Sony α6500 ILCE-6500: инструкция

C:\1003CX79700\00COV-ILCE6500CEC\000COV.indd

C:\1003CX79700\00COV-ILCE6500CEC\000COV.indd

2016/10/03 14:21

2016/10/03 14:21

4-690-670-41(1)

“Help Guide” (Web manual)

Refer to “Help Guide” for

in-depth instructions on the

many functions of the camera.

« Manuel d’aide » (Manuel en ligne)

Consultez le « Manuel d’aide » pour

obtenir des instructions détaillées

au sujet des nombreuses fonctions

de l’appareil.

E-mount

http://rd1.sony.net/help/ilc/1640/h_zz/

Interchangeable Lens Digital Camera/Instruction Manual GB

Appareil photo à objectif interchangeable/Mode d’emploi FR

Digitalkamera mit Wechselobjektiv/Gebrauchsanleitung DE

Cámara Digital de Lentes Intercambiables/Manual de instrucciones

ES

Fotocamera digitale con obiettivo intercambiabile/Istruzioni per l’uso

IT

Câmara Digital de Objetivas intercambiáveis/Manual de instruções

PT

Digitale camera met verwisselbare lens/Gebruiksaanwijzing NL

Aparat cyfrowy z wymiennymi obiektywami/Instrukcja obsługi PL

Цифровой фотоаппарат со сменным объективом/Инструкция по эксплуатации

RU

Цифровий фотоапарат зі змінним об’єктивом/Посібник з експлуатації

UA

Digitalkamera med utbytbart objektiv/Handledning SE

Digitaalinen kamera vaihdettavalla objektiivilla/Käyttöopas FI

Digitalkamera med utskiftbart objektiv/Bruksanvisning NO

Digitalkamera med udskifteligt objektiv/Betjeningsvejledning DK

©2016 Sony Corporation Printed in Thailand

ILCE-6500

ILCE-6500

4-690-670-41(1)

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\010BEF.indd

2016/09/30 16:25

English

Check out the

Help Guide!

The “Help Guide” is an on-line manual that you can read on your

computer or smartphone. Refer to it for details on menu items,

advanced usage, and the latest information on the camera.

Scan

here

http://rd1.sony.net/help/ilc/1640/h_zz/

ILCE-6500 Help Guide

Instruction Manual

In-Camera Guide

(this book)

This manual introduces some

The [In-Camera Guide] shows

basic functions.

explanations of the menu

For the quick start guide, see

items on the monitor of the

“Startup guide” (page21). The

camera.

“Startup guide” introduces the

You can quickly pull up

initial procedures from when you

information during shooting.

open the package until you release

To use the [In-Camera Guide]

the shutter for the first shot.

function, some settings must be

made beforehand. For details,

search “In-Camera Guide” in the

Help Guide.

GB

2

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\010BEF.indd

2016/09/30 16:25

Owner’s Record

CAUTION

Record the model and serial number

(which are located on the product)

Battery pack

in the space provided below. Refer

If the battery pack is mishandled, the

to these numbers whenever you

battery pack can burst, cause a fire

call your Sony dealer regarding this

or even chemical burns. Observe the

product.

following cautions.

Model No. ILCE-

• Do not disassemble.

Serial No.

• Do not crush and do not expose the

battery pack to any shock or force

such as hammering, dropping or

WARNING

stepping on it.

To reduce fire or shock hazard,

• Do not short circuit and do not allow

do not expose the unit to rain or

metal objects to come into contact

moisture.

with the battery terminals.

• Do not expose to high temperature

GB

above 60°C (140°F) such as in direct

IMPORTANT SAFETY

sunlight or in a car parked in the sun.

• Do not incinerate or dispose of in fire.

INSTRUCTIONS

• Do not handle damaged or leaking

lithium ion batteries.

-SAVE THESE

• Be sure to charge the battery pack

INSTRUCTIONS

using a genuine Sony battery charger

or a device that can charge the

DANGER

battery pack.

• Keep the battery pack out of the

TO REDUCE THE

reach of small children.

• Keep the battery pack dry.

RISK OF FIRE OR

• Replace only with the same or

equivalent type recommended by

ELECTRIC SHOCK,

Sony.

• Dispose of used battery packs

CAREFULLY

promptly as described in the

instructions.

FOLLOW THESE

• Do not expose to extremely low

temperatures of -20°C (-4°F) or lower

INSTRUCTIONS

or extremely low pressures of 11.6 kPa

If the shape of the plug does not fit

or lower.

the power outlet, use an attachment

plug adaptor of the proper

configuration for the power outlet.

GB

3

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\010BEF.indd

2016/09/30 16:25

Use a nearby wall outlet (wall socket)

Notice

when using the AC Adaptor/battery

If static electricity or

charger. If any malfunction occurs,

electromagnetism causes data

disconnect the plug from the wall

transfer to discontinue midway (fail),

outlet (wall socket) immediately to

restart the application or disconnect

disconnect from the power source.

and connect the communication

If you use the product with a charge

cable (USB, etc.) again.

lamp, note that the product is not

This product has been tested and

disconnected from the power source

found compliant with the limits set

even when the lamp turns off.

out in the EMC regulation for using

The power cord (mains lead), if

connection cables shorter than

supplied, is designed specifically

3meters (9.8feet).

for use with this equipment only,

The electromagnetic fields at the

and should not be used with other

specific frequencies may influence

electrical equipment.

the picture and sound of this unit.

