Connecting to a Macintosh or compatible

computer

Setup

Before using your monitor, check that the following accessories

are included in your carton:

• Power cord (1)

• Warranty card (1)

• Notes on cleaning the screen’s surface (1)

• This instruction manual (1)

Step 1:Connect your monitor to

your computer

Turn off the monitor and computer before connecting.

Note

Do not touch the pins of the video cable connector as this might bend the

pins.

x

Connecting to an IBM PC/AT or compatible

computer

AC IN

Step 2:Connect the power cord

With the monitor and computer switched off, first connect the

power cord to the monitor, then connect it to a power outlet.

to video output

IBM PC/AT or

compatible computer

6

Step 3:Turn on the monitor and

Selecting the on-screen menu

computer

language (LANGUAGE/

INFORMATION)

First turn on the monitor, then turn on the computer.

English, French, German, Italian, Spanish, Dutch, Swedish,

Russian and Japanese versions of the on-screen menus are

available. The default setting is English.

1

Press the center of the control button.

The installation of your monitor is complete.

See page 9 for more information on using the control button.

If necessary, use the monitor’s controls to adjust the picture.

MENU

MENU

If no picture appears on your screen

EXI T

SIZE/CENTER

• Check that the monitor is correctly connected to the computer.

GEOMETRY

SCREEN

• If NO INPUT SIGNAL appears on the screen, confirm that

COLOR

your computer’s graphic board is completely seated in the

LANGUAGE / INFORMAT NOI

correct bus slot.

SELECT

• If you are replacing an old monitor with this model and OUT

OF SCAN RANGE appears on the screen, reconnect the old

monitor. Then adjust the computer’s graphic board so that the

2

Move the control button

m

/

M

to highlight

horizontal frequency is between 30 – 85 kHz, and the vertical

LANGUAGE/INFORMATION and press the center

frequency is between 48 – 120 Hz.

of the control button again.

For more information about the on-screen messages, see “Trouble

MENU

LANGUAGE / I NFOR

M

A

T

I

O

N

symptoms and remedies” on page 13.

ENGL ISH FRANÇAI S

DEUTSCH I TAL I ANO

GB

ESPAÑOL NEDERLAN SD

Setup on various OS (Operating System)

SVENSKA

This monitor complies with the “DDC” Plug & Play standard and

SELECT EXI T

automatically detects all the monitor’s information. No specific driver

needs to be installed to the computer.

If you connect the monitor to your PC, and then boot your PC for the first

3

Move the control button

m

/

M

to select .

time, the setup Wizard may be displayed on the screen. Click on “Next”

Then move the control button

<

/

,

to select a

several times according to the instructions from the Wizard until the Plug

language.

& Play Monitor is automatically selected so that you can use this monitor.

• ENGLISH

• FRANÇAIS: French

For customers using Windows NT4.0

• DEUTSCH: German

Monitor setup in Windows NT4.0 does not use the display driver. Refer

• ITALIANO: Italian

to the Windows NT4.0 instruction manual for further details on adjusting

• ESPAÑOL: Spanish

the resolution, refresh rate, and number of colors.

• NEDERLANDS: Dutch

• SVENSKA: Swedish

• : Russian

• : Japanese

To close the menu

Press the center of the control button once to return to the main MENU,

and twice to return to normal viewing. If no buttons are pressed, the menu

closes automatically after about 30 seconds.

To reset to English

Press the RESET button while the LANGUAGE/INFORMATION menu

is displayed on the screen.
