Karcher ICC 1 D Adv: Contents Safety instructions

English

 21

Please read and comply with

these instructions prior to the

initial operation of your appliance. Retain

these operating instructions for future refer-

ence or for subsequent possessors.

Before first start-up it is definitely necessary

to read the safety indications Nr. 5.956-250!

Safety instructions

21

Function

21

Proper use

21

Environmental protection

22

Operating and Functional Elements

23

Before Commissioning

25

Start up

25

Operation

25

Shutdown

27

Maintenance and care

27

Accessories

35

Faults

36

Specifications

37

CE declaration

38

Warranty

38

Your sales outlet should be informed about

any transit damage noted when unpacking

the product.

Î

Please read the operating instructions

for your machine before using it, and

pay particular attention to the following

safety instructions.

– Warning and information plates on the

machine provide important directions

for safe operation.

– In addition to the information contained

in the operating instructions, all statuto-

ry safety and accident prevention regu-

lations must be observed.



Danger

Risk of injury!

Danger of tipping if gradient is too high.

–

The gradient in the direction of travel

should not exceed 20%.

Danger of tipping when driving round bends

at high speed.

–

Drive slowly when cornering.

Danger of tipping on unstable ground.

–

Only use the machine on sound surfac-

es.

Danger of tipping with excessive sideways

tilt.

–

The gradient perpendicular to the direc-

tion of travel should not exceed 10%.

– It is important to follow all safety instruc-

tions, rules and regulations applicable

for driving motor vehicles.

– The operator must use the appliance

properly. He must consider the local

conditions and must pay attention to

third parties, in particular children, when

working with the appliance.

– The appliance may only used by per-

sons who have been instructed in han-

dling the appliance or have proven

qualification and expertise in operating

the appliance or have been explicitly as-

signed the task of handling the appli-

ance.

– The appliance must not be operated by

children, young persons or persons who

have not been instructed accordingly.

– It is strictly prohibited to take co-passen-

gers.

– The appliance may only be started after

the operator has occupied the driver's

seat.

Î

Please remove the ignition key, when

not in use, to avoid unauthorised use of

the appliance.

Î

Never leave the machine unattended so

long as the engine is running.  The op-

erator may leave the appliance only

when the engine has come to a stand-

still, the appliance has been protected

against accidental movement, if neces-

sary, by applying the immobilization

brake and the ignition key has been re-

moved.



Danger

Risk of injury!

–

Do not close the exhaust.

–

Do not bend over the exhaust or touch it

(risk of burns).

–

Do not touch the drive motor (risk of

burns).

–

Exhaust gases are poisonous and haz-

ardous to health, do not inhale them.

–

The engine requires approx. 3-4 sec-

onds to come to a standstill once it has

been switched off. During this time, stay

well clear of the working area.

– Only use accessories and spare parts

which have been approved by the man-

ufacturer. The exclusive use of original

accessories and original spare parts en-

sures that the appliance can be operat-

ed safely and troublefree.

– At the end of the operating instructions

you will find a selected list of spare parts

that are often required.

– For additional information about spare

parts, please go to the Service section

at www.kaercher.com.

The following symbols are used in this op-

erating manual:



Danger

indicates an immediate threat of danger.

Failure to observe the instruction may result

in death or serious injuries.

몇

Warning

indicates a possibly dangerous situation.

Failure to observe the instruction may result

in light injuries or damage to property.

Note

indicates useful tips and important informa-

tion.

– The generated dust is bound through

water (1) that is sprayed.

– The side brushes (2) transport the dust

to the front of the suction opening (3).

– The suction blower (4) sucks in the

waste, chops it and transports it to the

waste container (5).

Use this appliance only as directed in these

operating instructions.

Î

The machine with working equipment

must be checked to ensure that it is in

proper working order and is operating

safely prior to use. Otherwise, the appli-

ance must not be used.

– This sweeper has been designed to

sweep dirt and debris from outdoor sur-

faces.

– The appliance should not be used in

closed rooms.

– The attachments are not approved for

public transport.  Please ask your dealer

for the equipment set for approval for

road traffic.

– The appliance can be used on public

roads only after an individual accept-

ance by an official regulatory body.

– The machine is not suitable for vacuum-

ing dust which endangers health.

– The machine may not be modified.

– Never vacuum up explosive liquids,

combustible gases or undiluted acids

and solvents. This includes petrol, paint

thinner or heating oil which can gener-

ate explosive fumes or mixtures upon

contact with the suction air. Acetone,

undiluted acids and solvents must also

be avoided as they can harm the mate-

rials on the machine.

– Do not sweep/vacuum up any burning

or glowing objects.

– The machine is only suitable for use on

the types of surfaces specified in the op-

erating instructions.

– The machine may only be operated on

the surfaces approved by the company

or its authorised representatives.

– The machine may not be used or stored

in hazardous areas. It is not allowed to

use the appliance in hazardous loca-

tions.

Contents Safety instructions

General notes

Drive mode

Appliances with combustion engine

Accessories and Spare Parts

Symbols in the operating instruc-

tions

Function Proper use
