Pioneer PD-D9MK2-K: Connecting up

Connecting up02

Chapter 2

Connecting up

For a coaxial connection, use a coaxial cable

Connecting to an amplifier

(not supplied) to connect the COAXIAL

DIGITAL OUT jack to a coaxial input on your

You can connect this player to your amplifier or

amplifier.

receiver using the analog outputs or one of the

digital outputs.

• Note that SACD audio is not output

through these jacks, so this connection

If you connect using one of the digital outputs,

should be in addition to, rather than

you should also connect the 2 channel analog

instead of, an analog connection.

outputs for compatibility with all discs.

1 Connect the analog LINE OUT jacks on this

player to a set of analog audio inputs on your

Using the remote sensor of

amplifier.

another Pioneer component

Many Pioneer components have SR CONTROL

jacks which can be used to link components

together. This allows you to use the remote

sensor of just one component, which is useful

if you want to put several components out of

view (for example, in a closed shelf space).

When you use a remote control, the control

signal is passed along the chain to the

1

appropriate component.

• Note that if you use this feature, make sure

that you also have at least one set of analog

audio jacks connected to another

component for grounding purposes.

1 Decide which component you want to use

the remote sensor of.

When you want to control any component in

the chain, this is the remote sensor at which

you’ll point the corresponding remote control.

2 Connect one of the digital outputs to the

corresponding digital input on your amplifier.

For an optical connection, use an optical cable

(not supplied) to connect the OPTICAL

DIGITAL OUT jack to an optical input on your

amplifier.

8

En

PD-D9MK2_SYXJ5.book 8 ページ ２００９年４月１５日　水曜日　午後６時９分

1 If you have connected a remote control to the CONTROL IN jack (using a mini-plug cable), you won’t be able to control this

unit using the remote sensor.

PD-D9MK2_SYXJ5.book 9 ページ ２００９年４月１５日　水曜日　午後６時９分

Connecting up 02

2 Connect the

CONTROL OUT

jack of that

English

component to the

CONTROL IN

jack of

another Pioneer component.

Use a cable with a mono mini-plug on each

end for the connection.

Pioneer componentPioneer component

CONTROL

CONTROL

IN OUT

IN

OUT

Deutsch Italiano EspañolFrançais

Nederlands

AC IN

CONTROL

IN

OUT

This player

3 Continue the chain in the same way for as

many components as you have.

Plugging in

Make sure to complete all connections before

connecting to an AC outlet.

• Connect the AC power cord to the AC IN

inlet on the rear panel of the player, then

plug into a power outlet.

9

En
