AEG KRC 4355 CD: English

36

English

7 F.FWD button (scan forwards)

• Thewallmountingofthecupboardmustbestableand

8 STOP button (stop)

anchored firmly in the wall with at least 2 screws.

9 OPEN/CLOSE button (open/ close CD tray)

• Important! Do not install the device above a cooker!

10 PLAY/PAUSE button (play/pause)

• Wheninstallingthedeviceitmustbeensuredthatthere

11 TUNING control

is a power socket within reach.

12 STANDBY/AL.OFF button (on/standby / alarm off)

• Themainssocketmustbewithineasyreach,sothatthe

13 FUNCTION button (function)

plug can be quickly removed in an emergency.

14 MUTE button (mute)

• Important! Do not connect the device to the mains

15 ALARM SET button (set alarm)

power supply until after installation!

16 TIME SET button (set time)

• Thedevicecannotbeinstalledundercupboardsunder

17 SLEEP/SNOOZE button (sleep timer/ snooze)

which there is a lighting strip.

18 M button (memory upwards)

• Formounting,youmayneedthefollowingsupplies:

19 M button (memory downwards)

Reamer or nail, screwdriver, measuring tape, adhesive

20 LCD display

tape, scissors, safety goggles.

Rear side (not shown)

Supplied mounting accessories

Power cord

1 Drilling template

Wire antenna

3x3screws(differentlengths)

AUXINjack(2xRCA)

3x3spacers(differentsizes)

WARNING:

Bottom side (not shown)

Screws that are driven in too far (screws that are too long)

Battery compartment

can damage the device or can result in danger to life.

Remote control

CAUTION:

21 MEM/PROG button

• Pleaseadheretothedimensionsstatedintheinstalla-

22

button

tion instructions.

23 REPEAT button

• Youshoulduseonlytheinstallationaccessoriessup-

24 button

plied.

25 AL.SET button

26 OPEN/CLOSE button

Installation

27 FUNCTION button

1. Tape the template into the cabinet with adhesive tape.

28 SLEEP button

With the help of a gimlet or nail pierce the crosses at the

29 SNOOZE button

attachment points and use it to mark the holes.

30 TIME SET button

2. Remove the template and drill the holes into the wall-

31 M button

mounted cabinet.

32 M button

3. Stick the spacers into the provided mounting brackets on

33 (increase volume)

the device.

(decrease volume)

/

(scanforward/nextsong)

NOTE:

/

(scan backwards/ previous song)

Adequate ventilation is only guaranteed with spacers.

34 button

4. Countersink the screws into the holes in the cabinet.

35 button

5. Select the screws according to the spacers used. Fasten

the kitchen radio to the bottom of the cabinet with the 3

Sub-structure assembly instructions

screws and the spacers.

6. Tighten the screws finger tight with a screwdriver.

If you don’t want to use the device as a standalone appliance,

then please assemble it as follows:

CAUTION:

• Removeallobjectsfromthecupboardandanything

Use a screwdriver and not a cordless screwdriver.

which is fragile in the adjacent cupboards.

• Fortheinstallationthecupboardmustfullthefollowing

Start-up of the device / Introduction

conditions:

Thicknessofthecupboardoor

NOTE:

between 16 mm and 20 mm.

You will find some buttons on both the device and the

remote control. Identical buttons fulfil the same function.
