IMPORTANT:
The wires in this mains lead are
ONLY FOR U. K.
coloured in accordance with the
following code:
IV
.
ELECTRICAL PLUG
Blue: Neutral
Brown: Live
INFORMATION
As the colours of the wire in the mains lead
FOR YOUR SAFETY PLEASE READ
of this appliance may not correspond with
THE FOLLOWING TEXT CAREFULLY
the coloured markings identifying the termi-
nals in your plug, proceed as follows.
This appliance is supplied with a moulded
The wire which is coloured BLUE must be
three pin mains plug for your safety and
connected to the terminal in the plug which
convenience.
is marked with the letter N or coloured
A5ampfuseisttedinthisplug.
BLACK.
Should the fuse need to be replaced please
The wire which is coloured BROWN must be
ensure that the replacement fuse has a rat-
connected to the terminal in the plug which is
ing of 5 amp and that it is approved by ASTA
marked with the letter L or coloured RED.
or BSI to BS1362.
Under no circumstances should either of
Check for the ASTA mark or the BSI mark
these wires be connected to the earth ter-
on the body of the fuse.
minal of the three pin plug, marked with the
If the plug contains a removable fuse cover
letter E or the Earth Symbol .
youmustensurethatitisrettedwhenthe
fuse is replaced.
How to replace the fuse: Open the fuse
If you lose the fuse cover the plug must not
compartment with a screwdriver and replace
be used until a replacement cover is ob-
the fuse and fuse cover if it is removable.
tained.
A replacement fuse cover can be purchased
from your local Panasonic Dealer.
IF THE FITTED MOULDED PLUG IS UN-
SUITABLE FOR THE SOCKET OUTLET IN
Fuse Cover
YOUR HOME THEN THE FUSE SHOULD
BE REMOVED AND THE PLUG CUT OFF
AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELEC-
TRICAL SHOCK IF THE CUT OFF PLUG
IS INSERTED INTO ANY 13 AMP SOCK-
This apparatus was produced to BS800.
ET.
Ifanewplugistobettedpleaseobserve
the wiring code as shown below.
If in any doubt please consult a qualied
electrician.
-
9
-
