Specifications

INTERCHANGEABLE LENS FOR DIGITAL CAMERA

“LUMIX G VARIO 45–150 mm/F4.0– 5.6 ASPH./MEGA O.I.S.”

Focal length f=45 mm to 150 mm

(35 mm film camera equivalent: 90 mm to 300 mm)

Aperture type 7 diaphragm blades/circular aperture diaphragm

Aperture range F4.0 (Wide) to F5.6 (Tele)

Minimum aperture value F22

Lens construction 12 elements in 9 groups (2 aspherical lenses, 1 UHR Lens)

In focus distance 0.9 m

to ¶ (from the focus distance reference line)

Maximum image magnification 0.17k (35 mm film camera equivalent: 0.35k)

Optical image stabilizer Available

[O.I.S.] switch None (Setting of the [Stabilizer] is done in [Rec] mode menu by

LUMIX digital cameras.)

Mount “Micro Four Thirds Mount”

Angle of view 27x (Wide) to 8.2x (Tele)

Filter diameter 52 mm

Max. diameter Approx. 62 mm

Overall length Approx. 73 mm

(from the tip of the lens to the base side of the lens mount)

Mass Approx. 200 g
