Thank you for buying Pioneer’s product.

Please read through the Operating Instructions to learn how

to operate your model safely and properly.

Please be advised to keep the Operating Instructions in your

place for future reference.

Installation

•  Consult your dealer if you encounter any difficulties

with this installation.

•  Pioneer is not liable for any damage resulting from

improper installation, improper use, modification, or

natural disasters.

Contents

Cautions  ................................................................. 10

Checking the Enclosed Parts ................................. 11

Care for the Glossy Surface of the Stand ............ 11

Assembling the Stand ........................................... 12

Attaching the Pioneer Display and Television .... 12

Forward/Backward Angle of Inclination

Adjustment Mechanism ........................................ 14

Installing the Product on a TV table etc. ............. 15

Preparing the Cables ............................................. 15

Preventing Equipment from Falling Over ............ 16

Detaching the Pioneer Display and Television

from the Stand ....................................................... 17

Specifications ......................................................... 17

Dimensions Diagram ............................................. 17

Cautions

This product is a table top stand exclusively designed for

Pioneer displays and televisions (PRO-101FD/KRP-500A/

KRP-500M*). Use with other model is capable of resulting in

instability causing possible injury. For further information,

please contact the store where you purchased your display.

Do not install or modify the product other than specified.

Do not use this stand for a Pioneer display and television

other than those designated and do not modify it or use it for

other purposes.

Perform attachments and installation by referring to the

operating instructions. Improper installation is extremely

dangerous because it may result in it falling over or other

accident.

Installation Location

•  Select a location that is strong enough to support the

weight of the stand and the Pioneer display and television.

•  Make sure to place it in a level and stable location.

•  Do not install it outdoors or in a wet place such as at a

hot spring or near a beach.

•  Do not install the stand where it may be subjected to

vibration or shock.

Assembling and Installation

•  Assemble the stand in accordance with the assembly

instructions and securely attach all screws at the

designated locations.

  There have been cases where unforeseen accidents

such as the equipment breaking or falling over

occurred after the installation of the display because

the stand was not installed as instructed.

•  The display must always be installed by two or more

people to assure it is installed safely.

•  Before installation, turn off the power for the display

and peripheral devices then remove the power cord

plug from the power outlet.

This product rotates 10° to the left and right and inclines

approximately 2° forward and backward. Do not place

objects within the range of rotation of this product and the

Pioneer display and television. Install this product so that

during routine use or when it is rotated, it does not protrude

from the TV table or other location it has been installed.

Failure to do so could cause unforeseen accidents such as

the equipment breaking or falling over (see page 15). While

adjusting its angle forward and backward, be extremely

careful to keep your hands out of the space between the

bottom of the Pioneer display and television and the stand (see

page 14).

Prevent accidents caused by the product falling over, by

taking reliable measures to prevent it from falling over (see

page 16).

Do not handle an attached Pioneer display and television on

a wagon or pallet that is smaller that its stand. It may break

or fall.

Do not install on a table smaller than the stand.

* Except for the North American region.
