Cable binding instructions

Preventing the plasma display from failing over

Securing to a wall.

Notes:

• Securely attach to a wall, pillar or similarly solid

structural feature using separately- obtained

products such as cords or chains of adequate

strength.

• Secure in the wall at two locations each on the left

and right.

1

  Attach the clampers to the pedestal.

Attach the stand clampers

 (right and left).

2

  Connect the cable and mains lead.

3

   Use the clampers to bind the cable and

mains lead.

The picture shown is illustrative purposely only and may differ slightly from the actual product.

*  For cable connection, refer to the operating instructions of plasma display.

Mains lead

Clampers

Accessories for pedestal security

We recommend that measures are taken to prevent the Plasma display from falling over in such an event.

*  The information in this section is designed to reduce the risk of injuries caused by the Plasma display falling over

during an earthquake, etc.

However, no measure can guarantee protection against all earthquakes.

5

English

How to

release:

How to

fi

 x:

Push both side hooks

and pull out

Clampers
