Panasonic HX015E: Specifications

SQT0244_E.book 10 ページ ２０１４年４月１１日　金曜日　午前９時１７分

Specifications

Specifications are subject to change without notice.

INTERCHANGEABLE LENS FOR DIGITAL CAMERA

“LEICA DG SUMMILUX 15 mm/F1.7 ASPH.”

Focal length f=15 mm

(35 mm film camera equivalent: 30 mm)

Aperture type 7 diaphragm blades/circular aperture diaphragm

Maximum aperture F1.7

Minimum aperture value F16

Lens construction 9 elements in 7 groups (3 aspherical lenses)

Nano surface coating Yes

In focus distance 0.2 m to ¶ [from the focus distance reference line]

Maximum image magnification 0.1k (35 mm film camera equivalent: 0.2k)

Optical image stabiliser Not available

[AF/MF] switch Available (Switching AF/MF)

Mount “Micro Four Thirds Mount”

Angle of view 72x

Filter diameter 46 mm

Max. diameter Approx. 57.5 mm

Overall length Approx. 36 mm

(from the tip of the lens to the base side of the lens mount)

Mass Approx. 115 g

10

SQT0244
