Sony MZ-B100: Preparing a power source
Preparing a power source: Sony MZ-B100
Preparing a power source
This section explains how to prepare the recorder for battery-powered
operation. For information on connecting the recorder to an AC power
outlet, see page 43.
1
Insert dry batteries.
2
Unlock the control.
9-GB
E
e
Back of the recorder
Press and slide the battery
Insert one LR6 (size AA)
Close the lid.
compartment lid as shown in
alkaline dry battery
the illustration.
(supplied with the world
model only).
Notes
• Do not use manganese dry battery. If you do, recording may not be possible.
• Insert the e and E poles of the battery correctly as shown on the recorder.
HOLD
HOLD
Slide HOLD to the direction of the arrow in the illustration.
Charging the built-in battery for the clock
When you use the recorder for the first time or after a long period of disuse, charge the
built-in battery for the clock. After setting the clock, leave the dry batteries installed for
about more than two hours so that the built-in battery is automatically charged. You can use
the recorder while charging. When the built-in battery is charged, the settings, such as
clock, will remain for about one month after dry batteries are taken out. For details on
setting a clock, see page 25.
10-GB
