Philips PowerPro Uno Akku-Staubsauger: инструкция

Always here to help you

Register your product and get support at

www.philips.com/welcome

FC6170

FC6164

User manual

1 2 3 4

5 6 7

ENGLISH 6

ČEŠTINA 9

DANSK 12

DEUTSCH 15

ΕΛΛΗΝΙΚΑ 18

ESPAÑOL 21

SUOMI 24

FRANÇAIS 27

HRVATSKI 30

MAGYAR 33

ITALIANO 36

ҚАЗАҚША 39

LIETUVIŠKAI 42

LATVIEŠU 45

NEDERLANDS 48

NORSK 51

POLSKI 54

PORTUGUÊS 57

ROMÂNĂ 60

РУССКИЙ 63

SLOVENSKY 66

SLOVENŠČINA 69

SVENSKA 72

УКРАЇНСЬКА 75

FC6170, FC6164

6

ENGLISH

Introduction

Congratulations on your purchase and welcome to Philips! To fully benet from the support that

Philips offers, register your product at www.philips.com/welcome.

Important

Read this important information carefully before you use the appliance and

save it for future reference.

Danger

- Never vacuum up water or any other liquid. Never vacuum up

ammable substances and do not vacuum up ashes until they are cold.

- Never immerse the appliance or the adapter in water or any other liquid,

nor rinse it under the tap.

Warning

- Check if the voltage indicated on the adapter corresponds to the local

mains voltage before you connect the appliance.

- Do not use the vacuum cleaner or the adapter if it is damaged.

- If the adapter is damaged, always have it replaced with one of the

original type in order to avoid a hazard.

- The adapter contains a transformer. Do not cut off the adapter to

replace it with another plug, as this causes a hazardous situation.

- This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand

the hazards involved. Children shall not play with the appliance. Cleaning

and user maintenance shall not be made by children without supervision.

- The plug must be removed from the socket-outlet before cleaning or

maintaining the appliance.

Caution

- Only charge the vacuum cleaner with the adapter supplied. During

charging, the adapter feels warm to the touch. This is normal.

- Always switch off the vacuum cleaner after use and when you charge it.

- Never block the exhaust air openings during vacuuming.

- Always use the vacuum cleaner with the lter unit assembled.

- Make sure that the appliance is installed with the wall xture mounted

to the wall according to the instructions in the user manual.

- Be careful when you drill holes in the wall to attach the wall xture, to

avoid the risk of electric shock.

- Maximum noise level: Lc = 84.5 dB(A)

ENGLISH 7

Electromagnetic elds (EMF)

This Philips appliance complies with all applicable standards and regulations regarding exposure to

electromagnetic elds.

Ordering accessories

To buy accessories or spare parts, visit www.shop.philips.com/service or go to your Philips

dealer. You can also contact the Philips Consumer Care Centre in your country (see the worldwide

guarantee leaet for contact details).

Recycling

- This symbol on a product means that the product is covered by European Directive 2012/19/

EU (Fig. 1).

- This symbol means that the product contains a built-in rechargeable battery covered by

European Directive 2006/66/EC which cannot be disposed of with normal household waste.

Follow the instructions in section ‘Removing the rechargeable battery’ to remove the

battery (Fig. 2).

- Inform yourself about the local separate collection system for electrical and electronic products

and rechargeable batteries. Follow local rules and never dispose of the product and rechargeable

batteries with normal household waste. Correct disposal of old products and rechargeable

batteries helps prevent negative consequences for the environment and human health.

Removing the rechargeable batteries

Batteries may explode when exposed to high temperatures or re.

Only remove the rechargeable batteries if they are completely empty.

You can remove the rechargeable batteries in the following way.

1 Disconnect the appliance from the mains and let it run until it stops.

2 Remove the dust bucket and the cyclone from the appliance.

3 Undo the 10 screws in the back of the housing of the appliance (Fig. 3).

4 Remove the housing of the appliance (Fig. 4).

5 Remove the motor unit and the suction part (Fig. 5).

6 Undo the 4 screws that keep the battery compartment cover in place (Fig. 6).

7 Remove the battery compartment cover (1) and take out the battery pack (2) (Fig. 7).

8 Disconnect the battery pack from the appliance.

Guarantee and support

If you need information or support, please visit www.philips.com/support or read the separate

worldwide guarantee leaet.

Troubleshooting

This chapter summarises the most common problems you could encounter with your appliance.

If you are unable to solve the problem with the information below, visit www.philips.com/

support for a list of frequently asked questions or contact the Philips Consumer Care Centre in

your country.

ENGLISH8

Problem Cause Solution

The appliance does

The battery light ashes fast

To charge the batteries, insert the

not work when I push

because the batteries are low.

small plug into the socket on the

the button.

appliance and insert the adapter into

a wall socket.

You cannot use the appliance

You have to remove the small plug

because the appliance is still

from the socket on the appliance

charging.

before you can switch on the

appliance.

You have to press two buttons. First press the on/off button to

switch on the appliance. Then press

the MAX button to get maximum

suction power.

The vacuum cleaner

The lter and the cyclone are

Clean the lter and the cyclone.

has a lower suction

dirty.

power than usual.

You have not connected the

Connect the dust bucket, the dust

dust bucket, the dust separator

separator and the cyclone properly.

and the cyclone properly.

Incorrect assembly of these parts

causes air leakage, which leads to

loss of suction power.

Dust escapes from the

The lter is dirty. Clean the lter.

vacuum cleaner.

The brush does not

The brush has encountered too

Clean the brush.

turn anymore.

much resistance.
