Sony SU-FL61: Assemble the TV Stand

6

(GB)

Assemble the TV Stand

If you allow the AC power cord to be pinched under or

between pieces of equipment, this may result in a short

circuit or an electric shock. If you stumble over the AC

power cord or the connecting cable, the TV Stand may

topple over and cause injury.

Decide on the installation location and lay the TV

Stand down before installing the TV.

Since the TV is heavy, it is recommended that you decide

on the installation location and lay the TV Stand down

before installing the TV.

1

Detach the front and rear pillar

support panels from the center

pillar.

WARNING

Rear pillar

support panel

Front pillar

support panel

2

Attach the center pillar to the

frame.

Secure the center pillar to the frame with the four

screws.

• Be sure that two or more persons assemble the TV Stand.

• Loosely attach the center pillar to the frame with the four

screws, then tighten all screws sufficiently.

• When using an electric screwdriver, set the torque setting

to approximately 1.5 N·m {15 Kgf·cm}.

3

As shown below, attach the front

pillar support panel.

Before attaching the front pillar support panel, check that the

four screws are firmly tightened.

Screw

Frame

Notes

Note
