Karcher BRC 45/45 C: Accessories and Spare Parts

10

English



Danger

Risk of injury and electrical shock! Repair

works may only be performed by the au-

thorised customer service.

–

Only use accessories and spare parts

which have been approved by the man-

ufacturer. The exclusive use of original

accessories and original spare parts en-

sures that the appliance can be operat-

ed safely and troublefree.

–

At the end of the operating instructions

you will find a selected list of spare parts

that are often required.

–

For additional information about spare

parts, please go to the Service section

at www.kaercher.com.

We hereby declare that the machine de-

scribed below complies with the relevant

basic safety and health requirements of the

EU Directives, both in its basic design and

construction as well as in the version put

into circulation by us. This declaration shall

cease to be valid if the machine is modified

without our prior approval.

The undersigned act on behalf and under

the power of attorney of the company man-

agement.

Alfred Kärcher GmbH Co. KG

Alfred Kärcher-Str. 28 - 40

D - 71364 Winnenden

Phone: +49 7195 14-0

Fax: +49 7195 14-2212

The warranty terms published by our com-

petent sales company are applicable in

each country. We will repair potential fail-

ures of your appliance within the warranty

period free of charge, provided that such

failure is caused by faulty material or de-

fects in fabrication. In the event of a warran-

ty claim please contact your dealer or the

nearest authorized Customer Service cent-

er. Please submit the proof of purchase.

Accessories and Spare Parts

Accessories

Part no.:

Brush, standard

8.621-605.0

Brush, natural, soft

8.629-525.0

Manual nozzle

4.130-163.0

Spray/suction hose

4.440-644.0

Technical specifications

Performance data

Nominal voltage

V

220...

240

Frequency

Hz

50/60

Maximum allowed net

impedance

Ohm

0.387+j

0.242

Rated power (max.)

W

1725

Suction engine output

W

1100

Brush engine output

W

600

Speed of front brush

roller

1/min

1050

Speed of rear brush

roller

1/min

875

Detergent solution

without vacuuming

I/min

0,3...

0,4

Detergent solution

with vacuuming

I/min

3,5

Dimensions and weights

Working width

mm

406

Brush diameter

mm

86

Width

mm

559

Length

mm

1029

Height without push-

ing handle

mm

1092

Unladen weight

kg

ap-

prox.

75

Noise emission

Sound pressure level

(EN 60704-1)

dB(A)

73,7

Machine vibrations

Vibration total value

(ISO 5349)

m/s

2

0,671

CE declaration

Product:

Spray extraction device

Type:

1.008-xxx

Relevant EU Directives

2006/95/EC

2004/108/EC

Applied harmonized standards

EN 55014–1: 2006

EN 55014–2: 1997 + A1: 2001

EN 60335–1

EN 60335–2–68

EN 61000–3–2: 2000 + A2: 2005

EN 61000–3–3: 1995 + A1: 2001 + A2:

2005

Applied national standards

-

Warranty

CEO

Head of Approbation
