Sony SU-FL61: Install the TV 1

7

(GB)

Install the TV 1

Prepare for the installation of the

TV.

Detach the Table-Top Stand (if attached) and remove

the two screws from the rear of the TV. For details,

refer to the leaflet supplied with the TV.

2

Attach the four hooks on the rear

of the TV.

Place the TV with its screen facing down on a stable

cloth-covered work surface.

Attach the four hooks with the four hook screws.

• When using an electric screwdriver, set the torque setting

to approximately 2 N·m {20 Kgf·cm}.

• Be sure not to use any screws other than the supplied ones

(+PSW5 × L16) when attaching the hooks.

Soft cloth

Align the hook with the circle on the

rear of the TV.

Hook screw

Hook

Notes

3

Attach the TV to the TV Stand.

1

Hold the TV as illustrated below, and insert the four

hooks on the rear of the TV into the top portion of

the holes of the center pillar. Check that all four

hooks are firmly secured in the four holes.

Be careful not to topple the TV Stand when attaching the TV

to the TV Stand.

2

Push the TV straight down to securely seat the

hooks into the TV Stand as shown.

• Confirm the hooks are firmly seated into the bottom of the

holes, then check that the TV hangs parallel level.

• Be careful not to move the TV Stand while attaching the

TV.

Note

Notes
