Sony Bravia KDL-32D3010: Analogue Set-up menu

Manual Programme

Before selecting “Label”/“AFT”/“Audio Filter”/“Skip”/“Decoder”, press PROG +/-

to select the programme number with the channel. You cannot select a programme

Preset

number that is set to “Skip” (page 33).

Programme/System/Channel

Presets programme channels manually.

1 Press

F/f to select “Programme”, then press .

2 Press

F/f to select the programme number you want to manually tune (if

tuning a VCR, select channel 00), then press RETURN.

3 Press F/f to select “System”, then press .

4 Press

F/f to select one of the following TV broadcast systems, then

press RETURN.

B/G: For western European countries/regions

I: For the United Kingdom

D/K: For eastern European countries/regions

L: For France

5 Press F/f to select “Channel”, then press .

6 Press

F/f to select “S” (for cable channels) or “C” (for terrestrial

channels), then press

g.

7 Tune the channels as follows:

If you do not know the channel number (frequency)

Press F/f to search for the next available channel. When a channel has been found,

the search will stop. To continue searching, press

F/f.

If you know the channel number (frequency)

Press the number buttons to enter the channel number of the broadcast you want or your

VCR channel number.

8 Press to jump to “Confirm”, then press .

9 Press

f to select “OK”, then press .

Repeat the procedure above to preset other channels manually.

Label

Assigns a name of your choice, up to five letters or numbers, to the selected channel.

This name will be displayed briefly on the screen when the channel is selected.

To input characters, follow steps 2 to 4 of “Programme Labels” (page 31).

AFT

Allows you to fine-tune the selected programme number manually if you feel that a

slight tuning adjustment will improve the picture quality.

You can adjust the fine tuning over a range of -15 to +15. When “On” is selected, the

fine tuning is performed automatically.

LNA

Improves the picture quality for individual channels in the case of very weak

broadcast signals (noisy picture).

If you cannot see any improvement in the picture quality even if you set to “On”, set

this option to “Off” (factory setting).

Audio Filter

Improves the sound for individual channels in the case of distortion in mono

broadcasts. Sometimes a non-standard broadcast signal can cause sound distortion or

intermittent sound muting when watching mono programmes.

If you do not experience any sound distortion, we recommend that you leave this

option set to the factory setting “Off”.

~

You cannot receive stereo or dual sound when “Low” or “High” is selected.

GB

32

Skip

Skips unused analogue channels when you press PROG +/- to select channels. (You

can still select a skipped channel using the number buttons.)

Decoder

Shows and records the scrambled channel selected when using a decoder connected

directly to scart connector / 1, or to scart connector / 2 via a VCR.

~

Depending on the country/region selected for “Country” (page 6), this option may not be

available.

Confirm

Saves changes made to the “Manual Programme Preset” settings.

Using MENU Functions

GB

33
