AEG BMG 5611: English

86

English

When the LCD shows the battery symbol , replace all batteries with new ones.

Rechargeable batteries are not suitable for this monitor.

Remove the batteries if the monitor will not be used for a month or more to avoid

relevant damage of battery leakage.

Do not let battery fluid get into your eyes. If it should get in your eyes, immedi-

ately rinse with plenty of clean water and contact a physician.

The monitor, the batteries and the cuff, must be disposed of according to local

regulations at the end of their usage.

2. CLOCK AND DATE ADJUSTMENT

a. Once you install the battery or turn off the monitor, it will enter Clock Mode, and

LCD will display time and date by turns. See Fig. 2 & 2-1.

Fig. 2 Fig. 2-1 Fig. 2-2

b. While the monitor is in Clock Mode, pressing the “START” button and the “MEM”

button simultaneously; a beep is heard and the month will flash first. See Fig. 2-2.

Press the button “START” repeatedly; the day, the hour and the minute will flash in

turn. While a number is flashing, press the button “MEM” to increase the number.

Hold the button “MEM” depressed, the number will increase rapidly.

c. You can turn off the monitor by pressing the “START” button when the minutes are

flashing, then the time and the date are confirmed.

d. The monitor will turn off automatically after 1 minute of no operation; with the time

and date unchanged.

e. After replacing the batteries, you should set the time and the date again.

3. CONNECTING THE CUFF TO THE MONITOR

Insert the cuff tubing connector into the socket in the left side

of the monitor. Make certain that the connector is completely

inserted to avoid air leakage during blood pressure

measurements.

Avoid compression or restriction of the connection tubing during measurement, as

this may cause an inflation error or harmful injury due to continuous cuff pressure.

87

English

4. APPLYING THE CUFF

a. If required, pull the cuff end through the medal loop

(the cuff is packaged like this already).

b. Place the cuff around a bare arm 1 to 2 cm above the

elbow joint.

c. While sitting, place your hand with the palm facing up

onto a flat surface like a table or similar. Position the air

tube in the middle of your arm in line with your middle

finger

d. Tighten the cuff and close the Velcro fastener. The cuff should fit comfortably,

yet snugly around your arm. You should be able to insert one finger between

your arm and the cuff.

Note:

1. Please refer to the cuff circumference range in “SPECIFICATIONS” to make

sure that the appropriate cuff is used.

2. Measuring on same arm each time.

3. Do not move your arm, body, or the monitor and do not move the rubber

tube during measurement.

4. Stay quiet, calm for 5 minutes before blood pressure measurement.

5. Please keep the cuff clean. If the cuff becomes dirty, remove it from the moni-

tor and clear it by hand in a mild detergent, then rinse it thoroughly in cold

water. Never dry the cuff in clothes dryer or iron it. Clean the cuff after the

usage of every 200 times is recommended.

5. BODY POSTURE DURING MEASUREMENT

Sitting Comfortably Measurement

a. Be seated with your feet flat on the floor, and don’t cross

your legs.

b. Place palm upside in front of you on a flat surface such as

table.

c. The middle of the cuff should be at the level of the right atrium of the heart.

Lying Down Measurement

a. Lie on your back.

b. Place your arm straight along your side with your palm

upside.

c. The cuff should be placed at the same level as your heart.

88

English

6. TAKING YOUR BLOOD PRESSURE READING

a. After applying the cuff and with your body in a comfortable position, press the

“START” button. A beep is heard and all display characters are shown for self-

test. See Fig. 6. Please contact the service center if a segment is missing.

b. Then the current memory bank (U1 or U2) is flashing. See Fig. 6-1. Press the

“MEM” button to change to the other bank. See Fig. 6-2. Confirm your selec-

tion by pressing the “START” button. The current bank will also be confirmed

automatically after 5 seconds with no operation.

Fig. 6

Fig. 6-1 Fig. 6-2

c. After selecting the memory bank, the monitor starts to seek zero pressure. See

Fig. 6-3.

d. The monitor inflates the cuff until sufficient pressure has built up for a measure-

ment. Then the monitor slowly releases air from the cuff and carries out the

measurement. Finally the blood pressure and pulse rate will be calculated and

displayed on the LCD screen separately. Irregular heartbeat symbol (if any) will

blink. See Fig. 6-4 & 6-5. The result will be automatically stored in the current

memory bank.

Fig. 6-3

Fig. 6-4 Fig. 6-5

e. After measurement, the monitor will turn off automatically after 1 minute of

no operation. You can also press the “START” button to turn off the monitor

manually.

f. During measurement, you can press the “START” button to turn off the moni-

tor manually.

Note:

Please consult a health care professional for interpretation of pressure measure-

ments.

89

English

7. DISPLAYING STORED RESULTS

a. After the measuring, you can review the measurements in the current memory

bank by pressing the button “MEM”. Now the LCD displays the amount of the

results in the current bank. See Fig. 7.

Fig. 7

Fig. 7-1 Fig. 7-2

b. You can also press the “MEM” button in Clock Mode to display the stored

results. The current memory bank will flash and the amount of results in this

bank will be displayed. See Fig. 7-1. Press the “START” button to change to

the other bank. See Fig. 7-2. Confirm your selection by pressing the “MEM”

button. The current bank will also be confirmed automatically after 5 seconds

with no operation.

c. After selecting the memory bank, the LCD will display the average value of

the last three results in this bank. See Fig. 7-3 & 7-4. If no results are stored, the

LCD will show dashes as shown in Fig. 7-5.

Fig. 7-3

Fig. 7-4 Fig. 7-5

d. When the average is displayed and you press the “MEM” button, the most

recent result will be displayed. See Fig. 7-6. Then the blood pressure and the

pulse rate will be shown individually. Possibly the irregular heartbeat symbol

may flash. See Fig. 7-7 & 7-8. Press the “MEM” button again to display the

next result. See Fig. 7-9. In this way, repeatedly pressing the “MEM” button

displays the respective results measured previously.

Fig. 7-6

Fig. 7-7
