Samsung PS51F8500SL: Built-in TV Camera and Microphone

English - 10

Built-in TV Camera and Microphone

This TV features a built-in TV camera that can be used for the Motion Control, Voice Recognition (built-in microphone),

and Face Recognition features. You can also use the knob for camera's angle adjustment to change the camera's

viewing angle.

From the Top

From Behind

Microphone

Lens

Knob for camera's angle adjustment

Microphone

Extending the TV Camera

In order to use the TV camera, you must first extend it.

Gently push the camera in without touching the lens until you hear a click.

Retracting the Camera

If you are not using the TV camera, keep it retracted inside the TV. The Motion Control and Face

Recognition features cannot be used while the TV camera is in the retracted state, but Voice Recognition

will still be available.

Gently push the camera in without touching the lens until you hear a click.

경고 주의 경고 주의

Do not touch the lens while operating the TV camera. Leave

fingerprints that may affect the image quality. If the lens gets dirty,

clean it using a soft piece of cloth.
