Appendix B: Specifications for PAL Standard

Item Details

Product type CCTV color dome camera

Power input AC 24V ± 10% (50Hz ± 0.3 Hz), DC 12V +10%/-5%

Broadcast type

PAL Standard System (625 Lines, 50 Fields)

Power consumptio

n Approx. 1.7W

Image device 1/3 inch IT

Type Super-HAD CCD

Total: 795(H) x 596(V), 470,000 pixels

Pixels

Effective: 752(H) x 582(V), 440,000 pixels

Scanning mod

e 625 Lines, 2:1 Interlace

Horizontal: 15.625Hz(INT)/1

5.625Hz(LL)

Scanning line frequency

Vertical: 50Hz(INT)/50Hz(LL)

Synchronization mod

e INT/Line Lock (Adjusting the phase using INC/DEC button)

Horizontal resolutio

n 540 TV Lines

S/N Ratio Approx. 50dB

SCC-B5355 (Color/BW

) SCC-B5354 (Color/BW)

50IR

E 0.4/0.04Lux 0.4/0.4Lux

Sens-up O

ff

30IR

E 0.24/0.024Lux 0.24/0.24Lux

Min. object illumination

15IR

E 0.12/0.012Lux 0.12/0.12Lux

F1.2

50IR

E 0.0031/0.00031Lux 0.0031/0.0031Lux

Sens-up x128

30IR

E 0.0019/0.00019Lux 0.0019/0.0019Lux

15IR

E 0.0009/0.00009Lux 0.0009/0.0009Lux

Signal output

COMPOSITE Video(1

.

0 Vp-p, 75ohm, BNC), Test Monitor OUT(1

.

0 Vp-p, 75ohm, Harness cable)

Lens Auto Iris (DC) / Focal length: 2.9 ~ 10.0mm / Aperture ratio: 1.2

PAN function Range: 0 to 355° (100 degree clockwise and 255 degree counterclockwise)

TI

LT function Range: 0 to 90°

Line Lock (LL)

Sens-Up; Low Speed Shutter(LSS)

Horizontal Reverse (H-REV)

Vertical Reverse (V-REV)

Backlight compensation (BLC)

Controls

Flickerless (FL)

Switching between color and B&W modes (D/N)

Auto white balancing (AWB)

Digital noise reduction (DNR)

Dynamic CCD defect compensation

Product color SCC-B535xP : White / SCC-B535xSP : Dark Silver

Operation temperatur

e -10°C to +50°C

Operation humidit

y Up to 90%

Size 128(Ø) x 91(H)mm

Weight 327g

AB68-00687E_Eng.indd 15 2007-08-06 ｿﾀﾈﾄ 2:09:27

AB68-00687E_Eng.indd 16 2007-08-06 ｿﾀﾈﾄ 2:09:27

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate

collection systems)

This marking shown on the product or its literature, indicates that it should

not be disposed with other household wastes at the end of its working life. To

prevent possible harm to the environment or human health from uncontrolled

waste disposal, please separate this from other types of wastes and recycle it

responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this

product, or their local government office, for details of where and how they can

take this item for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions

of the purchase contract. This product should not be mixed with other commercial

wastes for disposal.
