Sony BRAVIA KDL-20S2000: Digital Set-up menu

28

 GB

KDL-20S2020

2-685-333-41(0)

Digital Set-up menu

You can change/set the digital settings using the

Digital Set-up menu. To select options in

“Settings”, see “Navigating through menus”

(page 19).

Digital Tuning

Displays the “Digital Tuning” menu.

Digital Auto Tuning

Tunes in all the available digital channels.

Usually you do not need to do this operation because the channels are already tuned

when the TV was first installed (page 5). However, this option allows you to repeat

the process (e.g., to retune the TV after moving house, or to search for new channels

that have been launched by broadcasters).

Programme List Edit

Removes any unwanted digital channels stored on the TV, and changes the order of

the digital channels stored on the TV.

1

Press

F

/

f

 to select the channel you want to remove or move to a new

position.

If you know the programme number (frequency)

Press the number buttons to enter the three-digit programme number of the broadcast

you want.

2

Remove or change the order of the digital channels as follows:

To remove the digital channel

Press

. A message that confirms whether the selected digital channel is to be

deleted appears. Press

G

 to select “Yes”, then press

.

To change the order of the digital channels

Press

g

, then press

F

/

f

 to select the new position for the channel and press

G

.

Repeat the procedure in steps 1 and 2 to move other channels if required.

3

Press RETURN.

Digital Manual Tuning

Tunes the digital channels manually.

1

Press the number button to select the channel number you want to

manually tune, then press

F

/

f

 to tune the channel.

2

When the available channels are found, press

F

/

f

 to select the channel

you want to store, then press

.

3

Press

F

/

f

 to select the programme number where you want to store the

new channel, then press

.

Repeat the procedure above to tune other channels manually.

Set Up

Select:

Enter:

Exit:

MENU

English

-

Back:

Auto Start Up

Language

Country

Auto Tuning

Programme Sorting

AV Preset

Sound Offset

Manual Programme Preset

Digital Set Up

010COV.book  Page 28  Monday, June 12, 2006  3:29 PM

29

 GB

KDL-20S2020

2-685-333-41(0)

Using MENU Functions

Digital Set-up

Displays the “Digital Set-up” menu.

Subtitle Setting

Displays digital subtitles on the screen.

When “For Hard Of Hearing” is selected, some visual aids may also be displayed

with the subtitles (if TV channels broadcast such information).

Subtitle Language

Selects which language subtitles are displayed in.

Audio Language

Selects the language used for a programme. Some digital channels may broadcast

several audio languages for a programme.

Audio Type

Increases the sound level when “For Hard Of Hearing” is selected.

Parental Lock

Sets an age restriction for programmes. Any programme that exceeds the age

restriction can only be watched after a PIN Code is entered correctly.

1

Press the number buttons to enter your existing PIN code.

If you have not previously set a PIN, a PIN code entry screen appears. Follow the

instruction of “PIN Code” below.

2

Press

F

/

f

 to select the age restriction or “None” (for unrestricted

watching), then press

.

3

Press RETURN.

PIN Code

Sets a PIN code for the first time, or allows you to change your PIN code.

1

Enter a PIN as follows:

If you have previously set a PIN

Press the number buttons to enter your existing PIN.

If you have not set a PIN

Press the number buttons to enter the factory setting PIN of 9999.

2

Press the number buttons to enter the new PIN code.

A message appears to inform you that the new PIN has been accepted.

3

Press RETURN.

Tip

PIN code 9999 is always accepted.

Technical Set-up

Displays the Technical Set-up menu.

“Auto Service Update”: Enables the TV to detect and store new digital services as

they become available.

“Software Download”: Enables the TV to automatically receive software updates,

free through your existing aerial (when issued). Sony recommends that this option is

set to “On” at all times. If you do not want your software to be updated, set this option

to “Off”.

“System Information”: Displays the current software version and the signal level.

“Time Zone”: Allows you to select the correct time zone for your country.

CA Module Set-up

Allows you to access a Pay Per View service once you obtain a Conditional Access

Module (CAM) and a view card. See page 30 for the location of the

 (PCMCIA)

socket.

010COV.book  Page 29  Monday, June 12, 2006  3:29 PM