Power Cord

For the customers in the UK, Ireland,

For Customers in the U.S.A. and

Malta, Cyprus and Saudi Arabia

Canada

Use the power cord (A). For safety

reasons, the power cord (B) is not

RECYCLING LITHIUM-ION BATTERIES

intended for above countries/regions

Lithium-Ion batteries

and shall therefore not be used there.

are recyclable.

For the customers in other EU

You can help preserve

countries/regions

our environment by

Use the power cord (B).

returning your used

rechargeable batteries

(A) (B)

to the collection and recycling

location nearest you.

For more information regarding

recycling of rechargeable batteries,

call toll free 1-800-822-8837, or visit

http://www.call2recycle.org/

Caution: Do not handle damaged or

leaking Lithium-Ion batteries.

GB

4

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\010BEF.indd

2016/09/30 16:25

This equipment complies with FCC

For Customers in the U.S.A.

radiation exposure limits set forth

for an uncontrolled environment and

If you have any questions about this

meets the FCC radio frequency (RF)

product, you may call:

Exposure Guidelines. This equipment

Sony Customer Information Center

has very low levels of RF energy that

1-800-222-SONY (7669).

is deemed to comply without testing

The number below is for the FCC

of specific absorption rate(SAR).

related matters only.

The available scientific evidence does

Regulatory Information

not show that any health problems

are associated with using low power

Declaration of Conformity

wireless devices. There is no proof,

Trade Name: SONY

however, that these low power

Model No.: WW213019

wireless devices are absolutely safe.

Responsible Party: Sony Electronics

Low power Wireless devices emit low

Inc.

GB

levels of radio frequency energy (RF)

Address: 16535 Via Esprillo, San

in the microwave range while being

Diego, CA 92127 U.S.A.

used. Whereas high levels of RF can

Telephone No.: 858-942-2230

produce health effects (by heating

This device complies with Part15 of

tissue), exposure of low-level RF that

the FCC Rules. Operation is subject

does not produce heating effects

to the following two conditions: (1)

causes no known adverse health

This device may not cause harmful

effects. Many studies of low-level

interference, and (2) this device

RF exposures have not found any

must accept any interference

biological effects. Some studies

received, including interference

have suggested that some biological

that may cause undesired

effects might occur, but such

operation.

findings have not been confirmed by

additional research. This equipment

This device complies with Part 15 of

has been tested and found to

the FCC Rules. Operation is subject to

comply with IC radiation exposure

the following two conditions:

limits set forth for an uncontrolled

(1) This device may not cause harmful

environment and meets RSS-102 of

interference, and (2) this device must

the IC radio frequency (RF) Exposure

accept any interference received,

rules.

including interference that may cause

undesired operation.

This equipment must not be co-

located or operated in conjunction

with any other antenna or

transmitter.

GB

5

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\010BEF.indd

2016/09/30 16:25

CAUTION

The supplied interface cable must be

You are cautioned that any changes

used with the equipment in order to

or modifications not expressly

comply with the limits for a digital

approved in this manual could

device pursuant to Subpart B of Part

void your authority to operate this

15 of FCC Rules.

equipment.

For Customers in Canada

Note:

This equipment has been tested and

This device complies with Industry

found to comply with the limits for

Canada’s licence-exempt RSSs.

a Class B digital device, pursuant to

Operation is subject to the following

Part 15 of the FCC Rules.

two conditions:

(1) This device may not cause

These limits are designed to provide

interference; and

reasonable protection against

(2) This device must accept any

harmful interference in a residential

interference, including interference

installation. This equipment

that may cause undesired operation

generates, uses, and can radiate

of the device.

radio frequency energy and, if not

installed and used in accordance

CAN ICES-3 B/NMB-3 B

with the instructions, may cause

harmful interference to radio

For Customers in Europe

communications. However, there is

no guarantee that interference will

Manufacturer: Sony Corporation, 1-7-1

not occur in a particular installation.

Konan Minato-ku Tokyo, 108-0075

If this equipment does cause harmful

Japan

interference to radio or television

For EU product compliance: Sony

reception, which can be determined

Belgium, bijkantoor van Sony Europe

by turning the equipment off and

Limited, Da Vincilaan 7-D1, 1935

on, the user is encouraged to try to

Zaventem, Belgium

correct the interference by one or

more of the following measures:

– Reorient or relocate the receiving

antenna.

– Increase the separation between

Hereby, Sony Corporation, declares

the equipment and receiver.

that this equipment is in compliance

– Connect the equipment into an

with the essential requirements and

outlet on a circuit different from

other relevant provisions of Directive

that to which the receiver is

1999/5/EC. For details, please access

connected.

the following URL:

– Consult the dealer or an

http://www.compliance.sony.de/

experienced radio/TV technician

for help.

