Philips FC9122: инструкция

Specialist

Specialist

3

1 2 3 4

5 6 7 8

9 10 11 12

13 14 15 16

17 18 19 20

4

5

ENGLISH 6

POLSKI 11

ROMÂNĂ 16

РУССКИЙ 21

ČESKY 27

MAGYAR 32

SLOVENSKY 37

УКРАЇНСЬКІЙ 42

HRVATSKI 47

EESTI 52

LATVISKI 57

LIETUVIŠKAI 62

SLOVENŠČINA 67

БЪЛГАРСКИ 72

SRPSKI 77

Specialist

ENGLISH6

Important

Read these instructions for use carefully before using the appliance and save them for future

reference.

◗ Only use Philips S-bag double-layer paper dustbags (type FC8021), or the cotton dustbag

provided (some versions only).

◗ Check if the voltage indicated on the appliance corresponds to the local mains voltage before

you connect the appliance.

◗ Do not use the appliance if the plug, the cord or the appliance itself is damaged.

◗ If the mains cord or another part of this appliance is damaged, it must only be replaced by

Philips or a service centre authorised by Philips in order to avoid hazardous situations.

◗ Never use the vacuum cleaner to suck up water or any other liquid. Never suck up ashes

until they are cold.

◗ When the vacuum cleaner is used to suck up fine dust, the pores of the dustbag may become

clogged, causing the passage of air through the dustbag to become obstructed.As a result, the

dustbag-full indicator will indicate that the dustbag needs to be replaced, even though the

dustbag is not full at all.

◗ Never use the appliance without the Motor Protection Filter.This could damage the motor

and shorten the life of the appliance.

◗ Do not point the hose at the eyes or ears nor put it in your mouth when the vacuum

cleaner is switched on and the hose is connected to the vacuum cleaner.

◗ Noise level: Lc = 75 dB(A)

Preparing for use

Connecting accessories

Hose

1 To connect the hose, push it firmly into the appliance ("click") (fig. 1).

2 To disconnect the hose, push the buttons on the swivel and pull the hose out of the

appliance (fig. 2).

Tube

◗ Connect the tube to the handgrip by pressing the spring-loaded lock button on the handgrip

and inserting the handgrip into the tube. Fit the spring-loaded lock button into the opening in

the tube ("click") (fig. 3).

◗ To disconnect the tube from the handgrip, press the spring-loaded lock button and pull the

handgrip out of the tube.

◗ Use the same method to connect and disconnect the other accessories.

Telescopic tube (specific types only)

1 Connect the tube to the handgrip ("click").

2 Adjust the tube to the length you find most comfortable during vacuum cleaning (fig. 4).

Reach & Clean nozzle

◗ The Reach & Clean nozzle can be used on either carpets or hard floors.The nozzle can be

put in 4 different positions, allowing you to also vacuum clean hard-to-reach places in an easy

way.The nozzle can be turned 360 degrees clockwise as well as anticlockwise (fig. 5).
