Panasonic EY3740: ASSEMBLY MAINTENANCE

EY3740.fm6ページ２００８年８月８日 金曜日 午後６時１２分

ASSEMBLY

MAINTENANCE

1. To insert the battery pack; (fig.1)

•

To make any adjustments, changing accessory,

Slide the battery pack in place at the bottom of

or storing the flashlight, remove battery pack

the flashlight. The battery should snap into

from the flashlight.

place. If this is loosen, it has not been properly

•

To clean the flashlight, wipe with a dry, soft

connected.

cloth.

Make sure the battery is securely connected

How to replace the new bulb. (fig.4)

to the flashlight.

1.

Take off the ring ( )

1

2. To remove the battery pack;

2.

Match the joint part A and B, then remove the

Press the two tabs on the sides of the battery

bulb. ( , )

2

3

pack. Slide the battery pack out of the flashlight.

3.

Install the new bulb and turn to hold firmly.

3. Shoulder strap (fig.2)

( , )

4 5

Follow the steps to make the loop at the buckle.

4.

Fit the ring. ( )

1

Make sure the strap is firmly fixed on the

Lens, reflector, and bulb are hot immediately

flashlight.

after use. Wait a while before replacing the

bulb after switch off.

OPERATION

*

To purchase a new bulb, please consult your

authorized dealer. (Please always use the

1. Press the switch to light on.

genuine bulbs.)

2. Head angle adjustment; (fig.3)

Head angle can be changed at 4-locking

ACCESSORIES

positions for desired angle.

Battery Pack

3. When it is placed away from you, make sure it

•

See the Specification at the bottom of this page.

will not be tumble.

4. When the battery capacity level gets low, Iow

Battery Charger

voltage indicator will start to blink. Then charge

•

For inquiri es please contact an authorized dealer.

the battery pack.

5. Press the switch to light off after use.

SPECIFICATIONS

CAUTION:

Model no.

EY3740

•

Read the instruction manual of the charger

Bulb type

14.4 V Xenon 0.55 A

to charge the battery pack, and how to

279 124 90 mm

Size

handle battery pack.

(10-63/64" 4-7/8" 3-35/64")

Weight

310 (0.68 lbs)

g

Battery packs

Li-ion battery EY9L40

Battery voltage

14.4 V DC (3.6 V 4 cells)

‑6‑

EY3740.fm7ページ２００８年８月８日 金曜日 午後６時１２分

Information for Users on Collection and Disposal of Old

Equipment and used Batteries

These symbols on the products, packaging, and/or accompanying

documents mean that used electrical and electronic products and

batteries should not be mixed with general household waste.

For proper treatment, recovery and recycling of old products and used

batteries, please take them to applicable collection points, in accordance

with your national legislation and the Directives 2002/96/EC and

2006/66/EC.

By disposing of these products and batteries correctly, you will help to

save valuable resources and prevent any potential negative effects on

human health and the environment which could otherwise arise from

inappropriate waste handling.

For more information about collection and recycling of old products and

batteries, please contact your local municipality, your waste disposal

service or the point of sale where you purchased the items.

Penalties may be applicable for incorrect disposal of this waste, in

accordance with national legislation.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact your

dealer or supplier for further information.

[Information on Disposal in other Countries outside the Euro-

pean Union]

These symbols are only valid in the European Union. If you wish to discard these

items, please contact your local authorities or dealer and ask for the correct method

of disposal.

Note for the battery symbol (bottom two symbol examples):

This symbol might be used in combination with a chemical symbol. In this case it

complies with the requirement set by the Directive for the chemical involved.

‑7‑