GB

6

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\010BEF.indd

2016/09/30 16:25

Disposal of waste batteries and

collection point for the recycling of

electrical and electronic equipment

waste batteries.

(applicable in the European Union and

For more detailed information about

other European countries with separate

recycling of this product or battery,

collection systems)

please contact your local Civic Office,

This symbol on the

your household waste disposal

product, the battery

service or the shop where you

or on the packaging

purchased the product or battery.

indicates that the

product and the

For Customers in Singapore

battery shall not

be treated as household waste. On

certain batteries this symbol might be

used in combination with a chemical

symbol. The chemical symbols for

GB

mercury (Hg) or lead (Pb) are added

if the battery contains more than

For Customers in U.A.E.

0.0005% mercury or 0.004% lead.

By ensuring these products and

batteries are disposed of correctly,

you will help prevent potentially

negative consequences for the

environment and human health

which could otherwise be caused by

inappropriate waste handling. The

recycling of the materials will help to

conserve natural resources. In case of

products that for safety, performance

For Customers in Malaysia

or data integrity reasons require

a permanent connection with an

incorporated battery, this battery

should be replaced by qualified

service staff only. To ensure that

the battery and the electrical and

electronic equipment will be treated

properly, hand over these products

For Customers in India

at end-of-life to the applicable

Battery Pack

collection point for the recycling of

electrical and electronic equipment.

For all other batteries, please view

the section on how to remove the

battery from the product safely. Hand

the battery over to the applicable

GB

7

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\010BEF.indd

2016/09/30 16:25

Notes on using your camera

Along with this section, also see

No compensation for damaged

“Precautions” in the Help Guide

content or recording failure

(page2).

Sony can provide no guarantees

in the event of failure to record or

Screen language

loss or damage of recorded images

You can select the language

or audio data due to a malfunction

displayed on the screen using the

of the camera or recording media,

menu (page 41).

etc. We recommend backing up

important data.

Notes on recording/playback

Notes on the monitor, electronic

• Once you format the memory

viewfinder, lens, and image sensor

card, all the data recorded on

• The monitor and electronic

the memory card will be deleted

viewfinder are manufactured

and cannot be restored. Before

using extremely high-precision

formatting, copy the data to a

technology, and over 99.99% of the

computer or other device.

pixels are operational for effective

• Before you start recording, make

use. However, there may be some

a trial recording to make sure that

small black dots and/or bright

the camera is working correctly.

dots (white, red, blue or green in

Notes on handling the product

color) that constantly appear on the

monitor and electronic viewfinder.

• This camera is designed to be dust

These dots are normal due to the

and moisture-resistant, but is not

manufacturing process and do not

waterproof or splash-proof.

affect the images in any way.

• Do not leave the camera, the

• Do not hold the camera by the

supplied accessories, or memory

monitor.

cards within the reach of infants.

• When using the power zoom lens,

They may be accidentally

be careful not to get your fingers

swallowed. If this occurs, consult a

or any other objects caught in the

doctor immediately.

lens.

GB

8

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\010BEF.indd

2016/09/30 16:25

• Do not leave the lens or the

Notes on using lenses and

viewfinder exposed to a strong

accessories

light source such as sunlight.

It is recommended that you use Sony

Because of the lens’s condensing

lenses/accessories designed to suit

function, doing so may cause

the characteristics of this camera.

smoke, fire, or a malfunction inside

Using this camera with products from

the camera body or the lens. If you

other manufacturers may affect its

have to leave the camera exposed

performance, leading to accidents

to a light source such as sunlight,

or malfunction. Sony bears no

attach the lens cap to the lens.

responsibility for such accidents or

• When you shoot with backlighting,

malfunction.

keep the sun sufficiently far away

from the angle of view. Otherwise,

Notes on the Multi Interface Shoe

the sunlight may enter the focus

• When attaching or detaching

inside the camera and cause smoke

accessories such as an external

GB

or fire. Even if the sun is slightly

flash to the Multi Interface Shoe,

away from the angle of view, it may

first turn the power to OFF. When

still cause smoke or fire.

attaching the accessory, confirm

• Do not directly expose the lens to

that it is firmly fastened to the

beams such as laser beams. That

camera.

may damage the image sensor and

• Do not use the Multi Interface Shoe

cause the camera to malfunction.

with a commercially available flash

• Do not look at sunlight or a strong

that applies voltages of 250 V or

light source through the lens when

more or has the opposite polarity

it is detached. This may result in

of the camera. It may cause a

unrecoverable damage to the eyes

malfunction.

or cause a malfunction.

• Do not use the camera in areas

Notes on shooting with the

where strong radio waves or

viewfinder

radiation are being emitted.

• The image may be slightly distorted

Recording and playback may not

near the corners of the viewfinder.

function correctly.

This is not a malfunction. When you

• Images may trail across on the

want to see the full composition

screen in a cold location. This is not

with all its details, you can also use

a malfunction.

the monitor.

• The recorded image may be

different from the image you

monitored before recording.

GB

9

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\020PRE.indd

2016/09/30 16:25



Monitor (For touch operation:



For shooting: AF/MF

Touch panel/Touch pad)

button/AEL button

You can adjust the monitor to

For viewing:

(Enlarge)

an easily viewable angle and

button

shoot from any position.



