Thank you for buying this Pioneer product. Please read through

these operating instructions so you will know how to operate your

model properly. After you have finished reading the instructions,

put them away in a safe place for future reference.

Before you start

• The nominal impedance of this speaker system is 6

Ω

. Connect

the speaker system to an amplifier with a load impedance of 6

Ω

 (a model with “6

Ω

” displayed on the speaker output

terminals).

In order to prevent damage to the speaker system resulting from

input overload, please observe the following precautions:

• Do not supply power to the speaker system in excess of the

maximum permissible input.

• When using a graphic equalizer to emphasize loud sounds in

the high-frequency range, do not use excessive amplifier

volume.

• Do not try to force a low-powered amplifier to produce loud

volumes of sound (the amplifier’s harmonic distortion will be

increased, and you may damage the speaker).

Care of the speaker cabinets

• With normal use, wiping with a soft cloth should be sufficient

to keep the cabinet clean. If necessary, clean with a cloth

dipped in a neutral cleanser diluted five or six times with water,

and wrung out well. Do not use furniture wax or cleansers.

Never use alcohol, thinners, benzine, insecticide sprays or

other chemicals on or near this unit since these will corrode the

surfaces. When using chemically-treated cloths, be sure to

carefully read their accompanying instruction manual.

Cleaning the glossy finish of the speaker system

• When cleaning the finish of the speaker system, gently wipe it

with a dry soft cloth; the supplied cleaning cloth.

• If you use a dusty or hard cloth or if you rub the screen hard, the

finish of the product will be scratched.

• If you clean the surface of the speaker system with a wet cloth,

water droplets on the surface may enter into the product,

resulting in malfunction.

Caution

Installation

• Do not place the speaker on an unstable surface, as doing so

may cause the speaker to fall and cause damage or bodily

injury.

• Switch off and unplug your AV equipment and consult the

instructions when connecting up components. Make sure you

use the correct connecting cables.

• When placing this unit, avoid areas where it may be likely to fall

and cause injury in the event of a natural disaster (such as an

earthquake). For more information, see page 6.

• Pioneer is not responsible for any accidents or damage that

result from improper installation, misuse or modification of the

product, or natural disasters.

Using the speakers

• Do not use the speaker to output distorted sound for long

periods of time. This can result in damages to the speaker and

poses a potential fire hazard.

• Do not sit or stand on the speaker, or let children play on the

speaker. Doing so could provoke the speaker to fall, causing

damages or bodily injury.

CAUTION

These speaker terminals carry

HAZARDOUS LIVE voltage

. To

prevent the risk of electric shock when connecting or

disconnecting the speaker cables, disconnect the power cord

before touching any uninsulated parts.

01_S_LX70-LR_En.book  2 ページ  ２００７年９月１２日　水曜日　午後２時５８分

English Français Deutsch Nederlands Italiano Svenska Español Português

3

En

Confirm your accessories

• Bracket (for speakers/S) x 2

• Bracket (for speakers/L) x 2

• Bracket (for wall/Left) x 1

• Bracket (for wall/Right) x 1

• Screw  (long)  x  8

• Screw (short) x 4

• Cleaning  cloth  x  1

• Wall mounting template (Left) x 1

• Wall mounting template (Right) x 1

• Operating instructions

When using for home theater  systems

Combine this speaker system with a Pioneer plasma television to

enjoy excellent acoustics that match your interior.

This speaker system can be used as surround speakers of a home

theater system.

Arrange speakers as illustrated below.

So far as possible, place the front left and front right speakers on

the same plane as the TV screen.

Place the left and right speakers equal distances from your

listening position for good stereo sound. Use speaker cords of the

same length for each speaker.

The front right speaker and the surround left speaker are

interchangeable. The front left speaker and the surround right

speaker are also interchangeable.

When using this speaker system as surround speakers, place the

front right speaker as the surround left speaker, and the front left

speaker as the surround right speaker.

• S-LX70C is recommended for the center speaker.

• S-LX70W is recommended for the subwoofer.

Speaker system grill

The speaker system grill cannot be removed. Do not try to forcibly

remove it since doing so may damage the grille.

Front left

Front right

(Subwoofer)

(Center)

Surround left

Inter-

changeable

Inter-

changeable

Surround right
