AEG SRP 4335 CD-MP3: ENGLISH
ENGLISH: AEG SRP 4335 CD-MP3
ENGLISH
41
General Safety Instructions
WARNING!
Do not allow small children to play with the foil as there is a
Read the operating instructions carefully before putting the
danger of suffocation!
appliance into operation and keep the instructions including the
warranty, the receipt and, if possible, the box with the internal
• This device is not intended for use by persons (including
packing. If you give this device to other people, please also pass
children) with reduced physical, sensory or mental capabili-
on the operating instructions.
ties, or lack of experience and knowledge, unless supervised
• To avoid the risk of re or an electric shock, you should not
by a person responsible for their safety or they have been
expose the device to rain or moisture. Consequently, do not
instructed how to use the device by such person.
use the device in the immediate vicinity of water - for exam-
• Children should be supervised to ensure that they do not
ple near a bath tub, a swimming pool or in a damp cellar.
play with the appliance.
• Only use this device for private purpose as intended. This
device is not intended for commercial use.
Symbols in these Instructions for Use
• Only connect the device at a properly installed plug socket.
Important information for your safety is specially marked. It is
Pay attention that the specied voltage corresponds to the
essential to comply with these instructions in order to avoid ac-
voltage of the plug socket.
cidents and prevent damage to the machine:
• Observe the correct polarity and power output when using
WARNING:
external power adapters, always insert batteries with correct
This warns you of dangers to your health and indicates pos-
polarity.
sible injury risks.
• Assemble the device in such a way that the available ventila-
tion openings are not covered.
CAUTION:
• Never open the housing of the device. Incorrect repairs can
This refers to possible hazards to the machine or other
constitute a considerable risk for the user. Should the device
objects.
become damaged, in particular the mains supply cable, do
not operate the device any longer, but rather have it repaired
NOTE:
by an expert. Check the mains supply cable regularly for
This highlights tips and information.
damage.
• For safety reasons a broken or damaged mains lead may
only be replaced by an equivalent lead from the manufac-
Special safety information
turer, our customer service department or a similary qualied
person.
• If the device is not used for a longer period, remove the plug
This device works with a class 1
connector from the plug socket or take out the batteries.
laser.
These symbols may be found on the device and are to indicate
the following:
Location of Controls
The lightning symbol should advise the user
1 VOLUME MIN/MAX (volume control)
of parts in the inside of the device which carry dan-
2
p
OPEN CD compartment
gerously high voltage levels.
3 CD compartment
The symbol with an exclamation mark should
4 TUNING control
advise the user of important operation or mainte-
5 Nylon carrying handle
nance instructions in the accompanying documen-
6 USB port
tation.
7 Card slot
Devices bearing this symbol work with a “class 1
8 Loudspeaker
Laser“ for tracing the CD. The built-in safety
9 Cassette compartment
switches should prevent the user being exposed
10 Pause button - cassette
to dangerous laser light, which is invisible to the
11 / Stop/Eject button - cassette
human eye, when the CD compartment is opened.
12 Forward button - cassette
Under no circumstances should these safety switches be
13 Reverse button - cassette
bypassed or manipulated, as this could result in a danger of
14 Playback button - cassette
exposure to the laser light.
15 LCD display
Children and Frail Individuals
16 STOP button
• In order to ensure your children‘s safety, please keep all
17 MODE
button (repeat/random)
packaging (plastic bags, boxes, polystyrene etc.) out of their
18 PROGRAM button (memory)
reach.
19 Station scale
42
ENGLISH
20 SKIP UP button (forward search)
CAUTION:
21 SKIP DOWN button (reverse search)
• Batteries are not to be disposed of together with domestic
22 Band selector switch (AM / FM / FM ST.)
wastes. Dispose of the used batteries at the relevant col-
23 BBS switch
lection bin or at your dealer’s.
24 Function selector switch (AUX / TAPE / RADIO / MEDIA)
• Different battery types or new and used batteries must not
25 PLAY/PAUSE button
be used together.
Reverse Side (not shown)
WARNING:
26 PHONES Headphone connection
Do not subject batteries to heat or direct sunlight. Never
27 AUX IN socket
expose batteries to re. Danger of explosion!
28 Battery compartment
29 AC~IN Mains connection
CD deck transport protection
30 UKW/FM aerial
• Please open the CD compartment (3) by pressing the
31 POWER ON/OFF Switch
p
OPEN button (2).
32 DC IN 15V jack
• Remove the transport protection from the CD player if
present before use.