MOVIE (Movie) button



For shooting: Fn (Function)

button

For viewing:

(Send to Smartphone)

button

You can display the screen

for [Send to Smartphone] by

You may not be able to adjust

pressing this button.

the monitor angle depending



Control wheel

on the type of a tripod you

use. In such a case, release the



Center button

tripod screw once to adjust the



For shooting: C3 button

monitor angle.

(Custom button 3)

For viewing:

(Delete) button



Diopter-adjustment dial

Adjust the diopter-adjustment



(Playback) button

dial according to your eyesight

until the display appears

clearly in the viewfinder. If it is

hard to operate the diopter-

adjustment dial, remove the

eyepiece cup before operating

the dial.



(Flash pop-up) button



MENU button



(N mark)



AF/MF/AEL switch lever

This mark indicates the touch

point for connecting the

camera and an NFC-enabled

Smartphone.

GB

16

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\020PRE.indd

2016/09/30 16:25



Battery/memory card cover



Memory card slot



Battery lock lever



Battery insertion slot

• NFC (Near Field

Communication) is an

international standard of

the short-range wireless

communication technology.



Connection plate cover

GB

Use this when using an

AC-PW20 AC Adaptor

(sold separately). Insert the

connection plate into the

battery compartment, and

then pass the cord through

the connection plate cover as

shown below.

Make sure that the cord is not

pinched when you close the

cover.



Tripod socket hole

Use a tripod with a screw less

than 5.5 mm (7/32 inches)

long. Otherwise, you cannot

firmly secure the camera, and

damage to the camera may

occur.



Access lamp

GB

17

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\020PRE.indd

2016/09/30 16:25

Basic operations

Using the control wheel

• You can select setting items by turning or pressing the top/bottom/

left/right side of the control wheel. Your selection is determined when

you press the center of the control wheel.

• The default settings for the top/bottom/left/right side and the center

of the control wheel are as follows.

Top side: DISP (Display Setting)

Bottom side: Exposure Comp./Image Index (

/ )

Left side: Drive Mode (

)

Right side: ISO

Center: Eye AF

You can also assign the desired functions to the bottom/left/right side

or the center of the control wheel.

• During playback, you can display the next/previous image by pressing

the right/left side of the control wheel or by turning the control wheel.

GB

18

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\020PRE.indd

2016/09/30 16:25

Using the Fn (Function) button

You can register frequently used functions to the Fn (Function) button

and recall them while shooting. Up to 12 frequently used functions can be

registered to the Fn (Function) button.

1

Press the DISP button

repeatedly to display a

screen mode other than

[For viewfinder], and then

press the Fn (Function) button.

GB

Fn

2

Select the desired function by pressing the top/bottom/left/

right side of the control wheel.

3

Select the desired setting by

turning the control wheel, and

press the center of the control

wheel.

• Some functions can be fine-

tuned using the control dial.

To adjust settings from the dedicated setting screens

Select the desired function in step 2,

then press the center of the control

wheel. The dedicated setting screen

for the function will appear. Follow the

operating guide to adjust settings.

Operation guide

GB

19

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\020PRE.indd

2016/09/30 16:25

Using the AF/MF/AEL switch lever

You can switch the function of the

AF/MF/AEL button to AF/MF or AEL by

changing the position of the AF/MF/AEL

switch lever.

When you move the AF/MF/AEL

switch lever to the AF/MF position and

press the button, the focusing mode

AF/MF button/

temporarily switches between auto

AEL button

and manual (AF/MF control). When you

AF/MF/AEL switch lever

move the AF/MF/AEL switch lever to the

AEL position and press the button, the

exposure is locked (AE lock).

GB

20

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\020PRE.indd

2016/09/30 16:25

Startup guide

Step 1: Inserting the battery pack/memory card into the

camera

For details on memory cards that can be used with this camera, refer to

page 44.

1

Open the battery/memory

card cover.

GB

2

Insert the battery pack while

Lock lever

pressing the lock lever with

the tip of the battery until the

battery locks into place.

3

Insert the memory card.

• With the notched corner facing

in the direction illustrated, insert

the memory card until it clicks

into place. Otherwise, it may

cause a malfunction.

4

Close the cover.

GB

21

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\020PRE.indd

2016/09/30 16:25

Hint

• When you use a memory card with the camera for the first time, it is

recommended that you format the card on the camera for more stable

performance of the memory card (page 42).

To remove the battery pack

Make sure that the access lamp

Lock lever

(page 17) is not lit, and turn off

the camera. Then, slide the lock

lever and remove the battery pack.

Be careful not to drop the battery

pack.

To remove the memory card

Make sure that the access lamp

(page 17) is not lit, and then

push in the memory card once to

remove it.

GB

22

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\020PRE.indd

2016/09/30 16:25

Step 2: Charging the battery pack while it is inserted in

the camera

1

Turn the power off.

2

Connect the camera

with the battery pack

inserted to the AC Adaptor

(supplied) using the micro

USB cable (supplied), and

connect the AC Adaptor

GB

to the wall outlet (wall

socket).

