Supplied Accessories

Attaching/Detaching the Lens

[Inspection to be performed when you unpack the unit]

≥ Refer also to the camera’s operating instructions

When removing the unit from its packing box, check

for attaching and detaching the lens.

that the main unit and the supplied accessories are

∫ Attaching the Lens

there and also check their external appearance and

≥ Check that the camera is turned off.

functions to verify that they have not sustained any

1 Turn the lens rear cap

damage during distribution and transportation.

to detach it.

If you discover any trouble, contact your vendor

A: Lens Rear Cap

before using the product.

Product numbers correct as of September 2009.

These may be subject to change.

2 Align the lens fitting

marks B (red marks) on

the camera body and the

lens and then rotate the

lens in the direction of

the arrow until it clicks.

• Do not press the lens release button when you

1 Lens Storage Bag

attach a lens.

2 Lens Hood

• Do not try to attach the lens when holding it at an

3 Lens Cap

angle to the camera body as the lens mount may

4 Lens Rear Cap

get scratched.

(The lens cap and lens rear cap are attached to

• Check that the lens is attached correctly.

the interchangeable lens at the time of purchase.)

6

VQT2H16

H-ES045E-VQT2H16.book 6 ページ ２００９年９月１１日　金曜日　午前１１時４７分

H-ES045E-VQT2H16.book 7 ページ ２００９年９月１１日　金曜日　午前１１時４７分

∫ Detaching the Lens

∫ Attaching the Lens Hood

≥ Check that the camera is turned off.

(Supplied Accessory)

Press the lens release button C while

Insert the lens hood into the lens with the

short sides at the top and bottom, and

turning the lens as far as possible in the

turn in the direction of the arrow until it

direction of the arrow to detach it.

stops.

• Attach the lens rear cap so

that the lens contact point

does not get scratched.

• Attach the body cap to the

camera so no dirt or dust will



get inside the main unit.

D: Fit to the mark

∫ Attaching and Detaching the Lens Cap

≥ Be careful not to lose

∫ Removing the Lens Hood

the lens cap.

Turn the lens hood in the direction of the

arrow to detach it.

7
