Samsung EC-L100ZRBA-US: Specifications

12

Specifications

Image Sensor

- Type : 1/2.5" CCD

- Effective Pixel : Approx. 8.2 Mega-pixel

- Total Pixel : Approx. 8.3 Mega-pixel

Lens

- Focal Length :  SAMSUNG Lens f = 6.2 ~ 18.6mm

(35mm film equivalent : 37 ~ 111mm)

- F No. : F 2.8(W) ~ F 5.2(T)

- Digital Zoom :

·

Still Image mode : 1.0X ~ 3.0X

·

Play mode : 1.0X ~ 10.2X

     (depends on image size)

LCD Monitor

- 2.5" color TFT LCD (230,000 dots)

Focusing

- Type :  TTL auto focus (Multi-AF, Center AF, Face Detection AF)

 -

Range

 Shutter

- Speed 1 ~ 1/1,500 sec. (Manual : 8 ~ 1/1,500 sec.)

Exposure

- Control : Program AE

- Metering :  Multi, Spot, Center Weighted

- Compensation :

±

2EV (1/3EV steps)

- ISO : Auto, 80, 100, 200, 400, 800, 1600

Flash

- Modes :  Auto, Auto & Red-eye reduction, Fill-in flash,

Slow sync, Flash off, Red-eye Fix

- Range : Wide : 0.2m ~ 4.7m, Tele : 0.5m ~ 2.5m(ISO AUTO)

- Recharging Time : Approx. 4 sec

Sharpness

- -2, -1, 0, +1, +2

Color Effect

 -

Normal, B&W, Sepia, Red, Green, Blue, Negative, Custom Color

Normal Macro

Auto

Macro

Wide

80cm ~ Infinity

5cm ~ 80cm

5cm ~ Infinity

Tele

50cm ~  80cm

50cm ~ Infinity

White Balance

 -

Auto, Daylight, Cloudy, Fluorescent_H, Fluorescent_L,

Tungsten, Custom

Voice Recording

  - Voice Recording (max. 10 hours)

- Voice Memo in Still Image (max. 10 sec.)

Date Imprinting

- Date, Date & Time, Off (user selectable)

Shooting

- Still Image

·

Mode :  Auto, Program, Manual, DIS, Photo Help Guide, Scene,

Portrait

·

Scene :  Nightscene, Children, Landscape, Close up, Text,

Sunset, Dawn, Backlight, Firework, Beach & Snow

·

Shooting :  Single, Continuous, AEB, Motion Capture

·

Self-timer : 10 sec., 2 sec., Double, Motion Timer

 -

Movie

·

With Audio or without Audio

※

  The maximum memory capacity of continuous

movie is 2 hours.

·

Size :  640x480, 320x240

·

Frame rate :  30 fps, 15 fps

Storage

 -

Media

·

Internal memory : 10MB flash memory

·

External Memory (Optional) :  SD (up to 2GB guaranteed)/

SDHC Card (up to 4GB guaranteed)/

MMC Plus (Up to 2GB)

 -

File

Format

·

Still Image :  JPEG (DCF), EXIF 2.2, DPOF 1.1, PictBridge 1.0

·

Movie : AVI (MJPEG)

·

Audio : WAV

13

ENGLISH

Specifications

- Image Size













3264

X

2448

3264

X

2176

3264

X

1836

2592

X

1944

2048

X

1536

1024

X

768

- Capacity (256 MB Size)













Super Fine

64

71

84

100

150

459

Fine

117

135

157

186

269

822

Normal

171

192

220

256

372

868

   ※

  These figures are measured under Samsung standard conditions and may

vary depending on shooting conditions and camera settings.

"

E

"

 Button

- Effect :  Color, Image Adjust(Sharpness, Contrast, Saturation)

- Editing :   Resize, Rotate, Color, Image Adjust (ACB, Red Eye

Fix, Brightness, Contrast ,Saturation)

Image Play

- Type :  Single image, Thumbnails, Multi Slide show, Movie

Interface

- Digital output connector : USB 2.0 High Speed

- Audio : Mono

 - Video output : NTSC, PAL (user selectable)

Power Source

- Rechargeable battery : SLB-10A, 3.7V (1,050mAh)

- Adaptor : SAC-47 (DC 4.2V, 400mA)

Dimensions (WxHxD)

- 87.7 X 56.3 X 20mm (excluding protrusions)

Weight

- 114.5g (without batteries and card)

Operating Temperature

- 0 ~ 40

°

C

Operating Humidity

- 5 ~ 85%

Software

- Samsung Master, Adobe Reader

※

 Specifications are subject to change without prior notice.

※

 All trademarks are the property of their respective owners.