Charge lamp on the camera (orange)

Lit: Charging

Off: Charging finished

Flashing: Charging error or charging paused temporarily because the

camera is not within the proper temperature range

• Charging time (full charge): approximately 150 min (when charging a

fully depleted battery pack at a temperature of 25°C (77°F))

• When you use a completely new battery pack or a battery pack that

has not been used for a long time, the charge lamp may flash quickly

when the battery is charged. If this happens, remove the battery pack

or disconnect the USB cable from the camera and then re-insert it to

recharge.

• Be sure to use only genuine Sony brand battery packs, micro USB

cables (supplied) and AC Adaptors (supplied).

GB

23

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\020PRE.indd

2016/09/30 16:25

Step 3: Attaching a lens

1

Remove the body cap from the

camera and the rear lens cap

from the rear of the lens.

• When changing the lens,

work quickly in a dust-free

environment to keep dust or

debris from getting inside the

Body cap

camera.

Rear lens cap

2

Mount the lens by aligning

the two white index marks

(mounting indexes) on the

lens and camera.

• Hold the camera with the lens

facing down to prevent dust

or debris from entering the

camera.

3

While pushing the lens lightly

toward the camera, turn the

lens slowly in the direction of

the arrow until it clicks into

the locked position.

GB

24

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\020PRE.indd

2016/09/30 16:25

Note

• Be sure to hold the lens straight and do not use force when attaching a lens.

• Do not press the lens release button when attaching a lens.

• The Mount Adaptor (sold separately) is required to use an A-mount lens

(sold separately). For details, refer to the operating manual supplied with the

Mount Adaptor.

• When carrying the camera with a lens attached, hold both the camera and

the lens firmly.

• Do not hold the part of the lens that is extended for zoom or focus

adjustment.

To remove the lens

Keep pressing the lens release

button and turn the lens in the

GB

direction of the arrow until it stops.

Lens release button

GB

25

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\100MEN.indd

2016/09/30 16:25

List of MENU items

For details on each MENU items, refer to the Help Guide.

(Camera Settings1)

Red tab

Quality/Image Size

Quality

Sets the image quality for still images.

([RAW]/ [Fine], etc.)

Image Size

Selects the size of still images.

(L/ M/ S)

Aspect Ratio

Selects the aspect ratio for still images.

Panorama: Size

Selects the size of panoramic images.

Panorama: Direction

Sets the shooting direction for panoramic images.

Long Exposure NR

Sets noise reduction processing for shots with a

shutter speed of 1 second or longer.

High ISO NR

Sets noise reduction processing for high-sensitivity

shooting.

Color Space

Changes the color space (range of reproducible

colors).

Lens Comp.

Selects the type of lens compensation.

Shoot Mode/Drive

Auto Mode

You can shoot selecting either Intelligent Auto or

Superior Auto.

Scene Selection

Selects pre-set settings to match various scene

conditions.

([Portrait]/ [Sports Action], etc.)

S. Auto Img. Extract.

When the shooting mode is set to [Superior Auto]

and the camera recognizes the scene to be shot

with multiple images, this sets whether to extract an

image automatically and save it.

Drive Mode

Sets the drive mode, such as for continuous

shooting.

([Self-timer]/ [Cont. Bracket], etc.)

GB

32

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\100MEN.indd

2016/09/30 16:25

Bracket Settings

Sets self-timer shooting in bracket mode, shooting

order for exposure bracketing, and white balance

bracketing.

/ Recall

Calls up settings pre-registered to

[

/ Memory].

/ Memory

Registers the desired modes and camera settings.

AF

Focus Mode

Selects the focus mode.

([Single-shot AF]/ [Continuous AF], etc.)

Priority Set in AF-S

Sets the timing of the shutter release when

[Focus Mode] is set to [Single-shot AF], [DMF] or

[Automatic AF] with a still subject.

Priority Set in AF-C

Sets the timing of the shutter release when

GB

[Focus Mode] is set to [Continuous AF] or

[Automatic AF] with a moving subject.

Focus Area

Selects the area of focus.

([Wide]/ [Flexible Spot], etc.)

AF Illuminator

Sets the AF illuminator, which provides light to aid

focusing in dark scenes.

Center Lock-on AF

Sets the function to track a subject and continue

focusing when pressing the center of control wheel

in the shooting screen.

AF System

Sets the auto focus method when an LA-EA1/LA-EA3

Mount Adaptor (sold separately) is attached.

AF w/ shutter

Sets whether to perform auto focusing when the

shutter button is pressed halfway down. This is

useful when you want to adjust the focus and

exposure separately.

Pre-AF

Sets whether or not to perform auto focus before

the shutter button is half pressed.

Eye-Start AF

Sets whether to use auto focus when you look

through the viewfinder if an LA-EA2/LA-EA4 Mount

Adaptor (sold separately) is attached.

AF Area Auto Clear

Sets whether the focus area is displayed all the time

or disappears automatically shortly after focusing.

Disp. cont. AF area

Sets whether or not to display the focus area in

[Continuous AF] mode.

GB

33

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\100MEN.indd

2016/09/30 16:25

AF Micro Adj.

