Specifications

Specifications are subject to change without notice.

INTERCHANGEABLE LENS FOR DIGITAL CAMERA

“LEICA DG NOCTICRON 42.5 mm/F1.2 ASPH./POWER O.I.S.”

Focal length f=42.5 mm

(35 mm film camera equivalent: 85 mm)

Aperture type 9 diaphragm blades/circular aperture diaphragm

Aperture range F1.2

Minimum aperture value F16

Lens construction 14 elements in 11 groups (2 aspherical lenses, 1 ED Lens,1 UHR

Lens)

Nano surface coating Yes

In focus distance 0.5 m to ¶ [from the focus distance reference line]

Maximum image magnification 0.1k (35 mm film camera equivalent: 0.2k)

Optical image stabiliser Available

[O.I.S.] switch Available (Switching ON/OFF)

[AF/MF] switch Available (Switching AF/MF)

Mount “Micro Four Thirds Mount”

Angle of view 29x

Filter diameter 67 mm

Max. diameter Approx. 74 mm

Overall length Approx. 76.8 mm

(from the tip of the lens to the base side of the lens mount)

Mass Approx. 425 g
