Karcher PC 60-130 T: Warranty Spare parts Technical specifications

     -

8

The warranty terms published by our com-

petent sales company are applicable in

each country. We will repair potential fail-

ures of your accessory within the warranty

period free of charge, provided that such

failure is caused by faulty material or de-

fects in fabrication. In the event of a warran-

ty claim please contact your dealer or the

nearest authorized Customer Service cent-

er. Please submit the proof of purchase.

–

Only use accessories and spare parts

which have been approved by the man-

ufacturer. The exclusive use of original

accessories and original spare parts

ensures that the appliance can be oper-

ated safely and trouble free.

–

At the end of the operating instructions

you will find a selected list of spare

parts that are often required.

–

For additional information about spare

parts, please go to the Service section

at www.kaercher.com.

We hereby declare that the machine de-

scribed below complies with the relevant

basic safety and health requirements of the

EU Directives, both in its basic design and

construction as well as in the version put

into circulation by us. This declaration shall

cease to be valid if the machine is modified

without our prior approval.

The undersigned act on behalf and under

the power of attorney of the company man-

agement.

Authorised Documentation Representative

S. Reiser

Alfred Kärcher GmbH Co. KG

Alfred-Kärcher-Str. 28 - 40

71364 Winnenden (Germany)

Phone: +49 7195 14-0

Fax: +49 7195 14-2212

Winnenden, 2011/03/01

Warranty Spare parts Technical specifications

Electrical connection

Current type

3~

Frequency

Hz

50

Voltage

V

400

Connected load

kW

5,5

Type of protection

IP55

Performance data

Heating output

kW

4,5

Working pressure

MPa

(bar)

0,15

(1,5)

Flow rate

l/h

4560

Cleaning temperature °C

30...80

Cleaning time

min.

1...30

Content of detergent

solution container

l

100

Turntable diameter, in-

terior

mm

600

Usable height

mm

310

Load-bearing capaci-

ty of the turntable

kg

130

Noise emission

Sound pressure level

(EN 60704-1)

dB(A)

65

Dimensions and weights

Length

mm

1080

Width

mm

1000

Height

mm

1250

Unladen weight

kg

195

CE declaration

Product:

Machine for cleaning using

watery solutions

Type:

1.626-xxx

Relevant EU Directives

2006/42/EC (+2009/127/EC)

2004/108/EC

Applied harmonized standards

EN 12921 -1

EN 12921 -2

EN ISO 13732-1

EN ISO 13857

EN 60204–1

EN 55014–1: 2006 + A1: 2009

EN 55014–2: 1997 + A2: 2008

EN 61000–3–2: 2006 + A2: 2009

EN 61000–3–3: 2008

EN 62233: 2008

Applied national standards

-

CEO

Head of Approbation

18 EN
