Samsung PS51F8500SL: Using the Smart Touch Control

English - 5

English

 Basic  Features

 Using the Smart Touch Control

TV

MIC

STB

SOURCE

VOICE

MORE

SMART HUB

GUIDE

RETURN

EXIT

MUTE

AD

 VOICE

˜

 Take your voice command and enter a text

using your voice.

 You can use the MIC to give

Voice Recognition

 commands. Simply press the

VOICE

˜

 button.

✎

 Voice Recognition

function can be affected by unclear pronunciation, voice level, or surrounding noise.

 Changes  channels.

 View each digital channel's programming

schedule, including showtimes. In addition,

sets a

Schedule Viewing

 or

Schedule

Recording

 to press the touchpad on the

programme entry scheduled to air later.

 Turn on and off the satellite or cable set-top

box connected to the TV. For this, the Smart

Touch Control must be confi gured as a

universal remote control.

 Turns the TV on and off.

 Displays and selects the available video

sources.

 Adjusts the volume.

Cuts off the sound

temporarily.

 Press and hold this button

to select

Audio Description

and

Subtitle

. (Depending on

the country or region.)

 Returns to the previous menu. Press and

hold this button to exit all currently running

applications.

 Brings up Smart Hub applications. See the

e-Manual chapter,

Smart TV Features

 >

Smart Hub

.

✎

 To exit an application that is running,

press the

™

 button.

TV

MIC

STB

SOURCE

VOICE

MORE

SMART HUB

GUIDE

RETURN

EXIT

MUTE

AD

 Toggles this button between Recommended

and Search.

 Connecting to the TV

 In order to operate the TV using a Smart Touch Control, you must fi rst pair it to the TV via Bluetooth. However, the Smart Touch Control is only available

for the paired Samsung TV.

 1.

When the TV is off, point the Smart Touch Control at the remote control receiver of the TV and press the TV button for the fi rst pairing. Only this

buttons sends an IR signal. The remote control receiver's location may vary depending on the model.

 2.

A Bluetooth icon will appear at the bottom left of the screen as shown below. The TV will then attempt to connect to the Smart Touch Control

automatically.

 <Attempting to connect and completion icons>

 Reconnecting the Smart Touch Control

 <The Smart Touch Control's pairing button>

 If you need to reestablish the connection between the TV and the Smart Touch Control, press the pairing button at the back

of the Smart Touch Control toward the Remote receiver of the TV. The pairing button can be accessed by removing the Smart

Touch Control's battery cover. Pressing the pairing button automatically reestablishes the connection between the Smart Touch

Control and the TV.

 TouchPad

•

 Drag on the touchpad to move the focus

on the screen.

•

 Press the touchpad to run, activate, or

select the highlighted item.

•

 Press and hold the touchpad to display

the

Channel List

.

 Displays a virtual remote panel on the screen.

See the e-Manual chapter,

Controlling TV

>

Using the Virtual Remote Control.

 Press and hold the touchpad to select a

desired function (e.g.

MENU

 (

m

),

TOOLS

 (

T

),

INFO

 (

`

), etc.) easily.

 The colour buttons work differently, depending

on the function that the TV is currently

performing.

Press and hold the

{

 button while watching

TV to view information about the current

programme.

[PF8500-XH]BN68-04828G_01L16.indb   5

2013-03-16     7:05:19

English - 6

Battery Low Alarm

If the battery becomes and blanks low while using the Smart Touch Control, the following alarm window blinks and appears at the

bottom left of the screen. If the alarm window pops up, replace the batteries of the Smart Touch Control. Use alkaline batteries for

longer usage.

Inserting the Batteries (AAA X 2)

1.

Slightly lift the battery cover by pulling the strap or

using a plastic card. Next, pull on the cover’s notch

with a fingernail to remove the cover completely.

2.

Insert 2 AAA batteries, making sure to align the

positive and negative ends correctly.