Finely adjusts the autofocused position, when

using the LA-EA2 or LA-EA4 Mount Adaptor

(sold separately).

Exposure

Exposure Comp.

Compensates for the brightness of the entire image.

ISO

Sets the ISO sensitivity.

([ISO AUTO], etc.)

ISO AUTO Min. SS

Sets the slowest shutter speed at which ISO

sensitivity will start to change in [ISO AUTO] mode.

Metering Mode

Selects the method for measuring brightness.

([Multi]/ [Spot], etc.)

Spot Metering Point

Sets whether to coordinate the spot metering point

with the focus area when [Focus Area] is set to

[Flexible Spot] or [Expand Flexible Spot].

Exposure step

Selects the size of the increment step for shutter

speed, aperture, and exposure compensation.

AEL w/ shutter

Sets whether to lock the exposure when the shutter

button is pressed halfway down. This is useful

when you want to adjust the focus and exposure

separately.

Exposure Std. Adjust

Adjusts the standard for the correct exposure value

for each metering modes.

Flash

Flash Mode

Sets the flash settings.

Flash Comp.

Adjusts the intensity of flash output.

Exp.comp.set

Sets whether to reflect exposure compensation

value to flash compensation.

Red Eye Reduction

Reduces the red-eye phenomenon when using

flash.

Color/WB/Img. Processing

White Balance

Corrects the tone effect of the ambient light to shoot

whitish objects in a white tone.

([Auto]/ [Daylight], etc.)

Priority Set in AWB

Selects which tone to prioritize when shooting under

lighting conditions such as incandescent light with

[White Balance] set to [Auto].

GB

34

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\100MEN.indd

2016/09/30 16:25

DRO/Auto HDR

Analyzes the contrast of light and shadow between

the subject and the background by dividing the

image into small areas, and creates an image with

the optimal brightness and gradation.

Creative Style

Selects the desired image processing.

You can also adjust contrast, saturation, and

sharpness.

([Vivid]/ [Portrait], etc.)

Picture Effect

Shoots images with a texture unique to the selected

effect.

([Toy Camera]/ [Rich-tone Mono.], etc.)

Picture Profile

Changes settings such as color and tone when

recording images.

* This function is for skilled movie creators.

GB

Soft Skin Effect

Sets the Soft Skin Effect and the effect level.

Focus Assist

Focus Magnifier

Enlarges the image before shooting so that you can

check the focus.

Focus Magnif. Time

Sets the length of time the image will be shown in

an enlarged form.

AF in Focus Mag.

Sets whether or not to autofocus when an enlarged

image is being displayed. While the enlarged image

is being displayed, you can focus within a smaller

area than the flexible spot.

MF Assist

Displays an enlarged image when focusing

manually.

Peaking Level

Enhances the outline of in-focus areas with a

specific color when focusing manually.

Peaking Color

Sets the color used for the peaking function.

Face Detection/Shoot Assist

Smile/Face Detect.

Selects to detect faces and adjust various settings

automatically. Sets to automatically release the

shutter when a smile is detected.

([Off]/ [On (Regist. Faces)]/ [On]/ [Smile Shutter])

Face Registration

Registers or changes the person to be given priority

when focusing.

GB

35

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\100MEN.indd

2016/09/30 16:25

Auto Obj. Framing

Analyzes the scene when capturing faces, close-ups,

or subjects tracked by the Lock-on AF function, and

automatically trims and saves another copy of the

image with a more impressive composition.

(Camera Settings2)

Purple tab

Movie

Movie/S&Q Motion

Sets the exposure mode when shooting movies

or slow-motion/quick-motion movies.

File Format

Selects the movie file format.

([XAVC S 4K]/ [AVCHD], etc.)

Record Setting

Selects the bit rate and frame rate for the

movie size.

S&Q Settings

Changes the settings for slow-motion and

quick-motion movie shooting.

Dual Video REC

Sets whether to simultaneously record an

XAVC S movie and MP4 movie or an AVCHD

movie and MP4 movie.

AF drive speed

Switches focusing speed when using autofocus

in movie mode.

AF Track Sens

Sets the AF tracking sensitivity for the movie

mode.

Auto Slow Shut.

Sets the function that automatically adjusts the

shutter speed following the brightness of the

environment in movie mode.

Audio Recording

Sets whether to record audio when shooting

a movie.

Audio Rec Level

Adjusts the audio recording level during movie

recording.

Audio Level Display

Sets whether to display the audio level.

Wind Noise Reduct.

Reduces wind noise during movie recording.

Marker Display

Sets whether to display markers on the monitor

when recording movies.

GB

36

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\100MEN.indd

2016/09/30 16:25

Marker Settings

Sets which markers to displayed on the monitor

when recording movies.

Shutter/SteadyShot

Silent Shooting

Shoots images without a shutter sound.

e-Front Curtain Shut.

Sets whether to use the electronic front curtain

shutter function.

Release w/o Lens

Sets whether to release the shutter when the

lens is not attached.

Release w/o Card

Sets whether to release the shutter when a

memory card is not inserted.

SteadyShot

Sets whether to activate SteadyShot for

shooting.

