Specifications

INTERCHANGEABLE LENS FOR DIGITAL CAMERA

“LUMIX G VARIO 14–42 mm/F3.5–5.6 ASPH./MEGA O.I.S.”

Focal length f=14 mm to 42 mm

(35 mm film camera equivalent: 28 mm to 84 mm)

Aperture type 7 leaf shutters/iris diaphragm/circular diaphragm

Aperture range F3.5 (Wide) to F5.6 (Tele)

Minimum aperture value F22

Lens construction 12 elements in 9 groups (1 aspherical lens)

In focus distance 0.3 m to ¶ (from the focus distance reference line)

Maximum image magnification 0.16k (35 mm film camera equivalent: 0.32k)

Optical image stabilizer Available

[O.I.S.] switch None

(Setting of the [STABILIZER] is done in [REC] mode menu by

LUMIX digital cameras.)

Mount “Micro Four Thirds Mount”

Angle of view 75x (Wide) to 29x (Tele)

Filter diameter 52 mm

Max. diameter 60.6 mm

Overall length Approx. 63.6 mm

(from the tip of the lens to the base side of the lens mount)

Mass Approx. 165 g
