Panasonic EY6409GQKW: ONLY FOR U. K.

EY6405(EU).book Page 10 Wednesday, June 15, 2005 7:14 PM

IMPORTANT: The wires in this mains lead

ONLY FOR U. K.

are coloured in accordance

with the following code:

VIII.

ELECTRICAL PLUG

Blue: Neutral

Brown: Live

INFORMATION

As the colours of the wire in the mains lead

FOR YOUR SAFETY PLEASE READ

of this appliance may not correspond with

the coloured markings identifying the termi-

THE FOLLOWING TEXT CAREFULLY

nals in your plug, proceed as follows.

The wire which is coloured BLUE must be

This appliance is supplied with a moulded

connected to the terminal in the plug which

three pin mains plug for your safety and

is marked with the letter N or coloured

convenience.

BLACK.

A 3 amp fuse is fitted in this plug.

The wire which is coloured BROWN must

Should the fuse need to be replaced please

be connected to the terminal in the plug

ensure that the replacement fuse has a rat-

which is marked with the letter L or coloured

ing of 3 amp and that it is approved by

RED.

ASTA or BSI to BS1362.

Under no circumstances should either of

Check for the ASTA mark or the BSI

these wires be connected to the earth termi-

mark on the body of the fuse.

nal of the three pin plug, marked with the

If the plug contains a removable fuse cover

letter E or the Earth Symbol .

you must ensure that it is refitted when the

fuse is replaced.

How to replace the fuse: Open the fuse

If you lose the fuse cover the plug must not

compartment with a screwdriver and replace

be used until a replacement cover is

the fuse and fuse cover if it is removable.

obtained.

A replacement fuse cover can be pur-

chased from your local Panasonic Dealer.

IF THE FITTED MOULDED PLUG IS

UNSUITABLE FOR THE SOCKET OUTLET

Fuse CoverFuse Cover

IN YOUR HOME THEN THE FUSE

SHOULD BE REMOVED AND THE PLUG

CUT OFF AND DISPOSED OF SAFELY.

THERE IS A DANGER OF SEVERE ELEC-

TRICAL SHOCK IF THE CUT OFF PLUG

IS INSERTED INTO ANY 13 AMP

SOCKET.

If a new plug is to be fitted please observe

This apparatus was produced to BS800.

the wiring code as shown below.

If in any doubt please consult a qualified

electrician.

— 10 —
