AEG SRP 4342 CD-MP3: English

English

41

Overview of the components

1 CD compartment

2 CD tray lock (OPEN/LOCK)

3 VOLUME control (volume)

4 LCD display

5 IR sensor for the remote control

6 REPEAT button

7

button (Stop)

8

button (play/pause)

9 / buttons (search forward/backwards)

10 PROG button (Memory)

11 Memory card slot

12 AUX IN jack

13 USB connection

14 FOLDER+ button (folder upward)

15 MUTE button

16 FOLDER- button (folder downward)

17

STANDBY/ON button (standby/power)

18 EQ button (Equalizer)

19 MODE function switch

20 BASS control

21 Nylon handle mounting

22 Telescopic antenna

A Speaker

Rear view (not shown)

POWER ON/OFF switch

DC IN 12 V Power supply connection

Battery compartment

Remote control

1

STANDBY button

2 FM button (radio)

3 AUX IN button

4 PROG button (Memory)

5 PRESET utton (radio memory)

6 ID3 button

7 EQ button

8 / SKIP/TUNING UP button (search forward)

/ SKIP/TUNING DOWN button (search backwards)

9 STOP / FM MONO/ST button

10 VOLUME +/- (volume) button

11 PLAY/PAUSE

button

Installation/Introduction

• Readthemanualthoroughlybeforeoperatingthede-

vice!

• Selectasuitablelocationforthedevice.Suitableloca-

tions are dry, even and anti-slip surfaces on which you

may operate the device easily.

• Makesurethereisproperventilationforthedevice!

• Remove,ifnecessary,theprotectionsheetfromthe

display.

WARNING:

Turning up the volume too high may damage your hearing.

Power supply

• Insertthegridplugintoaproperlyinstalledthreeprong

socket with 230 V, 50 Hz. Connect the device with the

plug connector by inserting its plug into the IN 12 V jack

of the device.

• Makesurethegridvoltagecorrespondstothegureson

the rating plate.

CAUTION:

• TheincludedACadaptermayonlybeusedwiththis

device. Do not use it for other devices.

• UseonlyanACadapterwith12V(

). A differ-

ent AC adapter may damage the unit.

• Themainsplugshallremainreadilyoperable.

• Thedirectplug-inadapterisusedasthedisconnect

device, the disconnect device shall remain readily

operable

NOTE:

• Disconnectfrommainspowersupplyduringlonger

periods of non-use.

• Thepresettimeandstationislostassoonasthepower

supply has been interrupted.

Battery Operation (Batteries not supplied)

• Openthelidofthebatterycompartmentontherear

side.

• Insertthe10batteriestypeUM1/R201.5V.Observethe

correctpolarity(seebottomofbatterycompartment)!

• Closethebatterycompartment.

Should the device not be used for a long periods, remove

12 RANDOM button (random playback)

the batteries, to prevent any “leakage”.

13 REPEAT button

NOTE:

14 FOLDER +/- buttons (Album selection)

• Ifamainscableisconnected,thebatteriesareauto-

15 MUTE button

matically switched off.

16 CD/USB/SD button

• Thepresettimestationislostassoonasyouremove

the batteries.
