Sony Bravia KDL-32D3010: Set-up menu

Set-up menu: Sony Bravia KDL-32D3010

Set-up menu

You can select the options listed below on the “Set-

up” menu. To select options in “Settings”, refer to

“Navigating through menus” (page 20).

Auto Start-up

Starts the initial set-up to select the language and country/region, and tune in all

available digital and analogue channels.

Usually, you do not need to do this operation because the language and country/

region will have been selected and channels already tuned when the TV was first

installed (page 5).

However, this option allows you to repeat the process (e.g. to retune the TV after

moving house, or to search for new channels that have been launched by

broadcasters).

Language

Selects the language in which the menus are displayed.

Motion Enhancer

Provides smoother picture movement and reduces picture blur.

“High”: Provides smoother picture movement such as for film-based contents.

“Standard”: Provides smooth picture movement. Use this setting for standard use.

“Off”: Use this setting when the “High” and “Standard” settings result in noise.

~

• Depending on the video, you may not see the effect visually, even if you have changed the

setting.

• When you select Theatre Mode, “Motion Enhancer” is set to “Off” by default.

Film Mode

Provides smoother picture movement when playing DVD or VCR images taken on

film, reducing picture blur and graininess.

“Auto 1”: Provides smoother picture movement than the original film-based

content. Use this setting for standard use.

“Auto 2”: Provides the original film-based content as is.

“Off”: Turns off the “Film Mode” feature.

~

If the image contains irregular signals or too much noise, “Film Mode” will be automatically

turned off even if “Auto 1” or “Auto 2” is selected.

Game Mode

Depending on the game software, select “On” when reaction time is important.

GB

26

AV Set-up

AV Preset

Assigns a name to any equipment connected to the side and rear sockets. The name

will be displayed briefly on the screen when the equipment is selected. You can skip

input signals from connected equipment that you do not want displayed on the

screen.

1 Press F/f to select the desired input source, then press .

2 Press

F/f to select the desired option below, then press .

Equipment labels: Uses one of the preset labels to assign a name to connected

equipment.

“Edit:”: Creates your own label. Follow steps 2 to 4 of “Programme Labels”

(page 31).

“Skip”: Skips an unnecessary input source.

Auto S Video

Selects the input signal from S video sockets 6 when / 6 sockets are both

connected.

AV2 Output

Sets a signal to be output through the socket labelled / 2 on the rear of the TV.

If you connect a VCR or other recording equipment to the / 2 socket, you can

then record from the equipment connected to other sockets of the TV.

“TV”: Outputs a broadcast.

“AV1”: Outputs signals from equipment connected to the / 1 socket.

“AV6”: Outputs signals from equipment connected to the

/ 6 socket.

“Auto”: Outputs whatever is being viewed on the screen (except signals from the

/ 3, HDMI IN 4, HDMI IN 5, HDMI IN 7 and PC / sockets).

Using MENU Functions

Speaker

Turns on/off the TV’s internal speakers.

“TV Speaker”: The TV speakers are turned on in order to listen to the TV’s sound

through the TV speakers.

“Audio System”: The TV speakers are turned off in order to listen to the TV’s sound

only through your external audio equipment connected to the audio output sockets.

When connected with an HDMI control compatible equipment, you can turn the

connected equipment on interlocked with the TV. This setting must be made after

connecting the equipment.

Audio Out

“Variable”: The audio output from your audio system can be controlled by the TV’s

remote.

“Fixed”: The audio output of the TV is fixed. Use your audio receiver’s volume

control to adjust the volume (and other audio settings) through your audio system.

~

“Audio Out” is not available for audio system connected to the TV using the HDMI sockets.

Colour System

Selects the colour system (“Auto”, “PAL”, “SECAM”, “NTSC3.58”, “NTSC4.43”

or “PAL60”) according to the input signal from the input source.

Continued

GB

27

HDMI Set-up

This is used to set the HDMI control compatible equipment connected to the HDMI

sockets. Note that the interlock setting must also be made on the connected HDMI

control compatible equipment side.

HDMI Control

Sets whether to interlock the HDMI control compatible equipment and the TV.

When set to “On”, the following menu items can be performed.

Auto Devices Off

When this is set to “On”, the HDMI control compatible equipment turn off

interlocked with the TV.

Auto TV On

When this is set to “On”, the TV turns on interlocked with the HDMI control

compatible equipment.

Device List Update

Creates or updates the “HDMI Device List”. Up to 11 HDMI control compatible

equipment items can be connected, and up to 5 equipment items can be connected to

a single socket. Be sure to update the “HDMI Device List” when you change the

HDMI control compatible equipment connections or settings.

HDMI Device List

Displays the connected HDMI control compatible equipment.

~

You cannot use “HDMI Set-up” when an HDMI control compatible audio system is interlocked

with the TV.

Timer Settings

Sets the timer to turn on/off the TV.

Sleep Timer

Sets a period of time after which the TV automatically switches itself into standby

mode.

When “Sleep Timer” is activated, the (Timer) indicator on the TV front panel

lights up in orange.

z

• If you turn off the TV and turn it on again, “Sleep Timer” is reset to “Off”.

• A notification message appears on the screen one minute before the TV switches to standby

mode.

On Timer

Sets the timer to turn on the TV from standby mode.

“Day”: Selects the day on which you want to activate the “On Timer”.

“Time”: Sets the time to turn on the TV.

“Duration”: Selects the time period after which the TV automatically switches to

standby mode again.

“Volume Set-up”: Sets the volume for when the timer turns on the TV.

Clock Set

Allows you to adjust the clock manually. When the TV is receiving digital channels,

the clock cannot be adjusted manually since it is set to the time code of the

broadcasted signal.

Power Saving

Selects the power saving mode to reduce the power consumption of the TV.

When “Picture Off” is selected, the picture is switched off and the (Picture Off)

indicator on the TV front panel lights up in green. The sound remains unchanged.

GB

28

Light Sensor

“On”: Automatically optimizes the picture settings according to the ambient light in

the room.

“Off”: Turns off the “Light Sensor” feature.

~

Be sure not to put anything over the sensor, as its function may be affected. See page 10 for

further information on the sensor.

Product Information

Displays your TV’s product information.

All Reset

Resets all settings to the factory settings and then displays the “Auto Start-up”

screen.

~

• Be sure not to turn the TV off during this period (it takes about 30 seconds) or press any

buttons.

• All settings, including Digital Favourite list, country/region, language, auto tuned channels,

etc. will be reset.

Using MENU Functions

GB

29
