Karcher IB 7-40 Adv: Technical specifications

-

9

A Pressure in MPa

B Pressure in bar

C Volume stream in m

3

/min

1 straight nozzles

2 angled nozzles

A Pressure in MPa

B Pressure in bar

C Noise level in dB(A)

1 Round jet nozzle, short

2 Flat stream nozzle, short

3 Flat jet nozzle, angled

4 Round jet nozzle, long

5 Flat stream nozzle, long, included in de-

livery

A Pressure in MPa

B Pressure in bar

C Noise level in dB(A)

1 Round jet nozzle, short

2 Flat stream nozzle, short

3 Flat jet nozzle, angled

4 Round jet nozzle, long

5 Flat stream nozzle, long, included in de-

livery

Technical specifications

Electrical connection

Voltage

V

220...240

Current type

1~

Frequency

Hz

50

Connected load

kW

0,6

Leakage current, typ.

mA

7,5

FI safety switch

delta I in A

0,03

Compressed air

Nominal width of hose

Inch

1/2

Pressure supply (max.)

MPa (bar)

1,0 (10)

Pressure supply (min.)

MPa (bar)

0,2 (2)

Compressed air consumption

m

3

/min

0,5...3,5

Quality of compressed air

*

Performance data

Jet pressure (max.)

MPa (bar)

1,0 (10)

Diameter of dry ice pellets (max.)

mm

3

Dry ice consumption

kg/h

15...50

Dimensions

Contents of dry ice container

kg

15

Width

mm

510

Depth

mm

768

Height

mm

1096

Weight of IB 7/40 Classic, ready to operate

kg

93

Weight of IB 7/40 Advanced, ready to operate

kg

95

Weight of IB 7/40 Classic, empty, without  acessories

kg

70

Weight of IB 7/40 Advanced, empty, without  acessories

kg

71

Weight of the jet equipment (spray agent hose, spray gun, tool case)

kg

6,75

Recoil force of hand spray gun (max.)

N

30

Torque of jet pistol (max.), only with angled nozzle

N

8

Machine vibrations

Jet pistol

m/s²

1,2

Hose for spraying agent

m/s²

1,2

* dry and oil-free, at least one aftercooler and a separator must be downstream of the compressor

Compressed air demand

Sound

Sound power level

21

EN
