Replacing the Lamp

When the lamp becomes dark or the picture colour is

not normal or the lamp indicator   on the set flashes,

replace with a new lamp.

• Use the lamp XL-2000E for replacement. If you use

another lamp, it may cause damage to the set.

• Do not remove the lamp except when replacing it.

• Before replacing the lamp, turn off the power and

disconnect the power cord.

• Replace the lamp after it becomes cool.  The front

glass of the lamp remains 100 °C (212 °F) and more

even 30 minutes after the power is turned off.

• Do not place the removed lamp in proximity to

children or flammable material.

• Do not get the removed lamp wet, or insert objects

inside the lamp.  It may cause the lamp to explode.

• Do not place near metal or easily flammable objects,

as this may cause fire.  Also, do not put your hand

inside the lamp compartment, as you may be burned.

• Attach the new lamp firmly.  If it is not firmly

attached,  the picture may become dark.

1

Turn off the power and disconnect the power cord.

• If you start changing the lamp without disconnecting

the power cord, the standby indicator

on the set

flashes. To continue changing the lamp, disconnect the

power cord.

• Replace the lamp 30 minutes or more after the power

is turned off.

 Prepare the new lamp.

2

Remove the front panel

.

Remove the front panel without moving the set.

Grasping the right side of the front panel with your

fingers, pull it forward.  Be careful not to catch your

fingernails.

3

Loosen the screw with the object such as a coin and

remove the lamp cover.

4

Loosen two screws and pull out the lamp.

Loosen two screws with the supplied wrench.

Pull out the lamp by the handle.

The lamp is still too hot just after the power is turned

off.  Be careful that you don’t touch the front glass or

surrounding area of the lamp or the glass of the lamp

compartment.

5

Attach the new lamp.

Replace the new lamp securely in the lamp receptacle and

fasten the screws tightly.

6

Attach the lamp cover.

Fasten the screw tightly with the object such as a coin.

7

Attach the front panel.

Attach the front panel as it was.

Notes

•

Do not touch or stain the front glass of the new lamp or the glass

of the lamp compartment.  If the glass become dirty, the picture

quality may deteriorate or the lamp life may shorten.

•

Attach the lamp cover firmly.  If it is not firmly attached, the

power will not turn on.

•

When the lamp burns out, a noise is audible.  This does not

represent a damage.

•

Consult your nearest Sony service center to obtain a new lamp.

•

Always remember to dispose of used lamps in an evironmental

friendly way.
