme Sorting

Select NexTView

AV Preset

Manual Set Up

Select:

Start Auto Tuning

Start

- - - - - - -

Enter:

Set Up

Auto Tuning

Programme Sorting

Select NexTView

AV Preset

Manual Set Up

Select:

- - - - - - -

AV Preset

Select:

Enter:

INPUT

LABEL

VIDEO

VIDEO

VIDEO

AV1

AV2

AV3

AV4

AUTO FORMAT

Off

Off

Normal

Full

AV Preset

Select A-Z, 0-9:

Confirm: OK

INPUT

LABEL

   IDEO

V

VIDEO

VIDEO

AV1

AV2

AV3

AV4

AUTO FORMAT

Off

Off

Normal

Normal

AV Preset

Select:

Next:    Confirm: OK

INPUT

LABEL

VIDEO

VIDEO

VIDEO

AV1

AV2

AV3

AV4

AUTO FORMAT

Off

Off

Normal

Full
