Specifications

Specifications are subject to change without notice.

INTERCHANGEABLE LENS FOR DIGITAL CAMERA

“LUMIX G VARIO 14–42 mm/F3.5–5.6 II ASPH./MEGA O.I.S.”

Focal length f=14 mm to 42 mm

(35 mm film camera equivalent: 28 mm to 84 mm)

Aperture type 7 diaphragm blades/circular aperture diaphragm

Aperture range F3.5 (Wide) to F5.6 (Tele)

Minimum aperture value F22

Lens construction 9 elements in 8 groups (2 aspherical lenses)

In focus distance 0.2 m to ¶ (focal length 14 mm to 20 mm)

[from the focus distance reference line],

0.3 m to ¶ (focal length 21 mm to 42 mm)

[from the focus distance reference line]

Maximum image magnification 0.17k (35 mm film camera equivalent: 0.34k)

Optical image stabiliser Available

[O.I.S.] switch None (Setting of the [Stabilizer] is done in [Rec] mode menu by

LUMIX digital cameras.)

Mount “Micro Four Thirds Mount”

Angle of view 75x (Wide) to 29x (Tele)

Filter diameter 46 mm

Max. diameter Approx. 56 mm

Overall length

Approx. 49 mm (from the tip of the lens to the base side of the lens mount)

Mass Approx. 110 g
