Sony CPD-E430: Specifications

To display this monitor’s name, serial number, and

date of manufacture.

Specifications

While the monitor is receiving a

INFORMATION

video signal, press and hold the

MODEL

:

CPD-E430

CRT

MENU button for more than

SER NO

:

1234567

W

0.24 mm aperture grille pitch, 90-degree deflection, FD Trinitron

: 2001-30

5 seconds to display this

MANUFACTURED

R

G

19 inches measured diagonally

monitor’s information box.

B

Viewable image size

3

7

Approx. 365

× 274 mm (w/h) (14

/8 × 10

/8 inches)

18.0" viewing image

If thin lines appear on the screen

Resolution (H:Horizontal, V:Vertical)

(damper wires)

Maximum: H: 1920 dots, V: 1440 lines

Recommended: H: 1280 dots, V: 1024 lines

These lines do not indicate a malfunction; they are a normal

Input signal levels

effect of the Trinitron picture tube with this monitor. These are

Video signal: Analog RGB: 0.700 Vp-p (positive), 75

Ω

shadows from the damper wires used to stabilize the aperture grille.

SYNC signal: H/V separate or composite sync:

The aperture grille is the essential element that makes a Trinitron

TTL 2 k

Ω, Polarity free

picture tube unique by allowing more light to reach the screen,

Sync on Green: 0.3 Vp-p (negative)

resulting in a brighter, more detailed picture.

Standard image area

Approx. 352

× 264 mm

7

1

(13

/8 × 10

/2 inches)

Deflection frequency (H:Horizontal, V:Vertical)

Damper

H: 30 to 96 kHz, V: 48 to 170 Hz

wires

AC input voltage/current

100 to 240 V, 50 – 60 Hz, 2.0 – 1.0 A

Power Consumption

Approx. 135 W

Operating temperature

Self-diagnosis function

10 ºC to 40 ºC

Dimensions Approx. 451

× 471 × 461 mm (w/h/d)

This monitor is equipped with a self-diagnosis function. If there is

7

5

1

(17

/8 × 18

/8 × 18

/4 inches)

a problem with your monitor or computer, the screen will go blank

Mass Approx. 25.5 kg (56 lb 3 oz)

and the ! (power) indicator will either light up green or flash

Plug and Play DDC2B/DDC2Bi

orange. If the ! (power) indicator is lit in orange, the computer is

GTF

GB

Supplied accessories

in power saving mode. Try pressing any key on the keyboard or

Power cord

moving the mouse.

This instruction manual

x If the ! (power) indicator is green

1 Disconnect the video signal cable, or turn off the

connected computer.

2 Turn the monitor OFF and then ON.

3 Hold the control button upward for a few seconds

before the monitor enters power saving mode.

If all 4 color bars appear (white, red, green, blue), the monitor is

working properly. Reconnect the video input cables and check the

condition of your computer.

If the color bars do not appear, there is a potential monitor failure.

Inform your authorized Sony dealer of the monitor’s condition.

x If the ! (power) indicator is flashing orange

Turn the monitor OFF and then ON.

If the ! (power) indicator lights up green, the monitor is working

properly.

If the ! (power) indicator is still flashing, there is a potential

monitor failure. Count the number of seconds between orange

flashes of the ! (power) indicator and inform your authorized Sony

dealer of the monitor’s condition. Be sure to note the model name

and serial number of your monitor. Also note the make and model

of your computer and graphics board.

(continued)

7
