Philips SBC HC130: Installation Audio Connections

Installation Audio Connections

6

English

Headphone battery

replacement (figure 3)

1

Open the headphone’s battery

compartment.

2

Take out the batteries and dispose of them

properly.

3

Insert new batteries.

4

Make sure the batteries are correctly

inserted as indicated by the engraved

symbols in the battery compartment.

5

Close the battery compartment.

Audio Connections

Connecting the FM transmitter to a

headphone output of an audio

source (figure 4)

1

Connect the 3.5 mm stereo plug of the

stereo audio cable to the headphone

output of an audio source, such as TV, HiFi

or PC.

– In case your audio source has a 6.3 mm

headphone output, use the supplied

3.5 mm to 6.3 mm stereo adapter plug.

2

Switch on your audio source and carefully

increase the volume of the audio source.

3

Switch on the headphone and the

transmitter.

4

Adjust the volume to the desired level with

the headphone volume control.

Basic operation

When the IR transmitter is connected to a

headphone output of an audio source.

1

Switch on your IR transmitter and place it

at the same height or slightly higher than

the reception height of the IR headphone.

2

Position the LED’s towards the listening

area, ensuring that there are no obstacles in

between transmitter and headphone.

3

Switch on the headphone.

4

Switch on your audio source and carefully

increase the volume of the audio source.

5

Adjust the volume of the IR headphone to

the desired level with the headphone

volume control.

IMPORTANT

Because IR light travels in a straight

line, place the IR transmitter at the

same height, or slightly higher than the

reception height of the IR headphone.

High IR light content such as sunlight

and bright incandescent indoor lighting

may degrade the audio signal and

cause interference. If you experience

such problems, simply move the system

to a darker area.
