Specifications

INTERCHANGEABLE LENS FOR DIGITAL CAMERA

“LUMIX G X VARIO PZ 45–175 mm/F4.0–5.6 ASPH./POWER O.I.S.”

Focal length f=45 mm to 175 mm

(35 mm film camera equivalent: 90 mm to 350 mm)

Aperture type 7 diaphragm blades/circular aperture diaphragm

Aperture range F4.0 (Wide) to F5.6 (Tele)

Minimum aperture value F22

Lens construction 14 elements in 10 groups (2 aspherical lenses, 2 ED Lens)

Nano surface coating Yes

In focus distance 0.9 m

to ¶ (from the focus distance reference line)

Maximum image magnification 0.2k (35 mm film camera equivalent: 0.4k)

Optical image stabilizer Available

[O.I.S.] switch None (Setting of the [STABILIZER] is done in [REC] mode menu

by LUMIX digital cameras.)

Mount “Micro Four Thirds Mount”

Angle of view 27

x (Wide) to 7.1x (Tele)

Filter diameter 46 mm

Max. diameter Approx. 61.6 mm

Overall length Approx. 90.0 mm

(from the tip of the lens to the base side of the lens mount)

Mass Approx. 210 g
