Sony KLV-26U2520: Set-up menu

010COV.book Page 16 Wednesday, April 18, 2007 3:53 PM

Sleep Timer

Sets a period of time after which the TV automatically switches itself into standby

mode.

When the Sleep Timer is activated, the indicator on the TV (front) lights up in

amber.

Tips

• If you switch off the TV and switch it on again, “Sleep Timer” is reset to “Off”.

• “Sleep timer will end soon. Power will be turned off” appears on the screen one minute

before the TV switches to standby mode.

Set-up menu

Set Up

You can select the options listed below on the

Auto Start Up

Set-up menu. To select options in “Settings”, see

Language

English

“Navigating through menus” (page 12).

Country

-

Auto Tuning

Programme Sorting

AV Preset

Sound Offset

Manual Programme Preset

Back:

Select:

Enter:

Exit:

MENU

Auto Start-up

Starts the “first time operation menu” to select the language and country/region, and

tune in all available channels.

Language

Selects the language in which the menus are displayed.

Country

Selects the country/region where you operate the TV.

Tip

The country/region in which you want to use the TV does not appear in the list, select “-”

instead of a country/region.

Auto Tuning

Tunes in all the available channels.

Programme Sorting

Changes the order in which the channels are stored on the TV.

1 Press

F/f to select the channel you want to move to a new position,

then press

g.

2 Press

F/f to select the new position for your channel, then press .

AV Preset

Assigns a name to any equipment connected to the side and rear sockets.

1 Press

F/f to select the desired input source, then press .

2 Press

F/f to select the desired option below, then press .

• AV1 (or AV2/ AV3/ AV4/ PC/ HDMI 1/HDMI 2), VIDEO, DVD, CABLE, GAME,

CAM, SAT

: Uses one of the preset labels to assign a name to connected equipment.

• “Edit”: Creates your own label (Not available for PC,

HDMI 1, HDMI 2).

• “Skip”: Skips an input source that is not connected to any equipment when you

press F/f to select the input source.

Sound Offset

Sets an independent volume level to each equipment connected to the TV.

GB

16

KLV-40/32/26U25xx

3-216-582-31(0)

010COV.book Page 17 Wednesday, April 18, 2007 3:53 PM

Manual Programme

Before selecting “Label”/“AFT”/“Audio Filter”/“Skip”/“Decoder”, press F/f to

select the programme number you want to modify. Then, press .

Preset

System

Presets programme channels manually.

1 Press

F/f to select “System”, then press .

2 Press

F/f to select one of the following TV broadcast systems, then

press

G.

B/G: For western European countries/regions

D/K: For eastern European countries/regions

L: For France

I: For the United Kingdom

Note

Depending on the country/region selected for “Country” (page 5), this option may not be

available.

Channel

1 Press

F/f to select “Channel”, then press .

2 Press

F/f to select “S” (for cable channels) or “C” (for terrestrial

Using MENU Functions

channels), then press

g.

3 Tune the channels as follows:

If you do not know the channel number (frequency)

Press F/f to search for the next available channel. When a channel has been found,

the search will stop. To continue searching, press

F/f.

If you know the channel number (frequency)

Press the number buttons to enter the channel number of the broadcast you want or

your VCR channel number.

4 Press to jump to “Confirm”, then press .

5 Press

f to select “OK”, then press .

Repeat the procedure above to preset other channels manually.

Label

Assigns a name of your choice, up to five letters or numbers, to the selected channel.

AFT

Allows you to fine-tune the selected programme number manually if you feel that a

slight tuning adjustment will improve the picture quality.

Audio Filter

Improves the sound for individual channels in the case of distortion in mono

broadcasts. Sometimes a non-standard broadcast signal can cause sound distortion or

intermittent sound muting when watching mono programmes.

If you do not experience any sound distortion, we recommend that you leave this

option set to the factory setting “Off”.

Notes

• You cannot receive stereo or dual sound when “Low” or “High” is selected.

• “Audio Filter” is not available when “System” is set to “L”.

Skip

Skips unused channels when you press PROG +/- to select channels. (You can still

select a skipped channel using the number buttons.)

Decoder

Views and records the scrambled channel selected when using a decoder connected

directly to scart connector / 1, or to scart connector / 2 via a VCR.

Note

Depending on the country/region selected for “Country” (page 5), this option may not be

available.

GB

17

KLV-40/32/26U25xx

3-216-582-31(0)
