AEG BSB 18 LI: 18 19 ENGLISH ENGLISH

TECHNICAL DATA Cordless percussion drill/driver

BSB 18

EC-DECLARATION OF CONFORMITY

SYMBOLS

Drilling capacity in steel ...........................................................

...........................13 mm

We declare under our sole responsibility that this product is

Drilling capacity in wood ..........................................................

...........................55 mm

in conformity with the following standards or standardized

Please read the instructions carefully before

Drilling capacity in brick and tile ..............................................

...........................16 mm

documents.

starting the machine.

Wood screws (without pre-drilling) ..........................................

.............................8 mm

EN 60745-1:2009 + A11:2010

-1

No-load speed 1st gear ...........................................................

......................0-450 min

EN 60745-2-2:2010

-1

No-load speed 2nd gear ..........................................................

....................0-1600 min

EN 55014-1:2006 + A1:2009 + A2:2011

-1

Rate of percussion under load 1st gear. ..................................

.......................7200 min

EN 55014-2:1997 + A1:2001 + A2:2008

Remove the battery pack before starting any

-1

Rate of percussion under load 2nd gear..................................

.....................25600 min

in accordance with the regulations

work on the machine.

Torque (1.5 Ah Battery)*1 ........................................................

...........................70 Nm

2011/65/EU (RoHs)

Torque (3.0 Ah Battery)*1 ........................................................

...........................70 Nm

2006/42/EC

Battery voltage.........................................................................

...........................18 V

2004/108/EC

Drill chuck range ......................................................................

.....................1,5-13 mm

Do not dispose of electric tools together with

Weight according EPTA-Procedure 01/2003 (1.5 Ah) .............

........................2,25 kg

household waste material! In observance of

Weight according EPTA-Procedure 01/2003 (3.0 Ah) .............

..........................2,5 kg

European Directive 2002/96/EC on waste

electrical and electronic equipment and its

Winnenden, 2012-09-06

implementation in accordance with national law,

Noise/vibration information

electric tools that have reached the end of their

Measured values determined according to EN 60 745.

life must be collected separately and returned to

Typically, the A-weighted noise levels of the tool are:

an environmentally compatible recycling facility.

Sound pressure level (K = 3 dB(A)) .......................................

........................87,5 dB (A)

Rainer Kumpf

Sound power level (K = 3 dB(A)) ............................................

........................98,5 dB (A)

Director Product Development

Wear ear protectors!

Authorized to compile the technical le

Total vibration values (vector sum in the three axes)

BATTERIES

determined according to EN 60745.

Vibration emission value a

h

New battery packs reach full loading capacity after 4 - 5

2

Impact drilling into concrete ..................................................

..........................8,3 m/s

chargings and dischargings. Battery packs which have not

2

Uncertainty K= ......................................................................

..........................1,5 m/s

been used for some time should be recharged before use.

2

Drilling into metal ..................................................................

..........................2,5 m/s

2

Temperatures in excess of 50°C (122°F) reduce the

Uncertainty K= ......................................................................

..........................1,5 m/s

2

performance of the battery pack. Avoid extended exposure

Screw driving ........................................................................

..........................0,5 m/s

2

to heat or sunshine (risk of overheating).

Uncertainty K= ......................................................................

..........................1,5 m/s

The contacts of chargers and battery packs must be kept

*1 Measured according to AEG Standard N 877318

clean.

For an optimum life-time, the battery packs have to be fully

WARNING

charged, after used.

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given

To obtain the longest possible battery life remove the battery

in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.

pack from the charger once it is fully charged.

The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

For battery pack storage longer than 30 days:

applications, with different accessories or poorly maintained, the vibration emission may differ. This may signicantly increase

Store the battery pack where the temperature is below 27°C

the exposure level over the total working period.

and away from moisture

Store the battery packs in a 30% - 50% charged condition

An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or

Every six months of storage, charge the pack as normal.

when it is running but not actually doing the job. This may signicantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

BATTERY PACK PROTECTION LI-ION BATTERY

accessories, keep the hands warm, organisation of work patterns.

The battery pack has overload protection that protects it

from being overloaded and helps to ensure long life.

Under extreme stress the battery electronics switch off the

WARNING! Read all safety warnings and all

Do not store the battery pack together with metal objects

machine automatically. To restart, switch the machine off

instructions, including those given in the accompanying

(short circuit risk).

and then on again. If the machine does not start up again,

brochure. Failure to follow the warnings and instructions

Use only System GBS chargers for charging System GBS

the battery pack may have discharged completely. In this

may result in electric shock, re and/or serious injury.

battery packs. Do not use battery packs from other systems.

case it must be recharged in the battery charger.

Save all warnings and instructions for future reference.

Battery acid may leak from damaged batteries under

MAINTENANCE

extreme load or extreme temperatures. In case of contact

SAFETY INSTRUCTIONS

with battery acid wash it off immediately with soap and

Use only AEG accessories and spare parts. Should

Wear ear protectors when impact drilling. Exposure to

water. In case of eye contact rinse thoroughly for at least 10

components need to be replaced which have not been

noise can cause hearing loss.

minutes and immediately seek medical attention.

described, please contact one of our AEG service agents

Use auxiliary handle(s), if supplied with the tool. Loss of

(see our list of guarantee/service addresses).

control can cause personal injury.

SPECIFIED CONDITIONS OF USE

If needed, an exploded view of the tool can be ordered.

Hold power tool by insulated gripping surfaces, when

The electronic battery percussion drill/screwdriver may be

Please state the Article No. as well as the machine type

performing an operation where the cutting accessory

used for drilling, percussion drilling, as well as screwdriving

printed on the label and order the drawing at your local

may contact hidden wiring. Cutting accessory contacting

for independent use away from mains supply.

service agents or directly at: AEG Electric Tools GmbH,

a „live“ wire may make exposed metal parts of the power

Max-Eyth-Straße 10, D-71364 Winnenden, Germany.

Do not use this product in any other way as stated for

tool „live“ and could give the operator an electric shock.

normal use.

Sawdust and splinters must not be removed while the

machine is running.

When working in walls ceiling, or oor, take care to avoid

electric cables and gas or waterpipes.

Remove the battery pack before starting any work on the

machine.

Do not dispose of used battery packs in the household

refuse or by burning them. AEG Distributors offer to retrieve

old batteries to protect our environment.