3.

Align the battery cover with the back of the remote

control and press down along the edges until it is

cleanly attached to the remote control.

1

2

3

Using the Touchpad

Use the touchpad to perform various commands. Navigate to

Tutorial

 (Screen Menu >

System

 >

Device Manager

 >

Smart Touch Control Settings

>

Tutorial

) to view an on-screen guide to using the Smart Touch Control.

Dragging

Press

Drag on the touchpad in the desired direction.

Move the focus or the pointer in the direction the finger is dragging.

Press on the touchpad. This selects the focused item. When watching TV,

pressing and holding the touchpad displays the channel list. On some apps,

pressing and holding the touchpad for over 2 seconds displays a list of functions

available for the app.

Changing Channels by Entering Numbers

While watching TV, tap on the protruding line on the left or right edge of the touchpad

to bring up the numerical input window on the screen. Use your finger to enter the

number for the channel you want to watch. The recognised number is displayed on the

screen and the TV switches to the corresponding channel. See the e-Manual chapter,

Controlling TV

 >

Touchpad

.

Numerical Input Guide

Refer to the diagrams below when entering numerical values. The TV may not recognise your entries if you do not

follow the sequences shown below.

[PF8500-XH]BN68-04828G_01L16.indb   6

2013-03-16     7:05:19

English - 7

English

Show Status and Notification Banner

Press the

MORE

 button on the Smart Touch Control and then select

STATUS

 on the virtual remote panel to display the

status and notification banner at the top of the screen.

Recommendations

Press the

RECOMM. / SEARCH

 button and then select

Recommended

 from the list displayed at the bottom of

the screen. Select a programme that is currently airing to jump to the corresponding channel or a programme that

is scheduled to air to set up a Schedule Viewing or Schedule Recording setting. Select an application to launch.

Samsung Apps will launch if the selected application is not installed on the TV.

History

Press the

RECOMM. / SEARCH

 button and then select

History

 from the list displayed at the bottom of the screen.

This displays an interactive list of recently accessed channels, media content and applications.

Deleting History Data

You can delete the history information about recently viewed channels, content and applications.

Searching

Press the

RECOMM. / SEARCH

 button on the Smart Touch Control. The list appears at the bottom of the screen.

Press the

RECOMM. / SEARCH

 button again. The keypad will appear on the screen. Enter search criteria to search

not only many apps and their contents on the TV but also the Web. This button toggles between

Recommended

 and

Search

.

Adjusting the Touchpad

Users can adjust the sensitivity of the Smart Touch Control’s touchpad. Set

Touch Sensitivity

 to adjust sensitivity and

make it more convenient to use.

Using the Virtual Remote Control

Press

MORE

 button to display the virtual remote panel on the screen. The virtual remote panel consists of a number

panel, a playback control panel, and a quick access panel. Use the touchpad to select numbers and buttons.

✎

The displayed virtual remote panel on the TV screen may differ depending on the country.

Changing the Virtual Remote Panel

Choose the number panel, playback control panel, or quick access panel as the panel to be shown on the screen.

Use the touchpad to keep moving the focus left or right. The panel changes when the focus is moved beyond the

leftmost or rightmost edge.

✎

Use left / right scroll function on the touchpad to change the panel easily.

Using the Number Panel

Use the number panel to enter numbers on a keypad screen or webpage or to change the channel while watching TV.

Changing the channel using the number pad leaves a record, allowing you to easily return to previous channels.

Using the Playback Control Panel

Use the playback control panel to pause, rewind, fast forward, skip to the next file, and much more while enjoying

media content.

Using the Quick Access Panel

Quickly access the

INFO

,

MENU

 and

e-Manual

buttons. However, the availability of buttons vary depending on the

operating mode of the Smart Touch Control unit (with the TV only, as a universal remote, etc.).

[PF8500-XH]BN68-04828G_01L16.indb   7

2013-03-16     7:05:20