Start-up of the device/introduction
• Read the operating instructions thoroughly before the start-
up!
Please use headphones with a 3.5 mm stereo jack plug; these
• Select an appropriate location for the device, e.g. a dry, at,
should be inserted into the socket. The loudspeakers are then
non-slip surface on which the device can be easily operated.
switched off.
• Make sure that the device is adequately ventilated!
• Remove the protective lm from the display, if still attached.
To increase or decrease the bass output.
Power supply
= on, = off.
• Connect the power cable supplied (see battery compartment
if necessary) to a properly installed 230 V / 50 Hz safety
Volume
power socket and the mains connector AC~ IN on the back
of the machine.
The desired volume can be sent using the VOLUME regulator (1).
• Ensure that the voltage is the same as that indicated on the
model identication plate.
Switch-off
• Turn on the device by switching the “POWER” switch on the
The machine is switched off when the function selector switch
backside of the device to “ON”.
(24) is turned to the TAPE position. Then set the “POWER”
switch on the rear of the device to “OFF”. Now disconnect the
NOTE:
mains plug.
Optionally, you can run the device on an AC adapter. Connect
the device to the AC adapter by inserting the connector of the
AUX IN socket
adapter into the DC IN 15 V jack (32). The power switch will
To connect analogue replay devices. Via this socket you can
be disabled hereby.
also hear the sound of other playback devices such as MP3
CAUTION:
players, CD players etc. through the loudspeakers.
Only use an AC power adapter with 15 V (
), other
1. Please connect the external device with a 3.5 mm stereo
power adapters may damage the device.
jack plug to the AUX IN socket (27).
2. Turn the function selector switch (24) to the AUX position.
3. Through the loudspeakers you can hear the playback of the
Inserting the Batteries (Batteries not supplied)
sound from the external device; with the VOLUME control (1)
• Open the battery compartment cover on the rear.
you can change the volume. The CD buttons do not have
• Insert 10 batteries of type UM 1/R20 1.5 V. Please ensure
any function.
that the polarity is correct (see battery compartment cover)!
4. For the remaining procedure please see the operating
• If the device is not used for a long period of time, remove the
instructions of the external sound source.
batteries to avoid the spilling of battery acid.
• Then close the battery lid.
NOTE:
If the power cable is connected, the batteries are switched off
automatically.
ENGLISH
43
NOTE:
Listening to the Radio
• Adjust the volume of the external device to a comfortable
1. Turn the function selector switch (24) to the RADIO position.
level.
2. Use the band selector switch (22) to select the desired
• To connect external microphone, electric guitar, etc.:
frequency band.
Due to the different signal levels, you may need a pre-
amplier which is available at your local dealer.
VHF (Stereo) = FM ST., VHF = FM,
Medium wave = AM (Mono)
3. Tune in the desired station with the station adjustment knob
TUNING (4).
This device has been designed according to the latest state of
4. For VHF/FM mode pull out the telescopic antenna (30) and
the art in USB technology. The large number of different USB
turn it to improve reception. If the reception is too weak
devices of all kinds on the market today makes it impossible to
and there is interference on the station being received, we
guarantee full compatibility with all USB storage media. For this
recommend switching to FM.
reason, problems during playback from USB storage media may
5. An aerial is integrated into the device for the reception of
occur in rare cases. This is no malfunction of the device.
AM stations. The machine can be aligned to the station by
1. Turn the function selector switch (24) to the MEDIA position.
turning it. In this frequency band programs are transmitted
2. Connect a USB device directly to the USB port.
in “mono” only.
3. Press and hold the
STOP button (16) and select USB
mode. USb will be displayed.
Cassette Operation
4. After a few seconds, the total number of folders and tracks
will be displayed. Playback will start subsequently.
Playing Cassettes
5. The display alternately shows the current track and the
1. Turn the function selector switch (24) to the TAPE position.
folder together with MP3 and USB indicators.
2. Press the
/ stop/eject button (11) to open the cassette
compartment (9).
See chapter “Playing CDs/MP3” for more information.
3. Push a recorded audio cassette, with the tape downwards
NOTE:
and the listening side facing forwards, into the compartment
(full reel to the left). Then close the cassette compartment
The USB port will be automatically selected if there is no CD
again.
loaded in the CD drive.
4. Press the
u
playback key (14) to listen to the tape.
