Chapter 6

Preparation

Installing the unit

 Caution

•

Do not place a VCR or any other device on the

top of the unit.

•

When installing, allow enough space on the

sides and above the unit.

•

Do not block the side ventilation opening or the

rear exhaust opening of the unit.

 Caution

• Placing the unit alone in the vertical position can

result in product damage and malfunction.

Preparing the remote control

unit

Inserting batteries

1

Open the battery cover.

2

Load the supplied two AA size batteries while

inserting their respective negative polarity (–) ends

first.

Place batteries with their terminals corresponding to

the (+) and (–) indicators in the battery compartment.

3

Close the battery cover.

PDA-V100HD

1

2

3

4

5

6

STANDBY

STANDBY/ON

INPUT

INPUT

Over 5 cm

Over 5 cm

Over 5 cm

Over 10 cm

Exhaust

opening

Ventilation

opening

PDA-V100HD

12

34

5

6

ST

ANDBY

ST

ANDBY/ON

Preparation

06

13

En

English

 Caution

Improper use of batteries can result in chemical

leakage or an explosion. Be sure to follow the

instructions below.

• When you replace the batteries, use manganese or

alkaline ones.

• Place the batteries with their terminals

corresponding to the (+) and (–) indicators.

• Do not mix batteries of different types. Different

types of batteries have different characteristics.

• Do not mix old and new batteries. Mixing old and

new batteries can shorten the life of new batteries

or cause chemical leakage in old batteries.

• Remove batteries as soon as they have worn out.

Chemicals that leak from batteries can cause a

rash. If you find any chemical leakage, wipe

thoroughly with a cloth.

• The batteries supplied with this product may have a

shorter life expectancy due to storage conditions.

• If you will not use the remote control unit for an

extended period of time, remove the batteries from

it.

•

WHEN DISPOSING OF USED BATTERIES, PLEASE

COMPLY WITH GOVERNMENTAL REGULATIONS

OR ENVIRONMENTAL PUBLIC INSTITUTION’S

RULES THAT APPLY IN YOUR COUNTRY/AREA.

Operating range of the remote

control unit

Operate the remote control unit while pointing it toward

the remote control sensor (

) located at the left of the

front panel of the unit. The distance from the remote

control sensor must be within 7 m and the angle

relative to the sensor must be within 30 degrees in the

right, left, upward, or downward direction.

 Caution

• Do not expose the remote control unit to shock. In

addition, do not expose the remote control unit to

liquids, and do not place in an area with high

humidity.

• Do not install or place the remote control unit under

direct sunlight. The heat may cause deformation of

the unit.

• The remote control unit may not work properly if the

remote control sensor of the unit is under direct

sunlight or strong lighting. In such case, change

the angle of the lighting or unit, or operate the

remote control unit closer to the remote control

sensor.

• When any obstacle exists between the remote

control unit and the remote control sensor, the

remote control unit may not function.

• As the batteries become empty, the remote control

unit can function within a shorter distance from the

remote control sensor. Replace the batteries with

new ones early enough.

1

2

3

4

5

6

STAN

DBY

HDM

I CONT

ROL

STAN

DBY/O

N

INPUT

INPUT

30 º

30 º

Remote

control

sensor

7 m