SteadyShot Settings

Sets SteadyShot settings.

GB

Zoom

Zoom

Sets the zoom scale for zoom functions other

than the optical zoom.

Zoom Setting

Sets whether to use the Clear Image Zoom and

Digital Zoom when zooming.

Zoom Ring Rotate

Assigns the zoom in/out to the rotational

direction of the zoom lens. This function is

only available with a power zoom lens that is

compatible with this function.

Display/Auto Review

DISP Button

Sets the type of information to be displayed on

the monitor or in the viewfinder when the DISP

button is pressed.

FINDER/MONITOR

Sets the method for switching the display

between the electronic viewfinder and the

monitor.

Finder Frame Rate

Sets the frame rate for the viewfinder when

shooting still images.

Zebra

Displays stripes to adjust brightness.

Grid Line

Displays grid lines for adjusting the image

composition.

Exposure Set. Guide

Sets the guide displayed when exposure

settings are changed in the shooting screen.

GB

37

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\100MEN.indd

2016/09/30 16:25

Live View Display

Sets whether to reflect settings such as

exposure compensation in screen display.

Auto Review

Sets auto review to display the captured image

after shooting.

Custom Operation

Custom Key(Shoot.)

Assigns functions to the various keys so that

you can perform operations more quickly by

pressing the keys when shooting images.

Custom Key(PB)

Assigns functions to the keys so that you can

perform operations more quickly by pressing

the keys when playing back images.

Function Menu Set.

Customizes the functions displayed when the

Fn (Function) button is pressed.

Dial/Wheel Setup

Sets the function of the control dial and the

control wheel when the exposure mode is

set to M. You can adjust the shutter speed or

aperture with this setting.

Dial/Wheel Ev Comp

Adjusts the exposure compensation with the

control dial or the control wheel.

MOVIE Button

Enables or disables for the MOVIE button.

Dial/Wheel Lock

Sets whether to disable the control dial and

the control wheel temporarily by using the Fn

button when shooting. You can disable/enable

the control dial and the control wheel by

pressing and holding down the Fn button.

Audio signals

Selects whether to sound a beep during auto

focus or self-timer operations.

(Wireless)

Green tab

Send to Smartphone

Transfers images to display on a smartphone.

Send to Computer

Backs up images by transferring them to a

computer connected to a network.

View on TV

Allows you to view images on a network-

enabled TV.

GB

38

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\100MEN.indd

2016/09/30 16:25

One-touch(NFC)

Assigns an application to One-touch (NFC). You

can call up the application when shooting by

touching an NFC-enabled smartphone to the

camera.

Airplane Mode

Disables wireless communications from the

device such as Wi-Fi, NFC, and Bluetooth

function.

Wi-Fi Settings

Allows you to register your access point

and check or change the Wi-Fi connection

information.

Bluetooth Settings

Controls the settings for connecting the camera

with a smartphone via a Bluetooth connection.

Loc. Info. Link Set.

Obtains location information from the paired

GB

smartphone and records it to captured images.

Edit Device Name

Changes the device name under Wi-Fi Direct,

etc.

Reset Network Set.

Resets all the network settings.

(Application)

Light Green tab

Application List

Displays the application list. You can select the

application you want to use.

Introduction

Displays instructions on using the application.

(Playback)

Blue tab

Delete

Deletes an image.

View Mode

Plays back images from a specified date or

specified folder of still images and movies.

Image Index

Displays multiple images at the same time.

Display Rotation

Sets the playback orientation for images shot

vertically.

Slide Show

Plays a slide show.

GB

39

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\100MEN.indd

2016/09/30 16:25

Rotate

Rotates the image.

Enlarge Image

Enlarges the playback images.

Protect

Protects recorded images against accidental

erasure.

Specify Printing

Specifies in advance on the memory card which

still images to print out later.

Photo Capture

Captures a chosen scene in a movie to save as

a still image.

(Setup)

Yellow tab

Monitor Brightness

Adjusts the brightness of the screen.

Viewfinder Bright.

Sets the brightness of the electronic viewfinder.

Finder Color Temp.

Sets the color temperature of the viewfinder.

Gamma Disp. Assist

Converts an S-Log image into an image with

contrast equivalent to a normal gamma setting

when it is displayed to assist monitoring.

Volume Settings

Sets the volume for movie playback.

Upload Settings

Sets the upload function of the camera when

using a commercially available Eye-Fi card.

Tile Menu

Sets whether to display the tile menu every

time you press the MENU button.

Mode Dial Guide

Turns the mode dial guide (the explanation of

each shooting mode) on or off.

Delete confirm.

Sets whether [Delete] or [Cancel] is preselected

in the delete confirmation screen.

Display Quality

Sets the display quality.

Pwr Save Start Time

Sets the time intervals to automatically switch

to power save mode.

Auto Pwr OFF Temp.

Sets the camera temperature at which the

camera turns off automatically during shooting.

When shooting in hand-held mode, set to

[Standard].

GB

40

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\100MEN.indd

2016/09/30 16:25

NTSC/PAL Selector

*1

Changes the TV format of the device so that

you can shoot in a different movie format.