CAUTION:
5. With the / stop/eject key you can stop playback.
Slide the function selector (24) to the RADIO position before
6. Wind the tape forwards or backwards if necessary in the
disconnecting the USB device.
direction of the arrow keys
= forwards (12), = reverse (13).
7. Always press the
/ stop/eject key when changing the
1. To play data from an SD/MMC card, insert it into the card
direction or stopping the tape. This prevents damage to the
slot.
machine and the tape.
2. Turn the function selector switch (24) to the MEDIA position.
8. If the / stop/eject button is pressed again the ap of the
3. Press and hold the
STOP button (16) and select USB
cassette compartment opens.
mode. USb will be displayed. Now press and hold the
9. In order to interrupt playback briey, press the pause but-
STOP button again to select SD mode. Sd will be displayed.
ton (10). Pressing again continues playback.
4. After a few seconds, the total number of folders and tracks
appears on the display. Playback starts subsequently.
Playing CDs/MP3
5. The display will show the current track and the folder alter-
nately together with the
u
MP3 and SD icons.
This is how you play a CD
1. Turn the function selector switch (24) to the “MEDIA” posi-
For more information on operation, see chapter “Playing
tion.
CDs/MP3”.
2. Please open the CD compartment (3) by pressing the
p
OPEN button (2).
NOTE:
3. Insert a CD with the printed side facing up and close the CD
The card slot is automatically selected if there are no CD
deck.
loaded in the CD drive and no USB storage media connected.
4. After a few seconds, the display will show the total number
of tracks.
44
ENGLISH
Press three times: the display contains the word RND and the
NOTE:
track number that is to be played rst. All
With CDs in MP3 format, the number of folders is dis-
tracks are played back in random order.
played briey rst.
NOTE:
5. The CD will play from the rst title. The track currently being
Random playback (RND) always begins
played,
u
or
u
MP3 are shown in the display.
with the rst track on the CD/MP3 CD.
NOTE:
Press four times: all functions are cancelled. The normal play
With CDs in MP3 format, the current track and the folder
mode is resumed.
are displayed alternately.
6. In order to remove a CD, please press the
STOP key (16),
Only for CDs in MP3 format
open the CD compartment
p
OPEN (2) and lift the CD out
Press once: the current track is repeated continuously
carefully.
(REP appears in the display).
Press twice : the selected folder of the MP3 CD is re-
Always keep the CD deck closed.
peated continuously (REP ALBUM appears
in the display).
NOTE:
Press three times : the whole CD is played continuously (REP
• If a disc is incorrectly inserted - or no disc has been
appears in the display).
inserted - the symbol “- - -” and the word “no” appear in the
Press four times : the display contains the word RND, MP3
display.
and the track number that is to be played
• Playback of CDs produced by the user cannot be guar-
rst. All tracks are played back in random
anteed due to the large variety of software and CD media
order.
available.
Press ve times : the function is deactivated and the CD is
played in the normal mode.
Description of the CD buttons
Folder selection only for MP3 CDs:
To navigate one folder up press and hold the button during
This key allows you to briey pause playback. The
u
icon and
playback. F 01 will ash on the display. Press SKIP DOWN /
the current track are ashing on the display. Pressing again
SKIP UP to select the desired folder. CD playback starts auto-
continues playback.
matically. On pressing the button in stop mode, the display will
also ash. Press the PLAY/PAUSE button to start playback.
With an audio CD or a CD in MP3 format playing:
Programmed Play
With
SKIP UP you can jump to the next or previous track etc.
• If the button is kept pressed down, the machine starts to
This can be used to program any desired sequence of tracks.
search through the tracks.
1. Press the
STOP key (16).
2. Press the PROGRAM key (18). The number “P01” (storage
The SKIP DOWN button can be used as follows:
location) and the symbol PROG ash in the display. Use the
Press once = This jumps back to the previous track.
SKIP DOWN / SKIP UP buttons (21/20) to select the
Press twice = This plays the song before etc. If the button is
desired track and then press the PROGRAM button again.
kept pressed down, the machine starts to search
The display changes to memory slot P02.
through the tracks.
3. Select the next track with the
SKIP DOWN / SKIP UP
key and press the PROGRAM key again. Repeat the
procedure until all the desired tracks are selected.
Press briey:
NOTE:
The CD stops.
Once the storage capacity of the tracks to be programmed
Press long:
has been reached, “FUL” ashes in the display.
The USB connection or the card slot will be selected.
4. Press the
u
PLAY/PAUSE key (25). The playback starts.
