Karcher B 40 C Ep: English

English



-

1

Please read and comply with

these original instructions pri-

or to the initial operation of your appliance

and store them for later use or subsequent

owners.

Before using the appliance for the first time,

read and observe these operating instruc-

tions and the accompanying brochure:

Safety information for brush cleaning units

and spray-extraction units, No. 5.956-251.

The appliance may only be operated

when the hood and all lids are closed.

In dangerous situations, release the

safety switch.

The appliance must only be operated on

surfaces that do not exceed the max. per-

mitted incline (see "Technical Specifica-

tions").

몇

Warning

Do not use the appliance on inclines.

Safety devices serve to protect the user

and must not be rendered inoperational or

their functions bypassed.

If the safety switch is released, the brush

drive shuts off.



Danger

Immediate danger that can cause severe

injury or even death.

몇

Warning

Possible hazardous situation that could

lead to severe injury or even death.

Caution

Possible hazardous situation that could

lead to mild injury to persons or damage to

property.

The scrubber vacuum is used for wet

cleaning or polishing of level floors.

–

Rotating roller or disc brushes clean the

floor while adding detergent. The con-

taminated cleaning liquid is suctioned

into the wastewater reservoir.

–

The appliance can be easily adjusted to

the cleaning task by setting the water

quantity.

–

Depending on the selected cleaning

head, the working width of the B 40 is

between 430 mm and 550 mm.

–

Power supply operation allows a high

capacity without a restriction of the

working time.

Note

The appliance can be equipped with vari-

ous accessories depending on the cleaning

task.

Please request our catalogue or visit us on

the Internet at www.kaercher.com.

Use this appliance only as directed in these

operating instructions.

–

The appliance may only be used for the

cleaning of hard surfaces that are not

sensitive to moisture and polishing op-

erations.

–

The appliance is not suited for the

cleaning of frozen grounds (e.g. in cold

stores).

–

The appliance may only be equipped

with original accessories and spare

parts.

–

The appliance is not suited for the use

in potentially explosive environments.

–

The machine should not be used to

suck in inflammable gases, undiluted

acids or solvents.

This includes petrol, thinning agents or

hot oil that can form an explosive mix-

ture when it comes in contact with

sucked air.  Do not use acetone, undi-

luted acids and solvents as they are ag-

gressive towards the materials from

which the appliance is made.

–

The machine has been approved for

use on surfaces with max. gradients as

listed under "Technical Specifications".

Notes about the ingredients (REACH)

You will find current information about the

ingredients at:

www.kaercher.com/REACH

The warranty terms published by our com-

petent sales company are applicable in

each country. We will repair potential fail-

ures of your accessory within the warranty

period free of charge, provided that such

failure is caused by faulty material or de-

fects in fabrication. In the event of a warran-

ty claim please contact your dealer or the

nearest authorized Customer Service cent-

er. Please submit the proof of purchase.

Contents

Safety instructions  . . . . . . .

EN  . .  1

Safety Devices  . . . . . . .

EN  . .  1

Symbols in the operating in-

structions. . . . . . . . . . . .

EN  . .  1

Function  . . . . . . . . . . . . . . .

EN  . .  1

Proper use  . . . . . . . . . . . . .

EN  . .  1

Environmental protection  . .

EN  . .  1

Warranty . . . . . . . . . . . . . . .

EN  . .  1

Operating and Functional Ele-

ments  . . . . . . . . . . . . . . . . .

EN  . .  2

Illustration of scrubbing vac-

uum . . . . . . . . . . . . . . . .

EN  . .  2

Before Startup. . . . . . . . . . .

EN  . .  3

Installing the Brushes . .

EN  . .  3

Installing the Vacuum Bar

EN  . .  3

Unloading  . . . . . . . . . . .

EN  . .  3

Operation  . . . . . . . . . . . . . .

EN  . .  3

Electrical connection . . .

EN  . .  3

Filling in detergents . . . .

EN  . .  3

Setting the water quantity

EN  . .  3

Setting the Vacuum Bar

EN  . .  3

Setting the Advance Speed

(BD cleaning head only)

EN  . .  3

Cleaning  . . . . . . . . . . . .

EN  . .  3

Shutting Down the Appliance

EN  . .  4

Drain off dirt water. . . . .

EN  . .  4

Drain off clean water . . .

EN  . .  4

Transport  . . . . . . . . . . . . . .

EN  . .  4

Storage . . . . . . . . . . . . . . . .

EN  . .  4

Maintenance and care  . . . .

EN  . .  4

Maintenance schedule  .

EN  . .  4

Maintenance Works  . . .

EN  . .  4

Maintenance contract . .

EN  . .  5

Frost protection. . . . . . . . . .

EN  . .  5

Faults  . . . . . . . . . . . . . . . . .

EN  . .  6

Accessory B 40. . . . . . . . . .

EN  . .  7

BR appliance B 40 (brush

roller accessories) . . . . .

EN  . .  7

BD appliances B 40 (disc

roller accessories) . . . . .

EN  . .  7

BR/BD appliances B 40

(vacuum bar accessories)

EN  . .  7

Technical specifications . . .

EN  . .  8

EC Declaration of Conformity

EN  . .  8

Spare parts . . . . . . . . . . . . .

EN  . .  8

Safety instructions

Safety Devices

Safety button

Symbols in the operating instruc-

tions

Function Proper use Environmental protection

The packaging materials are

recyclable. Please do not throw

packaging in the domestic

waste but pass it on for recy-

cling.

Old units contain valuable recy-

clable materials. Batteries, oil

and similar substances may

not be released into the envi-

ronment. Therefore please dis-

pose of old units through

suitable collection systems.

Warranty

10 EN