Cleaning Mode

Starts the cleaning mode to clean the image

sensor.

Touch Operation

Sets whether or not to activate the touch

operation of the monitor.

Touch Pad (vertical)

Sets whether to operate the camera using the

touch pad when you use the viewfinder in the

vertical position.

Touch Pad Area Set.

Sets the area to be used in the touch

pad operation at the time of shooting by

viewfinder.

Demo Mode

Sets demonstration playback of movies to on

GB

or off.

TC/UB Settings

Sets the time code (TC) and user bit (UB).

* This function is for skilled movie creators.

Remote Ctrl

Sets whether to use the infrared remote

control.

HDMI Settings

Sets the HDMI settings.

4K Output Sel.

Sets how to record and output 4K movies via

HDMI when the camera is connected to an

external recorder/player that supports 4K.

USB Connection

Sets the USB connection method.

USB LUN Setting

Enhances compatibility by limiting the

functions of USB connection. Set to [Multi]

in normal conditions and to [Single] only

when the connection between the camera

and a computer or AV component cannot be

established.

USB Power Supply

Sets whether to supply power via USB

connection when the camera is connected to

a computer or USB device using a micro USB

cable. If you use the supplied AC Adaptor,

power will be supplied regardless of whether

this setting is on or off.

PC Remote Settings

Controls the PC remote shooting settings.

Language

Selects the language.

GB

41

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\120OTH.indd

2016/09/30 16:25

File Format Record Setting 8 GB 16 GB 32 GB 64 GB

MP4

1920×1080

60p 28M

/

35m 1h 15m 2h 35m 5h 20m

50p 28M

1920×1080

30p 16M

/

1h 2h 4h 10m 8h 25m

25p 16M

1280×720

30p 6M

/

2h 35m 5h 20m 10h 55m 22h

25p 6M

* Only when [NTSC/PAL Selector] is set to NTSC

• Continuous shooting is possible for approximately 29 minutes (a

product specification limit). The continuous recordable time may differ

in the following situations:

– When the file format is set to MP4 (28M): Approximately 20 minutes

(limited by file size of 4 GB).

– When shooting slow-motion/quick-motion movies: Recording will

automatically stop when the recorded file reaches approximately

29minutes (the played back movie reaches approximately 29

minutes).

(Recording will automatically stop when the recorded file reaches

approximately 15 minutes if [

Record Setting] is set to [60p/50p]

and [

Frame Rate] is set to [30fps/25fps].)

• The times for slow-motion/quick-motion movies are playback times,

not recording times.

Note

• The recordable time of movies varies because the camera is equipped with

VBR (Variable Bit-Rate), which automatically adjusts image quality depending

on the shooting scene. When you record a fast-moving subject, the image is

clearer but the recordable time is shorter because more memory is required

for recording. The recordable time also varies depending on the shooting

conditions, the subject or the image quality/size settings.

• The times shown are recordable times using a Sony memory card.

GB

48

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\120OTH.indd

2016/09/30 16:25

Notes on continuous movie recording

• It requires a lot of power to perform high quality movie recording

or continuous shooting. Therefore, if you continue to shoot, the

temperature inside the camera will rise, especially that of the image

sensor. In such cases, the camera will turn off automatically because

the surface of the camera is heated to a high temperature that can

affect the quality of the images or the internal mechanism of the

camera.

• The following values are the continuous times from when the camera

starts recording until the camera stops recording.

Ambient

Continuous recording time for

Continuous recording time for

temperature

movies (HD)

movies (4K)

20°C (68°F)

Approx. 29min. Approx. 20min.

GB

30°C (86°F)

Approx. 29min. Approx. 20min.

40°C (104°F)

Approx. 29min. Approx. 20min.

[Auto Pwr OFF Temp.]: [Standard]

HD: XAVC S HD (60p 50M/50p 50M, not connected via Wi-Fi)

4K: XAVC S 4K (24p 60M, not connected via Wi-Fi)

• The duration of time available for movie recording varies with the

temperature, file format/record setting for movies, Wi-Fi network

environment, or condition of the camera before you start recording. If

you frequently recompose or shoot images after the power is turned

on, the temperature inside the camera will rise and the recording time

available will be shorter.

• When the

icon appears, the temperature of the camera is too high.

• If the camera stops recording due to the temperature, leave it for some

time with the power turned off. Start recording after the temperature

inside the camera drops fully.

• If you observe the following points, the recording time will be longer.

– Keep the camera out of direct sunlight.

– Turn the camera off when it is not being used.

• When [

File Format] is set to [AVCHD], the file size of movies is

limited to approx. 2GB. If the movie file size reaches approx. 2GB

during recording, a new movie file will be created automatically.

• When [

File Format] is set to [MP4], the file size of movies is limited

to approx. 4GB. If the movie file size reaches approx. 4GB during

recording, recording will stop automatically.

GB

49

ILCE-6500

4-690-670-41(1)

C:\4690670411ILCE6500CEC\01GB-ILCE6500CEC\120OTH.indd

2016/09/30 16:25

Specifications

Metering range

Camera

EV–2 to EV20 (at ISO100 equivalent,