The selected track numbers are shown in the display in the
MODE
correct order and the symbol
u
or
u
MP3 and PROG. light
Press once: (the REP emits a xed light) the current
up. Press this button to pause briey the playback.
track is repeated continuously.
5. Press once the STOP key (16) to stop the playback while
Press twice: (the REP
emits a xed light) the whole
retaining the program.
CD is played continuously.
6. To resume the playback of the program press rst the
PROGRAM key once and then the
u
PLAY/PAUSE.
ENGLISH
45
7. Press the STOP button twice to delete the program. The
NOTE: Compact Disks:
PROG icon on the display turns off.
• Always place the CD into the CD compartment with the
label facing upwards. Compact discs can only be played
The device stops automatically once the entire sequence of pro-
on one side.
grammed tracks is completed. The programmed order of tracks
• Fingerprints and dust should be carefully removed from
remains in the memory until you change to a different mode,
the recorded side of the CD (the side without the label)
remove the CD from the CD compartment or switch off the
with a soft cloth. Wipe off in straight lines from the centre to
device.
the edge.
• After being played, CDs should be returned to their case
It is also possible to combine the programmed tracks with the
so that they do not become scratched.
REPEAT function. After you have programmed and started the
• Do not expose CDs to direct sunlight, high humidity levels
device, please press the MODE button (17) up to three
or prolonged high temperatures in order to prevent them
times and then you can use the functions as described under
from warping.
“MODE”.
• Do not adhere any paper to the CD or write on it.
• Do not spray any cleaning agents or antistatic sprays on to
Playing back Music in MP3 Format
the CD as in the case of phonographs.
With this device it is possible to play back pieces of music in
MP3 format. The device also supports all standard CD types:
CD, CD-RW, CD-R.
Troubleshooting
This machine of is able to play MP3 CDs. Up to 200 tracks can
Symptoms Course Solution
be compressed and stored on these CDs. Your machine detects
CD can not be
CD is not inserted
Ensure that the disc is
an MP3 CD automatically (the total number of tracks
played back.
or inserted incor-
inserted with the label
and MP3s appears in the display). If you would like to play one
rectly.
facing upwards.
of these CDs, proceed as described under “Playing CDs/MP3”.
Batteries too weak. Insert new batteries or
Tracks can be programmed as described under “Programmed
operate the device with
Play”.
the mains lead.
CD jumps dur-
Check the disc for
Check the disc for nger-
Please note:
ing playback.
ngerprints, dirt or
prints, dirt or scratches.
There are a number of different recording and compression
scratches.
methods, as well as quality differences between CDs and
The unit cannot
The unit is blocked
Pull the mains plug for
selfrecorded CDs.
be operated
and “hangs”
approximately 5 seconds.
Furthermore, the music industry does not adhere to xed stand-
Then connect the unit
ards (copy protection).
again
For these reasons it is possible that in rare cases there are
problems with the playback of CDs and MP3 CDs. This is not a
malfunction of the device.
Model: ............................................................. SRP 4335 CD/MP3
Power supply: .............................................................230 V, 50 Hz
Cleaning and Maintenance
Battery operation: ........................................10 x 1.5 V UM 1/R 20
Power consumption: ...............................................................25 W
• Always remove the mains plug before cleaning the machine.
Output rating: ............................................................400 W PMPO
• Any marks on the surface can be wiped off with a slightly
Protection class: ............................................................................II
damp cloth without any additives.
Radio section:
NOTE: Compact Disks:
Frequency ranges: ............................. VHF / FM 88 ~ 108.0 MHz
• This device is able to play CDs with a diameter of 8 cm
.............................. MW / AM 540 ~ 1600 kHz
and 12 cm.
Net weight: ...........................................................................5.40 kg
NOTE:
Subject to technical changes without prior notice!
Only place one disc in the CD compartment at a time.
This device was tested according to all relevant current CE
• Only audio CDs, CD-R and CD-RW disks can be played
directives, such as electromagnetic compatibility and the low
on this machine.
frequency directive, and was manufactured according to the
latest safety regulations.
46
ENGLISH
Disposal/Meaning of the “Dustbin” Symbol
Protect our environment: do not dispose of electrical equipment
in the domestic waste.
Please return any electrical equipment that you will no longer
use to the collection points provided for their disposal.
This helps avoid the potential effects of incorrect disposal on the
environment and human health.
This will contribute to the recycling and other forms of reutilisa-
tion of electrical and electronic equipment.
Information concerning where the equipment can be disposed of
can be obtained from your local authority.
